12.

Technical Data

This chapter provides information on the technical data of the device.
12.1

Device Model

Device
HPM5140-CAN-A
It will include USB memory stick and USB cable (USB-C to USB-A).
12.2

Mechanical Data

Designation
Dimensions (W × H × D)
Weight
Type of protection
Ambient temperature
Storage temperature
Relative humidity
Environmental impact test
Housing
Protective casing
VESA holder
12.3

Display Data

Designation
Resolution
Size
Brightness
HPM5000-MA-MUL-4294 Issue 1.0
Interface for up to 6 Webtec CAN sensors
2 inputs for standard analogue sensors
Property
215 × 60 × 154 mm
Approx. 850 g
IP 65 (EN 60529:1989 +A1:1999 + A2:2013), all screw connections
must be provided with sensors or protective caps
-20...+50° C
-30...+80°C
max. 95 %, non-condensing
Drop test 1 m (EN 60068-2-31:2008)
ABS/PC
TPE, thermoplastic elastomer
75 mm × 75 mm
Property
800 × 480 pixels
4.3"
700 cd
05/24
Technical Data
91
