- Page 1 LEPUS BOX 120V - 24V - BR 36V SEA USA Inc. 10850 N.W. 21st - unit 160 - DORAL - MIAMI Florida (FL) 33172 Phone: ++ 1 - 305.594.1151 www.sea-usa.com 67411870 REV. 04 - 07/2022...
- Page 2 UL 325 ED. 7 FOR GATE OPERATORS GENERAL SAFETY PRECAUTIONS The following precautions are an integral and essential part of the product and must be supplied to the user; Read them carefully as they contain important indications for the safe installation, use and maintenance. 1.
- Page 3 A gate operator shall be provided with the specific instructions describing all user adjustments required for proper operation of the gate. Detailed instructions shall be provided regarding user adjustment of any clutch or pressure relief adjustments provided. The instructions shall also indicate the need for periodic checking and adjustment by a qualified technician of the control mechanism for force, speed, and sensitivity.
- Page 4 e. A wireless contact sensor such as one that transmits radio frequency (RF) signals to the gate operator for entrapment protection functions shall be located where the transmission of the signals is not obstructed or impeded by building structures, natural landscaping or similar obstruction. A wireless contact sensor shall function under the intended end-use conditions.
- Page 5 As for misunderstandings that may arise refer to your area distributor or call our help desk. These instructions are part of the device and must be kept in a well-known place. The installer shall follow the provided instructions thoroughly. SEA products must only be used to automate doors, gates and wings.
- Page 6 1/2” MECHANICAL STOPS SEA operators have been designed for the automation of gates for vehicles use only Be aware to avoid the crossing of the gate path because it is very dangerous for pedestrians - Make sure that no person could activate the automation or act on it from the outside...
-
Page 7: General Features
GENERAL FEATURES LEPUS BOX is an electro-mechanical chain operator. The LEPUS BOX can be supplied with either mechanical clutch or electronic sensing device as methods of limiting the motor torque. The gate open & close stop limits are accurately stored by mechanically triggering the on-board micro-switch. Manual release is quickly achieved by operating a key manual release system.The control unit allows to choose... -
Page 8: Standard Installation
STANDARD INSTALLATION 1) O PERATOR WARNING WARNING 2) C ONCRETE PLATFORM Moving Gate Can Cause Serious Injury Or Death Moving Gate Can Cause - KEEP CLEAR ! Gate may move at any time without prior Warning. - Do not let children operate the gate or Serious Injury Or Death play in the gate area. - Page 9 Fig. 17 Fig. 16 HEAD FASTENER R425 ¹⁄ ’’ 3 ¹⁄ ’’ CONCRETE BASEMENT 3’’ ELECTRIC CABLES SHEATH 27’’ 3 - CHAIN SYSTEM 3.1. Secure two sturdy brackets at the two extremities of the gate for attaching the chain (Fig. 18) 3.2.
-
Page 10: Limit Switch Setup
Fig. 23 Fig. 24 4 - LIMIT SWITCH SETUP 4.1. Unscrew and lift the operator casing 4.2. Switch off the main power supply (120V) Before adjusting the limit switch, make sure that the operator chain is correctly fasten to the gate, that limit switch cursor is in the middle of its run (Fig. - Page 11 5 - MECHANICAL CLUTCH SETUP 5.1. Unscrew and lift the operator casing (Fig. 28 and Fig. 29) 5.2. Switch off the main power supply (120V) .3. To adjust the clutch, act on the grub screw «A» by the use of an hexagonal key (Fig. 30) 5.4.
-
Page 12: Manual Release System
7 - MANUAL RELEASE SYSTEM WARNING - Rotate and open the lock cap (Fig. 33) - Insert the hexagon «T» key (Fig. 34) and turn clockwise until it stops (Fig. 35) CAUTION! - Manually open and close the gate - Insert the hexagon «T» key and turn anti-clockwise until it stops (Fig. 35) CAUTION! - Slowly move the gate manually until the release is re-locked CAUTION! - Page 13 8 - 120V POWER WIRINGS Fig. 36 POWER L(P) SUPPLY GROUNDING TERMINAL CAPACITOR MOP MN MCL FASTON MOTOR WIRING 20 19 18 17 16 15 14 TERMINAL « » GATE 120V ~ ½ HP POWER and DUAL 1 HP WIRE MOTOR Up to Up to...
- Page 14 THE MANUFACTURER CAN NOT BE DEEMED RESPONSIBLE FOR ANY DAMAGE OR INJURY CAUSED BY IMPROPER USE OF THIS PRODUCT SEA reserves the right to make all the necessary changes and modifications of the products or manuals without giving prior notice...
- Page 15 PRICES: Prices are based on the Price List in force. Discounts and quotation from Sales Rep. and other selling branches must be approved by SEA. Prices are F.O.B SEA Warehouse in Miami and do not include shipments costs. SEA reserves the right to modify the price list at any time and provide notice to its sales network.
- Page 16 SEA USA Inc. 10850 N.W. 21st - unit 160 - DORAL - MIAMI Florida (FL) 33172 Phone: ++ 1 - 305.594.1151 www.sea-usa.com...
