Summary of Contents for Haier HWO60S12EPB5
- Page 1 Oven, 60cm, 12 Function, Self-cleaning with Air Fry HWO60S12EPB5, HWO60S12EPX5, HWO60S12EPG5 USER GUIDE NZ AU...
-
Page 3: Table Of Contents
CONTENTS Safety and warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Product overview . -
Page 4: Safety And Warnings
SAFETY AND WARNINGS WARNING! Electric Shock Hazard Failure to follow this advice may result in electric shock or death. • Do not cook on a broken or cracked cooktop . If the cooktop surface should break or crack, switch the appliance off immediately at the mains power supply (wall switch) and contact a qualified technician . - Page 5 SAFETY AND WARNINGS WARNING! Hot Surface Hazard Failure to follow this advice could result in burns and scalds. • Do not touch surface units or areas near units . Surface units maybe hot even though they are dark in colour . •...
- Page 6 SAFETY AND WARNINGS READ AND SAVE THIS GUIDE Only use the oven for its intended purpose, that is only for the cooking of foods: any other use, for example as a heat source, is considered improper and therefore dangerous. The manufacturer cannot be held responsible for any damage resulting from improper, incorrect or unreasonable usage.
- Page 7 SAFETY AND WARNINGS Do not install the product in open environments exposed to atmospheric agents. This appliance is designed to be used at altitude lower than 2000m. It is recommended to wear protective gloves during installation to avoid cut injuries. Do not install the product in open environments exposed to atmospheric agents.
- Page 8 SAFETY AND WARNINGS Use and maintenance Wash all accessories before first use with a solution of hot water and washing up liquid. The dripping pan collects the residues that drip during cooking. When you place the grid or air fry tray on the side racks, make sure that the shorter section of the side (between the stop and the extremity) is directed towards the interior of the oven.
-
Page 9: Product Overview
PRODUCT OVERVIEW FEATURES AND ACCESSORIES Control panel Oven door Shelf positions Side racks Racks Baking tray Roast dish Airfry tray Fan cover... -
Page 10: Control Panel
CONTROL PANEL Function dial Turn to select a function . Time Press to set clock, cooking duration, delayed start and timer . Temperature Press to check oven temperature and start function . FAST PREHEAT Display Displays the clock, cooking duration, timer and temperature . Key lock Lock the oven controls to prevent accidental use . -
Page 11: First Use
FIRST USE Preparing your oven Before using your oven for the first time, remove and wash all accessories, and clean the inside of the oven with a damp, soft cloth and mild detergent . Wipe the outside with a damp, soft cloth . Dry with a clean cloth . Run the empty oven at maximum temperature for 60 minutes to remove the newness smell . - Page 12 FIRST USE Setting the display brightness Turn the control dial to increase or decrease the display brightness . Press to confirm . Setting the alert volume level Turn the control dial to increase or decrease the alert volume level . Press to confirm .
-
Page 13: Using The Oven
USING THE OVEN 1. Turn the to select FUNCTION DIAL the desired cooking function . This turns the oven The default temperature for the function will show on the display . 2. Turn the to adjust CONTROL DIAL the temperature . Accessing the time menu Press to access the time menu... - Page 14 USING THE OVEN Setting the cooking duration Press to select COOKING then turn the control DURATION dial to set the duration . The countdown will start immediately if there is no preheat stage for the function . Turn the control dial to adjust the duration during cooking .
- Page 15 USING THE OVEN DELAYED START After setting a cooking duration, you can schedule a time for cooking to start . Press to select DELAYED START then turn the control dial to set a cooking start time . Not available with GRILL FAN GRILL Turn the dial back to...
-
Page 16: Cooking Functions
COOKING FUNCTIONS Preheating the oven Ensure you remove all accessories from the oven before using functions that have a preheating stage . FAST PREHEAT combines fan and heating elements to preheat the oven, without using the cooling fan, to FAST PREHEAT heat the oven faster and save energy . - Page 17 COOKING FUNCTIONS DEFAULT SUGGESTED TEMP°C / ICON FUNCTION SHELF PREHEAT COOKING SUGGESTIONS TEMP°C POSITION RANGE Ideal for all kinds of pizzas without preheating the oven . 300°C Pizza L2/L3 Use lower temperatures for 200–300°C frozen items and 300°C for homemade pizza . Ideal for sausages, steaks and toast .
-
Page 18: Care And Cleaning
CARE AND CLEANING General recommendations We recommend cleaning the oven after each use . Wait for the oven to cool before cleaning . Do not line the oven walls with aluminium foil or single-use protection as these may damage the enamel interior . - Page 19 CARE AND CLEANING Hydro cleaning This function uses steam to clean light levels of residue from the oven interior in a quick and eco-friendly way . Always use distilled or drinkable water . 1. Remove all racks, trays and side racks from the oven .
- Page 20 CARE AND CLEANING Cleaning the accessories We recommend you clean and dry the accessories thoroughly after every use . If required, soak them for 30 minutes in a mixture of hot water and mild detergent before cleaning . Cleaning the side racks 1.
- Page 21 CARE AND CLEANING Removing the door The door can be removed for greater access when cleaning the oven . 1. Open the door fully and use a screwdriver to rotate the hinge locks outwards, then carefully lift the door off and place it on a soft, level surface .
- Page 22 CARE AND CLEANING Removing and cleaning the door glass 1. Shut the door halfway, then press the buttons on both sides of the door at the same time to release the cover on top of the door . 2. Carefully remove the inner and middle panes and wipe clean with a soft, damp cloth and mild detergent .
-
Page 23: Replacing The Lights
REPLACING THE LIGHTS Always disconnect the oven from the power supply before replacing the lights . Replacing the back light 1. Turn the protective light cover clockwise to remove it . 2. Unscrew the light bulb to remove it . Replace with a new bulb and refit the protective cover . -
Page 24: Troubleshooting
TROUBLESHOOTING PROBLEM POSSIBLE CAUSES WHAT TO DO ER__ There is an error . If the oven is switched on, switched it off and wait is showing several minutes before powering it on again . If the on the display error has disappeared, you can continue to use the oven . -
Page 25: Manufacturer's Warranty
. You must produce both warranty card and proof of purchase in the event of a warranty repair being required . When you purchase any new Haier Product you automatically receive a two year Manufacturer's Warranty covering parts and labour for servicing . - Page 26 MANUFACTURER'S WARRANTY Note: This Warranty is an extra benefit and does not affect your legal rights and applies only to product purchased in New Zealand and Australia . Please keep this Warranty Card in a safe place . For Australian customers: Our goods come with guarantees that cannot be excluded under the Australian Consumer Law .
-
Page 27: Customer Service
CUSTOMER SERVICE We recommend our Haier Customer Service and the use of original spare parts . If you have a problem with your appliance, please first check TROUBLESHOOTING . If you cannot find a solution there, please contact: Your local dealer The Service &... - Page 28 WWW .HAIER .COM .AU WWW .HAIER .CO .NZ 432405A 70062299 07.24...
