WARNING: If the information in this manual is not
followed exactly, a fire or explosion may result causing
property damage, personal injury or loss of life.
— Do not store or use gasoline or other flammable va-
pors and liquids in the vicinity of this or any other
appliance.
— WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any
phone in your building.
• Immediately call your gas supplier from a neighbor's
phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire
department.
— Installation and service must be performed by a quali-
fied installer, service agency or the gas supplier.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
Questions, problems, missing parts? Before returning to your retailer, call
our customer service department at 1-866-762-4050, 8:00 am - 4:30 pm CST,
Monday through Friday or email service@bluegrassliving.com
MODELS
ANI ( SKU: 170040 )
AND
ALI ( SKU: 170039 )
REMOTE CONTROL
VENT - FREE GAS
FIREPLACE INSERT
OWNER'S OPERATION AND
INSTALLATION MANUAL
PFS
®
US
CSA/ANS
Z21.11.2 2019
Unvented Room
Heaters
PFS F09-056
Advertisement
Table of Contents
Related Manuals for Bluegrass Living HearthSense ANI
Summary of Contents for Bluegrass Living HearthSense ANI
- Page 1 MODELS ANI ( SKU: 170040 ) ALI ( SKU: 170039 ) REMOTE CONTROL VENT - FREE GAS FIREPLACE INSERT OWNER’S OPERATION AND INSTALLATION MANUAL CSA/ANS Z21.11.2 2019 Unvented Room ® Heaters PFS F09-056 WARNING: If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Safety ............3 Operation ..........17 Qualified Installing Agency ......4 Inspecting Burners........20 Specifications ..........5 Care And Maintenance ......21 Product Features ........5 Troubleshooting ........23 Local Codes..........5 Replacement Parts ........27 Unpacking..........6 Accessories .......... -
Page 3: Safety
SAFETY IMPORTANT: Read this owner’s WARNING: Do not allow fans manual carefully and completely to blow directly into fireplace. before trying to assemble, op- Avoid any drafts that alter burner erate, or service this heater. flame patterns. Improper use of this heater can cause serious injury or death from WARNING: Do not use a burns, fire, explosion, electrical... -
Page 4: Qualified Installing Agency
SAFETY Do not use heater if any part has been WARNING: The fire screen or under water. Immediately call a qualified guard designed for this unvent- service technician to inspect the room ed appliance must be installed heater and to replace any part of the prior to operation. -
Page 5: Specifications
SPECIFICATIONS Model Gas Type Natural Gas Propane Gas Maximum Input Rating 20,000 Btu/Hr 20,000 Btu/Hr Pressure Regulator Setting 4" W.C. 9" W.C. Max. 10.5" Max. 14" Inlet Gas Pressure* (inches of water) Min. 5" Min. 11" Ignition Electronic Electronic Fireplace Dimensions (WxHxD) • 21 1/2" × 34 1/2" × 15 3/8" Carton Dimensions (WxHxD) •... -
Page 6: Unpacking
UNPACKING 1. Remove top inner pack. 7. Remove log set by cutting plastic ties. 2. Tilt carton so that heater is upright. 8. Carefully unwrap log. 3. Remove protective side packaging. 9. Check for any shipping damage. If heater or log is damaged, promptly inform your 4. -
Page 7: Air For Combustion And Ventilation
AIR FOR COMBUSTION AND VENTILATION WARNING: This heater shall WARNING: This heater shall not be installed in a room or not be installed in a confined space space unless the required vol- or unusually tight construction ume of indoor combustion air unless provisions are provided is provided by the method de- for adequate combustion and... -
Page 8: Installation
AIR FOR COMBUSTION AND VENTILATION Ventilation Air From Outdoors The combined spaces must have enough Provide extra fresh air by using ventilation fresh air to supply all appliances in both grills or ducts. You must provide two perma- spaces. air entering the attic will activate the nent openings: one within 12"... - Page 9 INSTALLATION CONNECTING ELECTRICAL SUPPLY This fireplace insert requires an 120V elec- trical outlet within 4 feet of the unit. There is a power supply for the remote receiver located in the bottom of the fireplace insert. Extensions cords may be used. The remote receiver requires 4 AA batter- ies.
- Page 10 BUILT - IN FIREPLACE INSTALLATION Figure 6 - Fireplace Dimensions Built-in installation of this fireplace involves 1. Frame in rough opening. Use dimensions installing fireplace into a framed-in enclosure. shown in Figure 8 (page 11) for the rough This makes the front of the fireplace flush opening.
- Page 11 CLEARANCES TO COMBUSTIBLES Figure 8 - Framing Rough Opening Figure 9 - Framing Rough Opening - Corner Installation SAFE ZONE 12" EILING Figure 11 - Figure 10 - Nailing Flanges - Sides FIREPLACE TOP HOOD Mantel Clearances HearthSense 200549-08A...
- Page 12 INSTALLATION CONNECTING TO GAS SUPPLY WARNING: A qualified ser- CAUTION: For propane gas, vice technician must connect never connect heater directly heater to gas supply. Follow all to the gas supply. This heater local codes. requires an external regula- tor (not supplied). Install the external regulator between the WARNING: This appliance heater and propane gas supply.
- Page 13 INSTALLATION If you do not reduce incoming gas pressure, IMPORTANT: Install an equipment shutoff heater regulator damage could occur. Install valve in an accessible location. The equip- external regulator with the vent pointing down ment shutoff valve is for turning on or shutting as shown in Figure 13.
- Page 14 INSTALLATION CHECKING GAS CONNECTIONS Test Pressures Equal To or Less Than WARNING: Test all gas piping 1/2 PSIG (3.5 kPa) and connections for leaks after 1. Close equipment shutoff valve (see Fig- installing or servicing. Correct ure 15). all leaks at once. 2.
- Page 15 INSTALLATION PRESSURE TESTING HEATER GAS CONNECTIONS 1. Open equipment shutoff valve (see Figure 17, page 14). Apply a noncorrosive leak 15, page 16). detection fluid to all joints. Bubbles form- ing show a leak. 2. Open main gas valve located on or near gas meter for natural gas or open propane 5.
- Page 16 INSTALLATION BATTERY INSTRUCTIONS CAUTION: Do not dispose of batteries in fire, batteries may explode or leak. Battery • Battery is included. Positive • Remove battery when depleted. • Be sure to observe proper polarity (+/-) when installing or replacing the battery. Damage due to improper battery installation may void the warranty on the product.
-
Page 17: Operation
OPERATION FOR YOUR SAFETY READ BEFORE LIGHTING WARNING: If you do not fol- • Immediately call your gas supplier low these instructions exactly, a from a neighbor’s phone. Follow the fire or explosion may result caus- gas supplier’s instructions. • If you cannot reach your gas supplier, ing property damage, personal call the fire department. - Page 18 OPERATION 8. Be sure the slide switch on the front of the 6. With control knob pressed in, push down receiver is in the ON position. and release ignitor button. This will light pilot (Figure 25) The pilot is attached to the rear of the front of burner.
- Page 19 OPERATION REMOTE CONTROL SYSTEM Programming the Remote and Receiver Key Settings ON - Operates unit to on position, manually The remote and receiver must be “learned” to one another. operated solenoid ON. To prepare the receiver box for learning, use OFF - Operates unit to off position, manually a pen or small screwdriver to gently press operated solenoid OFF.
- Page 20 OPERATION Setting°F/°C Scale 2. Press and hold the SET key until the de- The factory setting for temperature is °F. To sired set temperature is reached. The LCD change this setting to °C, press the ON key screen set numbers will increase from 45° and the OFF key on the remote control at to 99°...
-
Page 21: Inspecting Burners
INSPECTING BURNERS IMPORTANT: Owner’s should check pilot flame pattern and burner flame pattern often. Incorrect flame patterns indicate the need for cleaning (see Care and Maintenance, page 22) or service. WARNING: Only a qualified service person should service and repair heater. This includes maintenance requiring replacement or alteration of components. -
Page 22: Care And Maintenance
CARE AND MAINTENANCE WARNING: Turn off heater and let cool before servicing. CAUTION: You must keep control areas, burner, and circulating air passageways of heater clean. Inspect these areas of heater before each use. Have heater inspected yearly by a qualified service techni- cian. - Page 23 CARE AND MAINTENANCE ODS/PILOT Thermocouple Ignitor CAUTION: Never use a wire, Electrode Pilot needle, or similar object to clean Assembly ODS/pilot. This can damage ODS/pilot unit. Use a vacuum cleaner, pressurized air, or a small, soft bristled brush to clean. A yellow tip on the pilot flame indicates dust and dirt in the pilot assembly.
-
Page 24: Troubleshooting
TROUBLESHOOTING WARNING: If you smell gas: • Shut off gas supply. • Do not try to light any appliance. • Do not touch any electrical switch; do not use any phone in your building. • Immediately call your gas supplier from a neighbor’s phone. Fol- low the gas supplier’s instructions. - Page 25 TROUBLESHOOTING Problem Possible Cause Corrective Action When ignitor button is 1. Ignitor electrode is posi- 1. Replace electrode. pressed in, there is no tioned wrong. Ignitor elec- spark at ODS/pilot trode is broken. 2. Ignitor electrode is not con- 2. Replace ignitor cable nected to ignitor cable.
- Page 26 TROUBLESHOOTING Problem Possible Cause Corrective Action Burner(s) does not light 1. Burner orifice is clogged. 1. Clean burner orifice (see after ODS/pilot is lit Care and Maintenance, page 22) or replace burner orifice. 2. Burner orifice diameter is too 2. Replace burner orifice. small.
- Page 27 TROUBLESHOOTING Problem Possible Cause Corrective Action Heater produces a click- 1. Metal is expanding while 1. This is common with most ing/ticking noise just after heating or contracting while heaters. If noise is exces- burner is lit or shut off. cooling.
- Page 28 PARTS MODEL ANI AND ALI This list contains replaceable parts for your heater. When ordering replacement parts, follow the instructions listed under Replacement Parts on page 30 of this manual. ITEM PART # DESCRIPTION AN/LI200MV-221 Top Reflector Panel AN/LI200MV-101 Top Cover Panel AN/LI200MV-104B Back Cover AN/LI200MV-110...
- Page 29 PARTS MODEL ANI AND ALI This list contains replaceable parts for your heater. When ordering replacement parts, follow the instructions listed under Replacement Parts on page 30 of this manual. ITEM PART # DESCRIPTION 161338-01 Ignitor 163814-01 NG Gastrain (ANI) 163814-02 Propane Gastrain (ALI) 160520-01...
-
Page 30: Replacement Parts
REPLACEMENT PARTS Note: Use only original replacement parts. This will protect your warranty coverage for parts replaced under warranty. PARTS UNDER WARRANTY PARTS NOT UNDER WARRANTY Contact authorized dealers of this product. Contact authorized dealers of this product. If they can’t supply original replacement If they can’t supply original replacement parts, call Customer Service toll free at part(s) call Customer Service toll free at... -
Page 31: Technical Service
TECHNICAL SERVICE You may have further questions about installation, operation, or troubleshooting. If so, contact When calling, please have our customer service department at 1-866-762-4050, 8:00 am - 4:30 pm CST your model and serial numbers of your heater ready. HearthSense 200549-08A... -
Page 32: Parts
We make no other warranty, expressed or implied. NEW PRODUCTS Standard Warranty: Bluegrass Living, Inc. warrants this product to be free from defects in materials and components for ONE (1) year from the date of first purchase, provided that the product has been properly installed by a qualified installer in accordance with all local codes and instructions furnished with the unit, operated and maintained in accordance with all applicable instructions.
