VENT - FREE YELLOW
FLAME GAS LOG
CHASSIS
OWNER'S OPERATION
AND INSTALLATION
MANUAL
WARNING: If the information in this manual is not
followed exactly, a fire or explosion may result causing
property damage, personal injury or loss of life.
— Do not store or use gasoline or other flammable va-
pors and liquids in the vicinity of this or any other
appliance.
— WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any
phone in your building.
• Immediately call your gas supplier from a neighbor's
phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire
department.
— Installation and service must be performed by a quali-
fied installer, service agency or the gas supplier.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
Questions, problems, missing parts? Before returning to your retailer, call
our customer service department at 1-866-762-4050, 8:00 am - 4:30 pm CST,
Monday through Friday or email service@bluegrassliving.com
MODELS
BC24/30NR
BC24/30PR
Advertisement
Table of Contents
Related Manuals for Bluegrass Living BC24/30NR
Summary of Contents for Bluegrass Living BC24/30NR
- Page 1 MODELS BC24/30NR BC24/30PR VENT - FREE YELLOW FLAME GAS LOG CHASSIS OWNER’S OPERATION AND INSTALLATION MANUAL WARNING: If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Specifications ..........3 Operation ..........18 Safety ............3 Inspecting Burners........22 Product Features ........5 Care And Maintenance ......23 Local Codes..........5 Troubleshooting ........24 Unpacking..........5 Replacement Parts ........27 Qualified Installing Agency ......6 Accessories .......... -
Page 3: Specifications
SPECIFICATIONS MODEL BC24/30NR BC24/30PR Ignition Electronic Piezo Electronic Piezo Gas Type Natural Propane Max. Input Rating 33,000 BTU/Hr 33,000 BTU/Hr Manifold Pressure 4" W.C. 9" W.C. Inlet Gas Pressure* Max. 9.5" W.C. Max. 14" W.C. (inches of water) Min. 5" W.C. - Page 4 SAFETY build-up inside fireplace and cause glass WARNING: Do not place cloth- to burst. If fireplace opening has vents ing or other flammable material at the bottom, you must open the vents on or near the appliance. Never before operating log set. Always operate heater with glass doors fully open.
-
Page 5: Product Features
PRODUCT FEATURES This log set has been tested and approved to ANSI Z21.11.2 standard for Unvented Heaters and can be operated with the flue damper closed. State and local codes in some areas prohibit the use of vent-free heaters. SAFETY PILOT THERMOSTAT HEAT CONTROL This heater has a pilot with an Oxygen Deple- When the hand held remote is in the... -
Page 6: Qualified Installing Agency
QUALIFIED INSTALLING AGENCY Only a qualified agency should install and in such work; that is familiar with all precau- replace gas piping, gas utilization equipment tions required; and that has complied with or accessories, and repair and equipment ser- all the requirement of the authority having vicing. - Page 7 AIR FOR COMBUSTION AND VENTILATION WARNING: If the area in which the heater may be operated does not meet the required volume for indoor combustion air, combus- tion and ventilation air shall be provided by one of the methods described in the National Fuel Gas Code, ANSI Z223.1/NFPA 54, the International Fuel Gas Code, or applicable local codes.
-
Page 8: Installation
INSTALLATION NOTICE: This heater is intended WARNING: Never install the for use as supplemental heat. heater Use this heater along with your • in a bedroom or bathroom primary heating system. Do not • in a recreational vehicle install this heater as your pri- •... - Page 9 INSTALLATION IMPORTANT: Vent-free heaters add moisture to the air. Although this is beneficial, installing heater in rooms without enough ventilation air may cause mildew to form too much moisture. See Air for Combustion and Ventilation, pages 6 and 7. Before beginning assembly or operation of the product, make sure all parts are pres- ent.
- Page 10 INSTALLATION you must have noncombustible material be- NOTICE: This heater may be hind it. Noncombustible material must extend used as a vented product. If so, at least 8" up. If noncombustible material is you must always operate log set less than 12", you must install the fireplace hood accessory.
- Page 11 INSTALLATION FLOOR CLEARANCES A. If installing appliance on the floor level, B. If combustible materials are less than 14" you must maintain the minimum distance to the fireplace, you must install appliance of 14" to combustibles (see Figure 8). at least 5" above the combustible flooring (see Figure 9).
- Page 12 INSTALLATION BATTERY INSTRUCTIONS CAUTION: Do not dispose of batteries in fire, batteries may explode or leak. Battery • Battery is included. Positive • Remove battery when depleted. • Be sure to observe proper polarity (+/-) when installing or replacing the batteries. Damage due to improper battery installa- tion may void the warranty on the product.
- Page 13 INSTALLATION CONNECTING TO GAS SUPPLY WARNING: A qualified ser- CAUTION: For natural gas, vice technician must connect check your gas line pressure heater to gas supply. Follow all before connecting heater to gas local codes. line. Gas line pressure must be no greater than 10.5"...
- Page 14 INSTALLATION Typical Inlet Pipe Diameters Install sediment trap in supply line as shown Use 1/2" black iron pipe or greater. Installa- in Figure 14. Place sediment trap where it is tion must include an equipment shutoff valve, within reach for cleaning. Place sediment trap union, and plugged 1/8"...
- Page 15 INSTALLATION CHECKING GAS CONNECTIONS 3. Check all joints from gas meter to equip- WARNING: Test all gas piping ment shutoff valve for natural gas or pro- and connections, internal and pane supply to equipment shutoff valve external to unit, for leaks after for propane (see Figure 17 or 18).
- Page 16 INSTALLATION INSTALLING LOGS See Log Assembly Instructions included with your log set for proper log installation. INSTALLING BATTERIES CAUTION: Do not mix old and new batteries. Do not mix alka- line, standard (carbon - zinc), or Battery Positive rechargeable (nickel - cadmium) batteries.
- Page 17 INSTALLATION INSTALLING REMOTE RECEIVER The remote receiver operates on four AA size 1. Remove battery cover on receiver as batteries (included). Use ALKALINE batteries shown on the box. Install four AA size for longer battery life and maximum micropro- batteries into receiver, (see Figure 20). cessor performance.
-
Page 18: Operation
OPERATION FOR YOUR SAFETY READ BEFORE LIGHTING • Immediately call your gas supplier WARNING: If you do not fol- from a neighbor’s phone. Follow the low these instructions exactly, a gas supplier’s instructions. fire or explosion may result caus- • If you cannot reach your gas supplier, call the fire department. - Page 19 OPERATION 8. Be sure the slide switch on the front of the 11. If heater will not operate, follow the instruc- receiver box is in the ON position. tions To Turn Off Gas To Appliance, and call your service technical or gas supplier. 9.
- Page 20 OPERATION REMOTE CONTROL SYSTEM Programming the Remote and Receiver Key Settings The remote and receiver must be “learned” ON - Operates unit to on position, manually to one another. operated solenoid ON. To prepare the receiver box for learning, use OFF - Operates unit to off position, manually a pen or small screwdriver to gently press operated solenoid OFF.
- Page 21 OPERATION Setting°F/°C Scale 2. Press and hold the SET key until the de- The factory setting for temperature is °F. To sired set temperature is reached. The LCD change this setting to °C, press the ON key screen set numbers will increase from 45° and the OFF key on the remote control at the to 99°...
-
Page 22: Inspecting Burners
INSPECTING BURNERS IMPORTANT: Owner’s should check pilot flame pattern and burner flame pattern often. Incorrect flame patterns indicate the need for cleaning (see Care and Maintenance, page 22) or service. WARNING: Only a qualified service person should service and repair heater. This includes maintenance requiring replacement or alteration of components. -
Page 23: Care And Maintenance
CARE AND MAINTENANCE WARNING: Turn off heater and let cool before servicing. CAUTION: You must keep control areas, burner, and circulating air passageways of heater clean. Inspect these areas of heater before each use. Have heater inspected yearly by a qualified service techni- cian. -
Page 24: Troubleshooting
TROUBLESHOOTING WARNING: If you smell gas: • Shut off gas supply. • Do not try to light any appliance. • Do not touch any electrical switch; do not use any phone in your building. • Immediately call your gas supplier from a neighbor’s phone. Fol- low the gas supplier’s instructions. - Page 25 TROUBLESHOOTING Problem Possible Cause Corrective Action ODS/pilot lights but flame 1. Control knob is not fully 1. Press in control knob fully. goes out when control pressed in. knob is released. 2. Control knob is not pressed 2. After ODS/pilot lights, keep in long enough.
- Page 26 TROUBLESHOOTING Problem Possible Cause Corrective Action Heater produces 1. Heater is burning vapors from 1. Open a window to ventilate unwanted odors. paint, hair spray, glues, etc. room. Stop using odor caus- See IMPORTANT statement, ing products while heater is page 17.
-
Page 27: Replacement Parts
You may feel your gas pressure is too low. If so, contact your local gas supplier. TECHNICAL SERVICE You may have further questions about installation, operation, or troubleshooting. If so, contact Bluegrass Living at 1-866-762-4050. When calling, please have your model and serial numbers of your heater ready. www.bluegrassliving.com... -
Page 28: Parts
PARTS MODELS BC24/30NR AND BC24/30PR This list contains replaceable parts used in your heater. When ordering parts, follow the instructions listed under Replacement Parts on page 26 of this manual. PART # DESCRIPTION ITEM 161338-01 Ignitor 161312-01 Receiver 161334-01 Remote... - Page 29 NOTES ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ www.bluegrassliving.com 200519-01A...
- Page 30 NOTES ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ www.bluegrassliving.com 200519-01A...
- Page 31 NOTES ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ www.bluegrassliving.com 200519-01A...
-
Page 32: Warranty
Bluegrass Living makes no other warranties regarding this product. Bluegrass Living’s liability is limited to the purchase price of the product and Bluegrass Living shall not be liable for any other damages whatsoever under any circumstances including direct, indirect, incidental, or consequential damages.
