Packing List
One of the following sets is included
depending on the purchased reference:
DT10
Wool Filter .... 1 box
Contains 10 filters
Filter Replacement
Be careful when manipulating the
tool. The metal and glass parts
may be hot.
Hold down the tool with one hand onto
the stand (1) and grasp the suction tube
at the point where it meets the suction
tube connector and pull upward (2) to
undock the solder-collector from the
heating element guard.
130 mm
100 mm
80 mm
DT11
60 mm
Metal Filter .... 1 box
Contains 10 filters
50 mm
40 mm
para manuales - color gris
INSTRUCTION MANUAL
DT10 / DT11
Wool Filter / Metal Filter
for DT530
Suction Tube
Connector
Heating Element
Guard
130 mm
Suction
2
Tube
1
Advertisement
Related Manuals for jbc DT10
Summary of Contents for jbc DT10
- Page 1 130 mm 130 mm One of the following sets is included depending on the purchased reference: 100 mm 80 mm DT10 / DT11 DT10 DT11 Wool Filter / Metal Filter 60 mm Wool Filter ..1 box Metal Filter ..1 box...
- Page 2 Suction Tube Detach the suction tube connector from Connector Gaskets the solder-collector by gently pulling both in opposite directions (3). If the solder- collector is too hot, use the heat-resistant gripper provided with the tool. Then remove both gaskets by pulling out as well.
