- Page 1 Pro Installation Guide Version 6 | Last updated 7/7/2023 INSIGHTS...
-
Page 2: Table Of Contents
Sensata INSIGHTS KP2 Pro Installation Guide Please follow along with this guide for details Table of contents on proper device installation and calibration. Pro installation guide ......................Package contents How to test your installation .................... KP2 feature reference How to calibrate your G-sensor ............. -
Page 3: Package Contents
Sensata INSIGHTS KP2 Pro Installation Guide Package contents KP2 vehicle recorder Mounting bracket & attached power cable Removable wedge block (Connects to adapter cables) (Driver-facing camera ordered separately) Torx® wrench 8" 3-wire adapter cable • 64GB microSD card (pre-installed) (Connects to bracket cable) Square adhesive cable clips (x5) •... -
Page 4: Kp2 Feature Reference
Sensata INSIGHTS KP2 Pro Installation Guide KP2 feature reference Front Side Lens angle Camera lock lens Unscrew the right-side bracket. Remove the KP2 from the bracket to adjust camera angle or insert/remove SIM/SD card. Windshield bracket Applied screws for design... - Page 5 Sensata INSIGHTS KP2 Pro Installation Guide KP2 feature reference Side cover open Optional Driver-Facing Camera (Model: KP2-DFC-S) Release tab Nano SIM slot (4FF) MicroSD card slot Memory SD card slot Back Bluetooth pairing & G-sensor E-call/panic button calibration button LED types:...
-
Page 6: How To Install Your Kp2
Prepare your KP2 Disclaimer The KP2 installation featured in this guide is designed for professional installation. Sensata INSIGHTS assumes installers possess knowledge of current, generally accepted industry installation standards and practices. The process outlined in this document accounts for driver positioning on the left side of the vehicle. -
Page 7: Attach Your Camera To The Windshield
How to install your KP2 Attach your camera to the windshield Your vehicle’s windshield temperature shouldn’t be too hot or cold. Sensata INSIGHTS recommends installing your KP2 in moderate temperatures (50°F~80°F). If in severe cold weather, use the vehicle defrosters to warm and dry out the windshield. -
Page 8: Connect The Kp2 To Your Vehicle's Power Source
Connect the KP2 to your vehicle’s power source If you are not a professional technician, click here to request installation from an approved Sensata INSIGHTS installer. By continuing this process without a certified installer, you accept the ramifications of tampering with your vehicle’s power source. -
Page 9: How To Test Your Installation
SIM card. Blue Green – If the light still blinks, this is a configuration or server issue that requires Sensata INSIGHTS support. Green • A blinking light, then there is an SD card error or corruption. Contact your local distributor or Sensata INSIGHTS support to repair or replace your SD card. -
Page 10: How To Calibrate Your G-Sensor
Sensata INSIGHTS KP2 Pro Installation Guide How to calibrate your G-sensor Park your vehicle on a flat surface for calibration. Ensure vehicle remains parked on a flat surface for both G-sensor and device settings calibration. After your camera boots up, press the G-sensor calibration button. This is the small black button to the right of the e-call/panic button. -
Page 11: How To Configure Kp2 Settings
No and contact Tap Show Me How for a brief Tap Next to set your Use the arrows to adjust Tap Next to select your Sensata INSIGHTS support. video walk-through of the vehicle’s “Horizon” and your vehicle’s “Horizon” power connection type. -
Page 12: Complete Your Installation/Support
+1 (312) 981-8774 EMEA +44 (0) 1483 397005 Not an installer? Once you complete the training (about a 30-minute webinar), Sensata INSIGHTS will provide you with login credentials for the SmartOPS portal. To schedule training, please complete the online form here. -
Page 13: Led & Buzzer Specifications
Sensata INSIGHTS KP2 Pro Installation Guide LED & buzzer specifications Warning Record Communication Status/Step Blue Green Sound Booting step 1 Startup & power off Booting step 2 On and off Booting step 3 On and off Booting finished Power off Fast simultaneous on and off Beep no. -
Page 14: Technical Specifications
Sensata INSIGHTS KP2 Pro Installation Guide Technical specifications Mechanical Size 82 mm W x 126 mm H x 64 mm D / 3.2" W x 5.0" H x 2.5" D Weight 232.4 g (Including 2nd Camera, Excluding Power Cable) Image Sensor 2 Megapixel CMOS Sensor Main, Road-Facing Camera (Forward-Facing): 140°... - Page 15 INSIGHTS © 2023 Sensata INSIGHTS. All Rights Reserved.
