Summary of Contents for Sensata INSIGHTS KP2
- Page 1 Please read this entire guide and refer to our installation materials before using your KP2. User Guide Version 3 | Last updated 1/1/2023 sensatainsights.com INSIGHTS...
-
Page 2: Table Of Contents
Table of Contents Please read this entire guide before installation and use. User Guide .............. GPS reception ..............12 Package contents ............Optional accessories Improve your signal ........................Get to know the KP2 Reception may be impaired ....................... Key functions .......... -
Page 3: Package Contents
Package contents KP2 vehicle recorder Mounting bracket & attached power cable Removable wedge block (Connects to adapter cables) (Driver-facing camera ordered separately) Torx® wrench 8” 3-wire adapter cable • 64GB microSD card (pre-installed) (Connects to bracket cable) Square adhesive cable clips (x5) •... -
Page 4: Optional Accessories
The items mentioned below are compatible with the KP2 and offer different benefits or trade-offs when employed with your device. For more details on prices and ordering options, please contact your Sensata INSIGHTS Account Manager or email us at sales.usa@smartwitness.com. -
Page 5: Get To Know The Kp2
Get to know the KP2 Front Side Lens angle Camera lock lens Unscrew the right-side bracket. Remove the KP2 from the bracket to adjust camera angle or insert/remove SIM/SD card. Windshield bracket Applied screws for design purpose only. - Page 6 Get to know the KP2 Side cover open Release tab Nano SIM slot (4FF) MicroSD card slot Memory SD card slot 2nd camera (Model: KP2-DFC) Back Bluetooth pairing button Ecall/panic button LED types: Warning LED (RED) Record LED (BLUE) Network LED (GREEN)
-
Page 7: Key Functions
Key functions Automatic Booting Once you’ve wired your KP2 to the vehicle’s power source, the KP2 will turn on and begin recording after about 30 seconds. 1. Video recording Continuous record This is the default mode for recording. Your KP2 begins recording after booting up and continues to record the entire time the device is on. -
Page 8: Bluetooth Panic Button
® Please get in touch with Sensata INSIGHTS or your supplier to buy a Bluetooth panic button for your KP2. Enable pairing To enable Bluetooth pairing for your panic button, change the following KP2 Configuration Tool settings in Info > Service: •... -
Page 9: Adas Functions
ADAS functions Your KP2’s Advanced Driver Assistance Systems (ADAS) features allow drivers to receive in-cabin preventive audio alerts in cases of potential incidents. Lane Departure Warning Forward Collision Warning Headway Monitoring Warning Your vehicle crosses a solid lane Your vehicle is likely to collide Your vehicle is not maintaining line on either side of the road. -
Page 10: Dsm Functions
DSM functions Your KP2’s Driver State Monitoring (DSM) functions allow drivers to receive audible alerts for driver distraction and fatigue. The following DSM events are configurable in your KP2: Driver Distraction Warning (DDW) Driver Fatigue Warning (DFW) Driver has eyes off the road Driver is yawning and/or has for a prolonged period of time. -
Page 11: Driver Safety Warnings
Driver safety warnings Disclaimer Operational concerns The KP2 is not a substitute for a safe, conscientious In certain conditions, including inclement weather, driver. The KP2 cannot compensate for a driver who is low visibility and precarious road conditions distracted, inattentive or impaired by fatigue, drugs or (including poor lane markings, construction zones, alcohol. -
Page 12: Gps Reception
GPS reception When satellites don’t have line of sight, cellular towers help triangulate a vehicle’s location. Improve your signal Reception may be impaired: 1. Activate your KP2 in an area 1. If there is an object at the end of the GPS antenna. without large buildings. -
Page 13: Led & Buzzer Specifications
LED & buzzer specifications Warning Record Communication Status/Step Blue Green Sound Booting step 1 Startup & power off Booting step 2 On and off Booting step 3 On and off Booting finished Power off Fast simultaneous on and off Beep no. 2 Power off/finished Continuous record Recording... -
Page 14: Technical Specifications
Technical specifications Mechanical Size 126 x 82 x 64 mm Weight 232.4 g (Including 2nd Camera, Excluding Power Cable) Image Sensor 2 Megapixel CMOS Sensor Main, Road-Facing Camera (Forward-Facing): 140° (115°(H), 60°(V)) Angle of View 2nd Camera (Optional, Driver-Facing): 130° (104°(H) x 56°(V)) Electrical Power Input DC 12V/24V, 1.5A... -
Page 15: Installation Resources
If you need to schedule a professional installation service Access KP2 Installation App in the USA for your Sensata INSIGHTS device(s), please visit https://sensatainsights.com/scheduleinstall and submit the online form. -
Page 16: Configuration Tool
Configuration tool KP2 configuration tool The KP2 Configuration Tool allows you to further customize your KP2 device settings. If you wish to make specific calibration changes, please follow this link to download the software and gain access to supplemental documentation. PC requirements Recommended settings for optimal configuration tool compatibility:... -
Page 17: Sd Viewer Software
SD viewer software SD viewer software Sensata INSIGHTS’ SD Viewer Software gives you access to enhanced video playback, editing and review. Please follow this link to download the software and gain access to supplemental documentation. PC requirements Recommended settings for optimal SD Viewer Software compatibility: Windows 7/8/8.1/10 or higher... -
Page 18: Technical Support & Warranty
Sensata INSIGHTS KP2 User Guide Technical support & warranty Technical support For technical support, please contact your local distributor or visit our Support Portal and submit a support ticket. You can also email us at support@smartwitness.com or call our support team:... -
Page 19: Safety Advice & Fcc Regulations
Safety advice & FCC regulations FCC Part 15.19 This device complies with Part 15 of the FCC Rules. Caution To reduce the risk of electric shock, do not remove cover. Operation is subject to the following two conditions: No user-serviceable parts inside. Refer servicing to qualified (1) This device may not cause harmful interference, service personnel. -
Page 20: Kp2 Adas Disclaimer
ADAS functions. This threshold is distinct from other speed thresholds used to configure ADAS events. Please contact your Sensata INSIGHTS integration team to learn about specific values for different event types. Below these thresholds, and in cases where vehicles without vehicle-sourced speed data encounter GPS signal “dead zones”... - Page 21 INSIGHTS © 2023 Sensata INSIGHTS. All Rights Reserved.
