- Page 1 USER GUIDE LANE DEPARTURE WARNING Please read this entire guide before installation and use. Version 2 Last updated 8/12/2022...
-
Page 2: Table Of Contents
................7 LEDs & BUZZER SPECIFICATIONS ..........8 TECHNICAL SPECIFICATIONS ............9 INSTALLATION RESOURCES ............10 MOBILE APPLICATION USER GUIDE ........11–12 TECHNICAL SUPPORT & WARRANTY ........13 SAFETY ADVICE & FCC REGULATIONS ........14 AP1 ADAS DISCLAIMER ..............15 SMARTWITNESS AP1 USER GUIDE... -
Page 3: Package Contents
MicroSD & SIM Card Slot Panic Button Multifunction Button Volume Control Button Status LED (3 EA) Microphone 1.2.3 from the left 5-Pin Micro USB Port Power Specifications Input: OBDII DC 10~32V, 2A Output: DC 5V, 3A SMARTWITNESS AP1 USER GUIDE... -
Page 4: Key Functions
5 seconds (long press), wait 3 seconds and then connect directly to the AP1 via Wi-Fi using your mobile device. 3. VOLUME CONTROL Please press the volume button to control. The volume level is 1 to 5. SMARTWITNESS AP1 USER GUIDE... -
Page 5: Adas Functions
SMARTWITNESS AP1 USER GUIDE... -
Page 6: Driver Safety Warnings
CLEANING ADVISORY While cleaning the device or the vehicle cab, do not apply compressed air or cleaning solutions (such as Windex) to the AP1 device. Usage of these products may cause damage to the device. SMARTWITNESS AP1 USER GUIDE... -
Page 7: Gps Reception
• Inside a building or garage Assisted GPS. • Surrounded by high-rise buildings If GPS signal reception is poor. It may take longer to locate your current position when the vehicle is moving than when it’s stationary. SMARTWITNESS AP1 USER GUIDE... -
Page 8: Leds & Buzzer Specifications
1 Color Is Flashing Wi-Fi Mode (Orange) *Flashing (On and off): 500msec on and 500msec off *Fast flashing (On and off): 100msec on and 100msec off SMARTWITNESS AP1 USER GUIDE *Slow flashing (On and off): 1,000msec on and 1,000msec off... -
Page 9: Technical Specifications
OBDII DC 10V~32V, 2A Output DC 5V, 3A Power Consumption Max. 750mA/12V (9.0W) Size/Weight 122 x 95.5 x 15.5 mm / 212g Operational Temperature -20°C~65°C Warranty Lifetime; Current Customers with an Active Subscription to SmartWitness Web Services SMARTWITNESS AP1 USER GUIDE... -
Page 10: Installation Resources
11. Scan the QR code above to AP1 camera unit for 5 seconds. find and download the app. Release button, and wait 3 seconds for blinking orange light. Download the Calibration Tool Download Watch AP1 Installation Video Quick Start Guide SMARTWITNESS AP1 USER GUIDE... -
Page 11: Mobile Application User Guide
STEP 4 In your settings, tap the AP1 Wi-Fi name (AP1****). The Wi-Fi password is the last 8 digits of your IMEI #, found either on the camera or the box label. SMARTWITNESS AP1 USER GUIDE... - Page 12 Tap OK. You have completed calibration. Your AP1 will reboot and incorporate your new settings. Important: Please ensure you maintain regular updates with your AP1 to ensure it runs on the most recently released firmware. SMARTWITNESS AP1 USER GUIDE...
-
Page 13: Technical Support & Warranty
The warranty excludes products that have been misused (including accidental damage) and damage caused by normal wear and tear. In the unlikely event that you encounter a problem with this product, it should be returned to the place of purchase. SMARTWITNESS AP1 USER GUIDE... -
Page 14: Safety Advice & Fcc Regulations
In the case of an accident, the sensor may not recognize the shock when the impact is light, and as a result, it may not begin recording automatically. SMARTWITNESS AP1 USER GUIDE... -
Page 15: Ap1 Adas Disclaimer
ADAS functions. This threshold is distinct from other speed thresholds used to configure ADAS events. Please contact your SmartWitness | Sensata integration team to learn about specific values for different event types. Below these thresholds, and in cases where vehicles without vehicle-sourced speed data encounter GPS signal “dead zones”... - Page 16 © 2022 SmartWitness. All Rights Reserved. smw3270-7-NA_0822...
