CDP-197
SERVICE MANUAL
AEP Model
UK Model
Model Name Using Similar Mechanism
CDP-791
CD Mechanism Type
CDM14-5BD8A
Optical Pick-Up Block Type
BU-SBD8A
SPECIFICATIONS
Compact disc player
Remote commander
Frequency response
2 Hz to 20 kHz +0.5 dB
Remote control system
Infrared control
Signal-to-noise ratio
More than 110 dB
Power requirements
3 VDC with two R6 (size AA) batteries
Dynamic range
More than 98 dB
Dimensions (approx., including projections)
Harmonic distortion
Less than 0.0027%
62 x 18 x 175 mm (w/h/d)
Channel separation
More than 105 dB
(2 1/2 x 23/32 x 7 inches)
Weight (approx.)
130 g (4.6 02) Including batteries
Outputs
LINE OUT (FIXED) (phono jacks)
Supplied accessories
Output level 2 V (at 50 kilohms)
Audio connecting cord
(1) (2 phono plugs — 2 phono plugs)
Load impedance over10 kilohms
Remote commander
(1)
LINE OUT (VARIABLE) (phono jacks)
Sony SUN-3(NS) batteries
(2)
Output level max. 2 V (at 50 kilohms)
Load impedance over 50 kilohms
DIGITAL OUT (OPTICAL) (optical output connector)
Wave length 660 nm
Output level -18 dBm
PHONES (stereo phone jack)
Output level max. 10 mW
Load impedance 32 ohms
Design and specifications are subject to change without motice.
General
Power requirements
AEP, Germany models:
220 V — 230 V AC, 50/60 Hz
UK model:
240 V AC, 50 Hz
Power consumption
12 W
Dimensions (approx., including projections)
430 x 110 x 295 mm (w/h/d)
(17 x 4 5/16 x 11 5/8 inches)
Weight (approx.)
3.9 kg (Ibs 0z)
COMPACT
DISC
p
YER
—25
SONY.
@
