Product Specification - Positive Grid Spark CAB User Manual

Product Specification
AUDIO SPECIFICATIONS
FREQUENCY RANGE
45-20,000 Hz
STEREO/MONO
MONO
MAXIMUM SOUND PRESSURE LEVEL
117 dB @1m (RMS), 120 dB @1m (Peak)
CABINET PRINCIPLE
Bass Reflex
POWER AMPLIFIERS
140 Watt Class D Amplifier
SPEAKERS
1x10-inch Woofer, 2x1-inch Tweeter
TOTAL IMPEDANCE
4 ohms
POWER
MAIN INPUT POWER
AC 100-240V
DC POWER OUTPUT
DC 19V/2.5A
USB-C POWER OUTPUT
DC 5V/2A
CONTROLS AND CONNECTIVITY
BACK PANEL CONTROLS
Input Selector
Speaker Volume
Line Out Volume
Ground Lift Switch
Contour Switch
WIRED CONNECTIVITY
1 x 1/8" Stereo Input for Spark Amp
2 x Mono XLR/TRS Combo Inputs
1 x Mono XLR Balanced Output
PHYSICAL UNIT
DIMENSIONS
492.5 x 399.8 x 255 mm
(19.39 x 15.74 x 10.04 in)
WEIGHT
13.5 kg
29.76 lb
GRILLE CLOTH
Woven
HANDLE
2 Recessed Speaker Handles
CABLE TIE
1 Adjustable Cable Tie
(for fixing instrument and audio cables on the back)
INCLUDED IN THE BOX
BOX CONTENTS
Spark CAB
Power Cord
3.5 mm Stereo Audio Cable
DC Power Cable
Quick Start Guide
