Troll Standard
EN
Instruction manual for the electrical connection and for commissioning
Item no. 3650 03 12 (ultra white) / 3650 03 22 (aluminium)
Type: 5620
VBD 592-02-R2 (09.23)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Troll Standard 5620 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for RADEMACHER Troll Standard 5620

  • Page 1 Troll Standard Instruction manual for the electrical connection and for commissioning Item no. 3650 03 12 (ultra white) / 3650 03 22 (aluminium) Type: 5620 VBD 592-02-R2 (09.23)
  • Page 2: Table Of Contents

    Contents Contents This manual..................4 13. Manual operation ................33 How to use this manual ..............4 14. Memory function - accepting the current time as switching time ................34 Hazard symbols ................... 5 Levels of danger and signal words..........5 15. Menu overview ..................35 Symbols and depictions used............6 16.
  • Page 3: This Manual

    1. This manual... 2. Hazard symbols ...describes how to install, connect the electrical system and operate The following hazard symbols are used in this manual: the Troll Standard. Danger of fatal electric shock 1.1 How to use this manual Danger area / dangerous situation Before you begin, please read this manual through completely and ‹...
  • Page 4: Symbols And Depictions Used

    2.2 Symbols and depictions used 3. Safety instructions There is a risk of fatal electric shock when touching electrical Other useful components. information The electrical connection and all work on electrical systems must ‹ Please read the respective only be carried out by a qualified electrician in accordance with the manual connection instructions in these operating instructions.
  • Page 5: Intended Use

    3.1 Intended use 4. Included in delivery Use the Troll Standard only for connecting and controlling a tubular motor for roller shutters, Venetian blinds, slats or awnings. Operating conditions The tubular motor must be fitted with a mechanical or electronic ‹...
  • Page 6: General View Of The Operating Unit

    5. General view of the operating unit General view of the operating unit Pos. Symbol Description OK button Open the selected menu ‹ Confirm and save settings ‹ Continue to the next setting ‹ Operating buttons Up / Down Manual operation ‹...
  • Page 7: General View Of The Installation Housing

    5.1 General view of the installation housing 5.2 Electrical connections Pos. Symbol Description Pos. Symbol Description E1 / E2 External inputs - optional Installation housing Connect external signal transmitters or external controllers (e.g. Troll Comfort), see page 26. Claw fasteners and screws L / N Power supply - 230 V / 50 Hz Connecting terminals...
  • Page 8: Display And Its Symbols

    5.3 Display and its symbols 6. Product description The Troll Standard controller is designed for controlling roller shut- ters, Venetian blinds, slats or awnings by connecting a corresponding tubular motor. Roller shutter control The device enables the roller shutter to be automated. Manual operation Symbol Description...
  • Page 9: Description Of The Safety Functions

    6.1 Description of the safety functions Overview of functions Blockage detection Memory function (easy acceptance of the current time as switching ‹ time) The Troll Standard is able to monitor the torque of motors equipped with Switch reversal of rotation direction on/off ‹...
  • Page 10: Technical Specifications

    7. Technical specifications Technical specifications Mains supply [ L / N ] General information Mains supply External dimensions (W x H x D) 50 x 50 x 12 mm 230 V / 50 Hz Operating unit [ 1 ]: according to DIN 49075 voltage: Ultra-white (UW), Consumption:...
  • Page 11: Werkseinstellungen

    7.1 Werkseinstellungen 7.2 Conduct in the event of a power failure Power reserve (approx. 8 hours) Factory settings The current time flashes for approx. 5 minutes in the event of a power Automatic mode: failure and the Troll Standard changes to power reserve. Switching times: Time and date after a power failure The power reserve is approx.
  • Page 12: Safety Instructions For The Electrical Connection

    (when using E1/E2). Only use the installation housing provided to connect and install ‹ the Troll Standard. Installation housings of other RADEMACHER products, such as ‹ other Troll controllers, are not compatible. DANGER! WARNING!
  • Page 13: Important Information Prior To The Electrical

    58 mm flush-mounted box or in an electronic socket. A maximum of 3 tubular motors can be connected in parallel to the Troll Standard (e.g. RADEMACHER electronic tubular motors). Stripping length 6 mm In order to do so, follow the information in the instruction All leads must be stripped to 6 mm.
  • Page 14: Installation After The Electrical Connection

    Place the frame onto the installation housing. * The white set lead (SET) from RADEMACHER tubular motors must be Then carefully insert the operating unit into the installation housing . connected to the neutral terminal [ N ] to ensure trouble-free opera- tion of the tubular motor..
  • Page 15: Brief Description Of The Standard Display And Main Menu

    10. Brief description of the standard display and 11. Introduction to opening the menus and main menu setting the functions The standard display (example) Open the main menu. Pressing the menu button on the standard Displays the current day of the week and time. ‹...
  • Page 16: Initial Commissioning With The Help Of The Installation Wizard

    11. Introduction to opening the menus and 12. Initial commissioning with the help of the setting the functions installation wizard The installation wizard, which guides you through the first basic settings, is Each setting must be confirmed with the automatically started for the initial commissioning or after a software reset. OK button.
  • Page 17: Manual Operation

    12. Initial commissioning with the help of the 13. Manual operation installation wizard Manual operation is possible from the standard display at any time and Set and confirm the closing time [ ]. has priority over the programmed automatic functions. Pre-setting: MO...SU (MON...SUN) * Example for manual control of a roller shutter * The opening time and the closing time...
  • Page 18: Memory Function - Accepting The Current Time

    14. Memory function - accepting the current time 15. Menu overview as switching time The memory function enables you to easily adapt the switching times Main menu during the course of the year by allowing the current time to be accepted as the switching time, without having to access the switching time menu.
  • Page 19: Switching Times (Opening And Closing Times) [ / ], Brief Description

    17. Switching times (opening and closing times) [ / ], AUTO 16. Menu 1 - Switching automatic mode on/off brief description Automatic mode on (symbol on the standard display) You can configure various opening [ ] and closing times [ ] for the Troll Standard in order to open or close your roller shutter automatically All set automatic functions are active ‹...
  • Page 20: Menu 2 - Configuring Opening And Closing Times [ / ]

    17.1 Menu 2 - Configuring opening and closing 17.1 Menu 2 - Configuring opening and closing times [ / ] times [ / ] If the type of switching time programme (weekly switching times, The following serves to describe the procedure for setting an opening and working day / weekend switching times) is not to be changed, start closing time [ / ] as weekly switching times.
  • Page 21: Menu 6 - Configuring The Random Function

    18. Menu 6 - Configuring the random function 19. Menu 9 - System settings The random function enables a random delay of the set timer periods This menu enables you to configure additional devices and system settings ranging between 0 and 30 minutes. to customise your Troll Standard to your individual preferences.
  • Page 22: Menu 9.1 - Setting The Time And Date

    19.2 Menu 9.5 - Configuring the switching time 19.1 Menu 9.1 - Setting the time and date programme The number of opening and closing times that can be configured de- Open menu 9.1. pends on the desired switching time programme selected in this menu. Configure and confirm the desired settings.
  • Page 23: Menu 9.6 - Configuring The Blockage Detection

    19.3 Menu 9.6 - Configuring the blockage detection 19.3 Menu 9.6 - Configuring the blockage detection Ø The Troll Standard is able to monitor the torque of motors equipped Motor types | Power with a mechanical end point setting. This enables the controller to 1 06 | 35 mm | 6 Nm...
  • Page 24: Menu 9.8 - Device Settings

    19.3 Menu 9.6 - Configuring the blockage detection 20. Menu 9.8 - Device settings Automatic reversing function in the event of a blockage Menu 9.8 - Device Settings In the event of a blockage, the motor immediately runs in the opposite direction for approx.
  • Page 25: Menu 9.8.1 - Switching The Automatic Summer/Winter Time On/Off

    20.1 Menu 9.8.1 - Switching the automatic 20.2 Menu 9.8.2 - Setting the display contrast summer/winter time on/off The Troll Standard features an automatic summer/winter changeover Open menu 9.8.2. function. Summer time The timer is changed to summer time on the last Sunday in March. The Set and confirm the desired contrast.
  • Page 26: Menu 9.8.5 - Switching The Button Lock On / Off

    20.5 Menu 9.8.7 - Switching the reversal of rotation 20.4 Menu 9.8.5 - Switching the button lock on / off direction on/off You can activate the automatic button lock to protect against any unin- It is not necessary to re-wire the motor if the direction of rotation of tentional input.
  • Page 27: Menu 9.8.0 - Displaying The Software Version

    20.6 Menu 9.8.0 - Displaying the software version 21. Deleting all settings, software reset This menu enables the current Troll Standard software version to be A software reset can be performed to reset the Troll Standard to the displayed. original default condition as when supplied. Open menu 9.8.0.
  • Page 28: Performing A Hardware Reset

    Internal device error highlighting that the Troll Standard may be defective. To do so, pull the operating unit out of the installation housing. Please then contact RADEMACHER Service. ‹ The centre section on the rear 24. Dismantling...
  • Page 29: Simplified Eu Declaration Of Conformity

    25. Simplified EU declaration of conformity DELTA DORE RADEMACHER GmbH,hereby declares that the Troll Standard complies with the Directives 2014/35/EU (Low-voltage direcive) and 2014/30/EU (EMC directive). The full text of the declaration of conformity is available at the following website: www.rademacher.de/ce...
  • Page 31 DELTA DORE RADEMACHER GmbH Buschkamp 7 46414 Rhede - GERMANY...
