3.2 • Mounting of the head box
3.3 • Closing the side guiding channel
1
Slide the fabric into the HPVC inner rail
Be sure to observe the correct direction of the inner
rails!
Make sure the V cut-out is positioned at the top of the
side guiding channel and the clicker is positioned at the
bottom of the side guiding channel.
3
Insert the inner rail back into the side guiding channel.
4
16
Go
Place the head box on the fixed profile
guiding channel.
After placing the head box on the fixed profile
the side guiding channel, make sure it is straight using
the spirit level before proceeding.
Put the removable profile
of the side guiding channel
into place and screw it
down.
Check that the fabric slides
freely into the inner rail
without any tension.
TIP
.
➁
➂
➁
of the side
➀
of
➀
2
Respect the position of the
side guiding channel. The
(black) clicker is at the
➃
bottom of the side guiding
channel.
