EN Fixscreen
®
3 • Installation
3.1 • Mounting of the side guiding channels
1
➃
➄
Side guiding channel S
• Demount the 2-part side guiding channel.
• Use a torx key T20 for unscrewing the removable profile
channel.
• The base plate of the side guiding channel
guiding channel prevent the H-PVC inner rail
14
Go
If the power is supplied from inside the house, you will
have to drill a 10 mm opening in the wall to provide a
RB
passage for the power cable of the motor to go indoors,
depending on the type of cable feed (B, K).
In the case of a cable feed type 'K', you can have the cable
run inside the side guiding channel. The cable is thus led
downward aesthetically so that the connection with the
power supply can be made inside the house.
RK
➀
➁
➂
Fixed profile
➀
Inner rail
➁
Removable profile
➂
Clicker
➃
Base plate side guiding
➄
channel
of the side guiding
➂
and clicker at the base of the side
➄ ➃
from sliding down.
➁
