Before You Begin

This Quick Installation Guide gives step-by-step instructions for setting up the D-Link

DES-1005D 10/100M Fast Ethernet Switch. The model you have purchased may

appear slightly different from those shown in the illustrations. For more detailed

information about the switch, its components, making network connections and

technical specifications, please refer to the User's Guide included you're your switch.

Check Your Package Contents

These are the items included with your DES-1005D purchase:

If any of the above items are missing, please contact your reseller.

respective holders. Software and specifications subject to change without notice.

• DES-1005D 10/100M Fast Ethernet Switch

• User Manual

• Quick Installation Guide

• DC Power Adapter

DES-1005D

10/100M Fast Ethernet Switch

Using a power

supply with a

different voltage rating

will damage and void

the warranty for this

product.

Table of Contents

Page 1: Before You Begin
These are the items included with your DES-1005D purchase: If any of the above items are missing, please contact your reseller. ©2003,2005 D-Link Systems, Inc. All rights reserved. Trademarks or registered trademarks are the property of their respective holders. Software and specifications subject to change without notice.
Page 2: Physical Installation
Unpacking Please make sure the following items are present and undamaged. Physical Installation Putting the Rubber Feet For desktop installation, please take time now to attach the included rubber feet to the base of the switch. 1.The switch 2.AC Power Adapter 3.Rubber Feet 4.Screws and Anchors...
Page 3 Mounting Switch on Wall The DES-1005D can be mounted on a wall. Two mounting slots are provided on the bottom side of the hub for this purpose. Make sure that the front panel is exposed to allow you to view the LEDs while the unit is on.
Page 4: Additional Information
100Mbps speed or light amber for hookup to 10Mbps speed. Hub to DES-1005D hub (10 or 100BASE-TX) can be connected to the DES-1005D via a two-pair Category 3, 4, 5 UTP/STP straight cables. For 100Mbps operation a Category 5 cable must be used. The connection is accomplished from any port of the hub to any port of the switch.
