- Page 1 Pack 12: The Matrix of Leadership B U I L D I N S T R U C T I O N S TRANSFORMERS and HASBRO and all related trademarks and logos are trademarks of Hasbro, Inc. ©2023 Hasbro.
- Page 2 Advice from the experts Please keep ALL unused screws as they may be required in a later stage. Please make sure you don’t mix up the screws. They look quite similar, but the threads do vary slightly. Using the wrong screws may damage the parts. When securing parts together using multiple screws, fit each screw loosely to ensure all the parts are correctly aligned before gently tightening them firmly, but not overtight, in the order in which you placed them.
- Page 3 Pack 11 Parts for the Matrix T R A Y 3 TR-11-71 TR-11-68 TR-11-70 TR-11-59 TR-11-62 TR-11-58 TR-11-69 TR-11-52 TR-11-53 TR-11-63 TR-11-57 TR-11-56 TR-11-65 TR-11-66 TR-11-64 TR-11-60 TR-11-72 TR-11-67 TR-11-73 TR-11-54 TR-11-61 TR-11-74 AGORAMODELS OPTIMUS PRIME...
- Page 4 Pack 12 Parts for the Matrix T R A Y 2 : S c r e w s a n d F i x i n g s PB 2.3x8mm x3 M 3x10mm x7 PWB 2x6mm x3 TR-12-169 PB 2.3x6mm x95 TR-12-161 x18 nut 3 (TR-12-162) TR-12-168...
- Page 5 Pack 12 Parts for the Matrix TR-12-31 T R A Y 4 TR-12-07 TR-12-08 TR-12-30 TR-12-27 TR-12-26 TR-12-97 TR-12-39 TR-12-83 TR-12-63 TR-12-10 TR-12-96 TR-12-78 TR-12-27 TR-12-29 TR-12-134 TR-12-82 TR-12-137 TR-12-26 TR-12-11 TR-12-164 TR-12-142 TR-12-79 TR-12-170 TR-12-141 TR-12-61 TR-12-80 TR-12-135 TR-12-62 TR-12-38 TR-12-28 TR-12-09...
- Page 6 Assembling the Matrix S T E P 1 TR-12-142 Plug TR-12-141 into circuit board TR-12-142. TR-12-141 S T E P 2 Attach the assembly ‘A’ to TR-12-24. TR-12-24 S T E P 3 Your assembly now loooks like this. S T E P 4 Attach TR-12-30 to assembly B as shown...
- Page 7 Assembling the Matrix S T E P 5 ... then secure it by inserting TR-12-149. TR-12-149 S T E P 6 TR-12-31 (“2”) Attach TR-12-31 in the same way... S T E P 7 ... and secure it using TR-12-149. TR-12-149 S T E P 8 TR-12-25...
- Page 8 Assembling the Matrix S T E P 9 PB 2x6 Secure it using 3x PB 2x6 mm screws. S T E P 1 0 Install 3x batteries type AG7/LR57. Battery AG7/LR57 S T E P 1 1 PB 2x6 Attach TR-12-38 to assembly A, then secure using 2x PB 2x6 mm TR-12-38...
- Page 9 Assembling the Matrix S T E P 1 3 TR-12-28 Apply glue to TR-12-28 then fix in place. S T E P 1 4 TR-12-170 Applly glue to TR-12-39 then attach 3x TR-12-170. TR-12-39 S T E P 1 5 Fit assembly B to assembly C.
- Page 10 Assembling the Matrix S T E P 1 7 Apply glue to assembly TR-12-168 A as shown then fit 3x TR-12-168. S T E P 1 8 Glue TR-12-39 then fit 3x TR-12-170 TR-12-170. TR-12-39 S T E P 1 9 Attach assembly B to assembly C.
- Page 11 Assembling the Matrix S T E P 2 1 Fit TR-12-26 to assembly A. TR-12-26 S T E P 2 2 TR-12-96 Glue TR-12-96 and fit to assembly B. S T E P 2 3 TR-12-97 Glue TR-12-97 and fit to assembly C.
- Page 12 Assembling the Matrix S T E P 2 5 TR-12-26 Fit TR-12-26 to assembly A. S T E P 2 6 TR-12-96 Glue TR-12-96 and fit to assembly B. S T E P 2 7 TR-12-97 Glue TR-12-97 and fit to assembly C.
- Page 13 Assembling the Matrix S T E P 2 9 Glue TR-11-58 as shown TR-11-58 and fit on top of TR-11-59. S T E P 3 0 PB 2.3x6 Fit TR-11-57 to assembly B and secure with 2x PB 2.3x6 mm screws. TR-11-57 S T E P 3 1 Glue TR-11-56 and fit on...
- Page 14 Assembling the Matrix M A T R I X O F L E A D E R S H I P C O M P L E T E The Matrix of Leadership is an artifact of great power that can be stretched when held aloft..
