Acer AOPEN 27E1 bi Quick Start Manual

AC Adapter
1. Take out the machine and accessories from the carton, and put the machine on the smooth cushion. Then take out the bracket
and base for assembly, and put the bracket into the base.
2. Push the assembled stand arm along the slot to install it on the monitor.
3. The installation is complete.
1. Power off the monitor and unplug the power source of the PC.
2. Connect the signal cable:
a. Make sure the monitor and PC are powered off;
b. Connect the signal cable to the PC.
3. Connect one end of the power adapter into the DC port of the monitor.
4. Connect the power adapter of the PC and the monitor into a power outlet nearby.
Overview of monitor IN ports
1 HDMI port
2 VGA port
3 DC port
Notice: Specific interfaces and signal
lines are based on actual conditions.
No. Icon Item
1 Mode/Exit
/
Brightness/
2
/
Enter
3 Input/+
/
4 Menu/-
/
5 POWER Power button
2 3
1 4
5
Description
a. Press to view Main page. Press again to enter mode select function.
b. When the Function Menu is active. Press to return previous Menu or exit current Menu.
a. Press to view Main page. Press again to enter brightness adjustment function.
b. When the Function Menu is active, this button will enter a selection in the OSD.
a. Press to view Main page. Press again to enter Input select function.
b. When the Function Menu is active, press this button selected or move to the previous function.
a. Press to view Main page. Press again to enter next function in the Function Menu.
b. When the Function Menu is active, press this key selected or move to the next function.
Power on/off the monitor. It indicates power on if the light remains on. It indicates
stand-by/power-saving mode if the light flashes.
VGA cable
LED Indicator
E0 Series
20E0Q
User Manual
HDMI VGA DC
