TABLE OF CONTENTS
Special notes on LCD monitors .................................................. 1
Information for your safety and comfort .................................. 2
Unpacking ................................................................................... 5
Attaching/Removing the base .................................................... 6
Screen position adjustment ........................................................ 6
Connecting the power cord ....................................................... 7
Safety precaution ....................................................................... 7
Cleaning your monitor ............................................................... 7
Power saving ............................................................................... 8
DDC .............................................................................................. 8
Connector Pin Assignment ......................................................... 9
Standard Timing Table..................................................................11
Installation.....................................................................................
User controls..................................................................................
Troubleshooting............................................................................
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Acer Maestro 195DXL
Summary of Contents for Acer Maestro 195DXL
-
Page 1: Table Of Contents
TABLE OF CONTENTS Special notes on LCD monitors ..........1 Information for your safety and comfort ........2 Unpacking ................... 5 Attaching/Removing the base ............ 6 Screen position adjustment ............6 Connecting the power cord ............7 Safety precaution ............... 7 Cleaning your monitor ............... -
Page 2: Special Notes On Lcd Monitors
SPECIAL NOTES ON LCD MONITORS The following symptoms are normal with LCD monitor and do not indicate a problem. NOTES · Due to the nature of the fluorescent light, the screen may flicker during initial use. Turn off the Power Switch and then turn it on again to make sure the flicker disappears. -
Page 3: Information For Your Safety And Comfort
Information for your safety and comfort Safety instructions Read these instructions carefully. Keep this document for future reference. Follow all warnings and instructions marked on the product. CAUTION for accessibility Be sure that the power outlet you plug the power cord into is easily accessible and located as close to the equipment operator as possible. - Page 4 Product servicing Do not attempt to service this product yourself, as opening or removing covers may expose you to dangerous voltage points or other risks. Refer all servicing to qualified service personnel. Unplug this product from the wall outlet and refer servicing to qualified service person- nel when: •...
- Page 5 Warning! We do not recommend using the product on a couch or bed. If this is unavoidable, work for only short periods, take breaks regularly, and do some stretching exercises. ----------------------------------------------------------------------------------------------------- For more information and help in recycling, please visit the following websites: Worldwide: http://www.acer-group.com/public/Sustainability/sustainability01.htm http://www.acer-group.com/public/Sustainability/sustainability04.htm EN-4...
-
Page 6: Unpacking
UNPACKING Please check the following items are present when you unpack the box, and save the packing materials in case you will need to ship or transport the monitor in future. AC Power Cord LCD Monitor AC Adapter ·... -
Page 7: Attaching/Removing The Base
Attaching/Removing the Base -------------------------------------------------------------------- Note: Remove the monitor and monitor base from its packaging. Carefully place the monitor face-down on a stable surface -- use a cloth to avoid scratching the screen. Attaching the Base Removing the Base Maestro195DXL Maestro 205DL/ Maestro225DXL /Maestro235DL SCREEN POSITION ADJUSTMENT In oder to optimize the best viewing position, you can adjust the tilt of... -
Page 8: Connecting The Power Cord
CONNECTING THE POWER CORD · Check first to make sure that the power cord you use is the correct type required for your area. · This monitor has a universal power supply that allows operation in either 100/120V AC or 220/240 V AC voltage area. No user-adjustment is required. ·... -
Page 9: Power Saving
Power saving The monitor will be driven into Power Savin mode by the control signal power LED. from the display controller, as indicated by the blinking white State Light White Power Saving Blinking White Mode The power saving states will be kept until a control signal has been detected or the keyboard or mouse is activated. -
Page 10: Connector Pin Assignment
CONNECTOR PIN ASSIGNMENT 15-Pin Color Display Signal Cable PIN NO. DESCRIPTION PIN NO. DESCRIPTION Green Logic Ground Blue Monitor Ground Monitor Ground DDC-Serial Data DDC-return H-Sync R-Ground V-Sync G-Ground DDC-Serial Clock B-Ground 19-pin Color Display Signal Cable* PIN No. Description PIN No. - Page 11 24-Pin Color Display Signal Cable* Meaning Meaning TMDS Data2- TMDS Data2+ +5V Power TMDS Data 2/4 Shield Logic Ground Hot Plug Detect TMDS Data0- DDC Clock TMDS Data0+ DDC Data TMDS Data 0/5 Shield TMDS Data1- TMDS Data1+ TMDS Clock Shield TMDS Data 1/3 Shield TMDS Clock+ DDC TMDS Clock-...
-
Page 12: Standard Timing Table
Standard Timing Table Maestro195DXL/ Maestro 205DL ... - Page 13 Standard Timing Table Maestro225DXL /Maestro235DL...
-
Page 14: Installation
INSTALLATION To install the monitor to your host system, please follow the steps as given below: Steps 1. 1-1 Connect Video Cable a. Make sure both the monitor and computer are powered-OFF. b. Connect the VGA video cable to the computer. Connect the digital cable (only for dual-input models). -
Page 15: User Controls
USER CONTROLS Power Switch / Power LED: To turn the monitor ON or OFF. Lights up to indicate the power is turned ON. Using the Shortcut Menu Press the function button to open the shortcut menu. The shortcut menu lets you quickly select the most commonly accessed settings. - Page 16 Acer eColor Management Operation instructions Step 1: Press “ “ Key to open the eColor Management OSD and access the scenario modes Step 2: Press “ “ or “ ” to select the mode Step 3: Press “ AUTO “ Key to confirm the mode and exit the eColor menu.
- Page 17 Adjusting the OSD settings -------------------------------------------------------------------- Note: The following content is for general reference only. Actual product specifications may vary. The OSD can be used for adjusting the settings of your LCD Monitor. Press the MENU key to open the OSD. You can use the OSD to adjust the picture quality, OSD position and general settings.
- Page 18 Adjusting the OSD position 1 Press the MENU key to bring up the OSD. 2 Using the directional keys, select OSD from the on screen display. Then navigate to the feature you wish to adjust.
- Page 19 Adjusting the setting 1 Press the MENU key to bring up the OSD. 2 Using the keys, select Setting from the OSD. Then navigate to the feature you wish to adjust. 3 The Setting menu can be used to adjust the screen Menu Language and other important settings.
- Page 20 Product information 1 Press the MENU key to bring up the OSD. 2 Using the keys, select Information from the OSD. Then the basic information of LCD monitor will show up for current input.
-
Page 21: Troubleshooting
TROUBLESHOOTING Before sending your LCD monitor for servicing, please check the trouble- shooting list below to see if you can self-diagnose the problem. (VGA Mode) Problems Current Status Remedy LED ON · Using OSD, adjust brightness and contrast to maximum or reset to their default settings. - Page 22 DVI mode Problems Current Status Remedy LED ON · Using OSD, adjust brightness and contrast to maximum or reset to their default settings. LED OFF · Check the power switch. · Check if AC power cord is properly No Picture connected to the monitor.
- Page 23 New Taipei City 221, Taiwan Declaration of Conformity Acer Incorporated 8F, 88, Sec. 1, Xintai 5th Rd., Xizhi, New Taipei City 221, Taiwan Contact Person: Mr. RU Jan, e-mail:ru.jan@acer.com And, Acer Italy s.r.l Via Lepetit, 40, 20020 Lainate (MI) Italy Tel: +39-02-939-921 ,Fax: +39-02 9399-2913 www.acer.it...
