Summary of Contents for Gotrax F1V2

  • Page 1 F1V2...
  • Page 2: Table Of Contents

    Contents Don't Ride Until You Read This ........... 02 Warning Message ................. 03 Unpacking and Product Specs ............ 07 Get to Know Your E-Bike ............. 08 Front Wheel Installation Procedure ........... 09 Installation of headlights and taillights ........10 Handle Bar Installation and Folding .......... 11 Bike Frame Folding and Unfolding ..........
  • Page 3 bicycle TOOLS INCLUDED:3mm、4mm、5mm、 6mm Allen wrech, 8mm&10mm、 13mm&15mm open-end wrench,Flat Head & Phillips dual-purpose Screwdrive.
  • Page 4: Don't Ride Until You Read This

    WARNING: Lithium-ion Batteries and/or products that contain Lithium-ion Batteries can expose you to chemicals including cobalt lithium nickel oxide, and nickel, which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information, go to www.P65Warnings.ca.gov...
  • Page 9: Unpacking And Product Specs

    TOOLS: (2)LARGE WRENCH, Seat Bag (4)ALLEN WRENCHES, (1)SCREWDRIVER Rearview Mirror Folding Lock Phone Holder Pedals F1V2 1380*250*600mm(54.3*9.8*23.6in) 40miles (65km) 22miles (35km) 35 PSI...
  • Page 10: Get To Know Your E-Bike

    Phone Holder Rearview Mirror Seat Bag...
  • Page 11: Front Wheel Installation Procedure

    Front Wheel Installation Procedure 1.Remove packing block from disc 2.Loosen the front axle screws (it brake caliper – Do Not Throw Away doesn't need to be totally loose, just – Re-install Packing Block whenever to a suitable position for installa- you remove your front wheel.
  • Page 12: Installation Of Headlights And Taillights

    Installation of headlights and taillights Attach the front headlight bracket to the front headlight mounting hole, align it with the corresponding installation hole on the bracket, insert a screw, and on the other end, fasten it with a nut. Tighten the front headlight securing screw with a 5mm hex key on one end and a 10mm open-end wrench on the other end.
  • Page 18: Accessory Installation Procedure

    Accessory Installation Procedure Installation instructions for the rearview mirror, seat bag, and phone holder please follow the below notes 1.Install the seat bag: align the guide groove on the seat bag at the lower seat and hanger, advance and tighten. 2.Install the rearview mirror, insert the 3.Install the phone holder: put the rearview mirror into the handlebar end...
  • Page 27: Function Definition

    Headlight Icon Battery level display Fault Indication Speed Unit Display Real-time Speed Power Assist Push Icon Gear Display Single Trip Mileage Total Travel Distance Maximum Speed Range and Unit Display Average Speed Plus Button Minus Button Confirm "i" Button Power On/Off Button Headlight Button...
  • Page 28 Power On/Off: Press and hold the button for 2-3 seconds to activate the display and press the button again for 2-3 seconds to turn off the display (the bike will automatically power off , if there is no activity for 10 minutes in a stationary state). Display Data Switching: After the display panel is powered on, it defaults to display- ing real-time, speed and total mileages.
  • Page 29 Only when the fault is resolved can you exit the fault display screen. After a fault occurs, the electric bike will not be able to continue to operate. Please contact the GOTRAX after-sales team for assistance or seek the help of a professional technician to diagnose and rectify the issue.
  • Page 30 Metric/Imperial Unit Setting: "01P" is the option for selecting metric or imperial units. "00" represents metric and "01" represents imperial Use the button to make the selection, and press the button shortly to save the parameter setting and return to the personalized parameter selection interface. Voltage Setting: "02P"...
  • Page 31 Speed Limit Setting: "05p" is the option for setting the speed limit in power assist mode, and the adjustable range for the vehicle speed limit is 10 to 40 km/h. The factory default is 32 km/h, and the maximum limit is 40 km/h. This mode allows you to adjust the speed limit only for power assist mode, as the electric mode has a maximum limit of 32 km/h, which is not adjustable.
  • Page 32 To change the password: In the "06P" interface, press the button shortly to enter the parameter change mode.Use the button to select "PSd-y" to enable password change.Press button to confirm and enter the four-digit password setting mode.In the password setting interface, input your new password. Use the button to select the digits and press the button to save each digit and move to the next.
  • Page 36: Troubleshooting Guidance

    Check the motor connection cable. If the connection cable is The motor current failure ERROR 21 normal, replace the a new motor. Check the throttle connection The throttle abnormal cable. If the connection cable is ERROR 22 normal, replace the throttle. Please check the motor connec- tion cable at firstly.
  • Page 39 (US) W W W .G OT R A X . C O M ( C A ) w w w . g o t r a x c a n a d a . c o m...
  • Page 40 (US)GOLABS,INC GOTRAX.com 2201 Luna Rd. Carrollton,TX 75006 (CA)Tao Motor Canada Inc. 170 Bartor Road, Unit 1 North York, Ontario M9M 2W6, Canada.
