Sony TA-P9000ES - Amplifier Dimensions

TAP-9000ES
RMP-9000 REMOTE COMMANDER
IR
SENSOR
1/2" 2 "
1 1/4 "
INPUT 1
FRONT
L
R

NOTE:

WHERE THERE ARE CLOSE TOLERANCES INVOLVED IN CABINET BUILDING
OR APPLICATIONS WHICH REQUIRE A GREAT DEGREE OF PRECISION
RECOMMEND THAT THE PRODUCT ITSELF BE USED TO MAKE THE ACTUAL
MEASUREMENTS. SONY WILL NOT BE RESPONSIBLE FOR INACCURACIES IN
THE DESIGN OR MANUFACTURE OF ENCLOSURES .
Consumer Integrated Systems • Park Ridge, New Jersey 07656 • FAX (201) 930 7891 • b2b.sel.sony.com
Features and specifications subject to change without notice. • Non-metric weights and measurements are approximate.

DESCRIPTION:

DIMENSIONS
(WHD):

WEIGHT:

FRONT VIEW

SIDE VIEW

2 "

BACK VIEW

INPUT 2 BYPASS 5.2 CH
REAR CENTER FRONT REAR CENTER FRONT REAR CENTER
L L
R R
WOOFER WOOFER WOOFER
Multi Channel
Pre Amplifier
17" x 4 7/8" x 15 1/4 "
Approx 22 lbs
17"
12 "
15 1/4"
8 3/8 " 2 "
BYPASS 2CH PRE OUT
FRONT REAR CENTER
L L
CTRL A1
TO POWER AMP
R R
WOOFER
POWER
REQUIREMENTS: 120VAC
POWER
CONSUMPTION:
20
Watts
4 7/8"
4 1/4"
ES
2 " 1/2"
5/8"
1/2 "
AC
WE
D
N
60Hz
