3-3.
HDMI RE BOARD
connector
(CN3509)
3-4.
FRONT PANEL BLOCK
front panel block
three screws
(BVTP3
three screws
(BVTP3
HDMI RE board
HDMI left bracket
wire (flat type) (17 core)
(CNS510)
claw
two claws
8)
three claws
wire (flat type) (17 core)
(HDMI RE BOARD (CN3511),
MAIN BOARD (CNS506))
8)
two screws
(BVTP3
screw
(BVTP3
claw
STR-KS2000
8)
four screws
(BVTT3
6)
connector
(CNS510)
saranet cushion
8)
7
