Teletype 38 Adjustments

TELETYPE CORPORATION
Skokie, Illinois, U.S.A.
SECTION 574-426-70<YrC
I~ue 1, May 1972
38 COVER AND TABLE
ASR
ADJUSTMENTS
CONTENTS
1. GENERAL ...
2. BASIC UNIT
Cover ...
Front cover
Front door
Keyboard . . ....
Local return . . . . . .
Paper advance . . . . . . .
Reader to cabinet
Rear door .
Window
Table ..
Left door latch
Right door ...
Right door latch
1. GENERAL
PAGE
1
2
2
5
4
2
6
6
3
4
5
7
8
7
7
1.01 This section is issued to provide adjust-
m ent information for the Model 38
cover and table. The requirements apply
to
Automatic Send-Receive (ASR) Sets only (see
figure).
1.02 After completing adjustments, place
covers in their operating positions and
replace any parts that were removed. All adjust-
ment clearances are in inches and all spring
tensions are in ounces unless otherwise specified.
1.03 In the adjustments covered in this
section, location of clearances and posi-
tion of parts are illustrated by line drawings.
Requirements and procedures are set forth.in the
texts that accompany the line drawings.
1.04 References to left, right, front, or rear
are to be considered as viewed from the
wise, loosen screws or nuts friction tight while
making an adjustment, then tighten after adjust-
ment is made.
1.05 Special tools to perform adjustments
are found in 185830 maintenance tool
kit and are listed in Section 570-005-800TC.
Check Section 574-426-702TC for approved dis-
assembly and reassembly procedure of cover and
parts.
NOTE: When a stop position is called for, the
clutch shoe lever contacts a trip lever.
CA UT/ON: DISCONNECT POWER FROM
SET BEFORE MAKING ANY ADJUSTMENTS.
normal operating position. Unless stated other- 38 ASR Set and Table
©
1972 by Teletype Corporation
All rights reserved
Printed in U.S.A. Page 1
