- Page 1 User Guide MS-63U1A USB-A Extender Set - up to 100m. USB 3.2 Gen1 PoC, RS-232 pass through Revision: 1.0 - April 2024...
- Page 2 MS-63U1A USER GUIDE Contents Introduction Key Features Connectivity Overview (Host and Device) Understanding the LED’s Cabling for Extenders RS-232 Control & Power Specifications & Package Contents Schematic Notices • This MSolutions product contains electrical components that may be damaged by electrical spikes, surges, electric shock, lightning strikes, etc.
- Page 3 MS-63U1A USER GUIDE Introduction The MSolutions MS-63U1C is a USB 3.2 Gen 1 USB-A extender allowing for a single USB-A data channel to be extended to distances of up to 100m over a single CATx cable infrastructure. The extender features RS-232 serial pass-through and bi-directional 12V PoC (Power over Cable) expand the capabilities of this extender kit for a variety of commercial uses..
- Page 4 MS-63U1A USER GUIDE Connectivity Overview - Device Front panel: • CATx Link - connect to Cat cable from receiver • USB-A - connect USB-A peripheral Line in USB-A Device Back panel: • Control - Micro USB for firmware and control (reserved for future use) •...
- Page 5 MS-63U1A USER GUIDE Understanding the LED’s This MSolutions extender set includes status LED indicators on both the Host and Device products to show active connections and to further help integrators diagnose potential problems with the associated cabling. The RJ45 Link connections on both the host and device units have orange and green LED’s.
- Page 6 CloudOS control. RS-232 Control The MS-63U1A can distribute bi-directional serial commands between the transmitter and receiver to allow for control commands to be sent alongside USB. Each unit is fitted with a 3-pin phoenix connector block that will need the serial TX, RX and Ground pins terminating into for serial pass-through.
- Page 7 MS-63U1A USER GUIDE Specifications Device Host • USB-A connectivity: 1 x USB-A (female • USB-C connectivity: peripheral 1 x USB-C (female) - host • USB control: 1 x Micro USB (female) • USB control: 1 x Micro USB (female) •...
- Page 8 MS-63U1A USER GUIDE Schematic...
