Summary of Contents for Solutions MS-210U6S
- Page 1 User Guide MS-210U6S HDBaseT™ Extender Set - 4K to 40m (10G), 70m @ 1080p. USB 2.0 (x6), 2-way S/PDIF, one-way analogue audio pass-through, RS- 232 pass through, with single channel bi-directional IR. HDCP2.2 compliant Revision: 1.1 - Nov 2020...
-
Page 2: Table Of Contents
MS-210U6S USER GUIDE Contents Introduction Key Features Connectivity Overview (TX and RX) 04-05 Understanding the LED’s Cabling for HDBaseT Audio IR Control & RS-232 Control Specifications & Package Contents Schematic Notices • This MSolutions product contains electrical components that may be damaged by electrical spikes, surges, electric shock, lightning strikes, etc. -
Page 3: Introduction
MS-210U6S USER GUIDE Introduction The MSolutions MS-210U6S is a 4K HDMI / KVM HDBaseT extender set allowing for uncompressed video and audio to be extended up to 40m at 4K UHD (10.2Gbps), and 70m at 1080p or lower resolutions. 6 x independent USB2.0 channels allow for bi-directional USB client to host connectivity for connectivity of various peripherals in a variety of commercial and residential applications. -
Page 4: Connectivity Overview (Tx And Rx)
MS-210U6S USER GUIDE Connectivity Overview - TX Front panel: • Power - connect to supplied 48V/0.5A power supply • HDBaseT Out - connect to Cat cable to receiver • HDMI In - connect to HDMI source • USB Host - connect to USB host device •... - Page 5 MS-210U6S USER GUIDE Connectivity Overview - RX Front panel: • HDBaseT In - connect to Cat cable from transmitter • HDMI Out - connect to HDMI sink device • USB - connect USB peripheral devices (x2 Type A connections) •...
-
Page 6: Understanding The Led's
Cat and HDMI cables can be used for video signal distribution. Audio The MS-210U6S allows for bi-directional Optical audio signals to be transferred between TX and RX and vice-versa. This enables digital audio signals to be sent in either direction based on requirement of the install. -
Page 7: Usb
The MS-210U6S is supplied with a single 5V IR transmitter that can be connected to either of the 3.5mm jack sockets on the transmitter or receiver to the labelled ‘IR’ port. The 5V IR Receiver is then connected to the 3.5mm jack socket labelled ‘IR’... -
Page 8: Specifications & Package Contents
MS-210U6S USER GUIDE Specifications Transmitter Receiver • Video connectivity: 1 x HDMI input (female), • Video connectivity: 1 x HDBaseT input (RJ45 1 x HDBaseT output (RJ45 keystone) keystone), 1 x HDMI output (female) • Digital audio connectivity: 2 x S/PDIF •... -
Page 9: Schematic
MS-210U6S USER GUIDE Schematic... - Page 10 www.m4sol.com...
