hykolity WHC-0213 Owner's Manual

Hide thumbs

Advertisement

Table of Contents

SKU:WHC-0212
WHC-0213
WHC-0214
WHC-0215
WARNING
Improper installation, adjustment, alteration, service or maintenance can cause injury or property
damage. Read the owner's manual thoroughly before installing or servicing this equipment. If the
information in this manual is not followed exactly, a fire or explosion may result causing property
damage, personal injury or loss of life.
Save these instructions for future use. If
you are assembling this unit for someone
else, give this manual to him or her and
read and save for future.
OWNER'S MANNUAL
5016039
DANGER
If you smell gas:
1.Shut off gas to the appliance.
2.Extinguish any open flame.
3. If odor continues, keep away from
the appliance and immediately call
your gas supplier or fire department.
WARNING
Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other
appliance. An Propane-cylinder not
connected for use shall not be
stored in the vicinity of this or any
other appliance.
WARNING
For outdoor use only!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WHC-0213 and is the answer not in the manual?

Questions and answers

Related Manuals for hykolity WHC-0213

Summary of Contents for hykolity WHC-0213

  • Page 1 OWNER’S MANNUAL DANGER If you smell gas: SKU:WHC-0212 1.Shut off gas to the appliance. WHC-0213 2.Extinguish any open flame. WHC-0214 3. If odor continues, keep away from the appliance and immediately call WHC-0215 your gas supplier or fire department. WARNING...

  • Page 2: Safty Information

    SAFTY INFORMATION WARNING Before you assemble or operate this unit, please carefully read this entire manual. Failure to do so may result in a fire, explosion, injury or death.  The installation of this unit must adhere to local codes or either the National Fuel Gas Code, ANSI Z223.
  • Page 3 SAFTY INFORMATION  DO NOT operate unit if any part has been under water. Call a service technician to replace any damaged parts should this occur.  DO NOT disconnect any part while unit is in use.  DO NOT store a spare propane tank on or near this unit. ...

  • Page 4: Part List

    PART LIST 。 - DD 。 HARDWARES LIST 》 多 � 俨 ＾ ＠ 归 归 Item Description M8 Nut M6 Nut M8 Bolt M6x30 Bolt Wrench Reflector Stud Wing Nut Washer Webbing Cap Nut Small Screw M5 Bolt Anchoring Arm Anchoring M6*12 Bolt NOTE: Before beginning assembly of product, make sure all parts are present.
  • Page 5 PART LIST PARTS LIST � Item Description Reflector Panel Center Reflector Head Assembly Post Tank Housing Post Support Support Legs Regulator Base Wheel Assembly...
  • Page 6 ASSEMBLY INSTRUCTIONS STEP 1. Align the holes in the wheel assembly (J) with the holes in the base ( I), attach the wheel assembly to the base using 2 pcs M8 bolts (CC) and 2 pcs M8 nuts ( A A). Note: If it needs to be fixed on the ground,Secure the anchoring arm (NN) with two M6*12 bolts(PP) and M6 nuts (BB).
  • Page 7 ASSEMBLY INSTRUCTIONS STEP 4. Place the tank housing (E) on top of the assembly. STEP 5. Screw the threaded end of the reflector studs (FF) into the top holes of the head assembly (C). STEP 6. Slide two reflector panels (A) together and assemble the outer rim using one small screw (LL) and one cap nut (KK).
  • Page 8 ASSEMBLY INSTRUCTIONS STEP 8. Unscrew the four screws that are preassembled on the head assembly (C). Place the head assembly (C) into the top of the post (D) by inserting the regulator (H) into the post (D). Tightly fasten the previously removed screws back into the head assembly (C) through the slots at the top of the post (D).

  • Page 9: Operation

    OPERATION Before performing a leak test, be sure that no sparks can occur and you are in a spacious outdoor area. Connect the propane gas tank to the regulator and turn the valve on the unit to the "off" position. Brush a soap and water mixture on all connections.

  • Page 10: Maintenance

    MAINTENANCE  Before performing any maintenance always disconnect propane gas tank.  Keep the heating item free and clear from combustible materials.  Visually inspect burner for obstructions and keep tank enclosure free and clear from debris.  Use a soft brush to get rid of the mild stains, loose dirt and soil after the burner is completely cooled down.
  • Page 11 TROUBLESHOOTINGS PROBLEM CAUSE SOLUTION There is slight smoke This is residue from the manufacturing This will stop after approximately 30 minutes and odor during process. of operation. initial operation. Turn off the heater and let it cool. Remove There is thick black There is blockage in the burner.

This manual is also suitable for:

Whc-0214Whc-0215Whc-0212
