SKU:WHC-0201
WHC-0202
WARNING
Improper installation, adjustment, alteration, service or maintenance can cause injury or property
damage. Read the owner's manual thoroughly before installing or servicing this equipment. If the
information in this manual is not followed exactly, a fire or explosion may result causing property
damage, personal injury or loss of life.
Save these instructions for future use. If
you are assembling this unit for someone
else, give this manual to him or her and
read and save for future.
OWNER'S MANNUAL
5016039
Customer Support:(562)456-0507 / inquiry@hykolity.com
DANGER
If you smell gas:
1.Shut off gas to the appliance.
2.Extinguish any open flame.
3. If odor continues, keep away from
the appliance and immediately call
your gas supplier or fire department.
WARNING
Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other
appliance. An Propane-cylinder not
connected for use shall not be
stored in the vicinity of this or any
other appliance.
WARNING
For outdoor use only!
Advertisement
Table of Contents
Related Manuals for hykolity WHC-0201
Summary of Contents for hykolity WHC-0201
- Page 1 Save these instructions for future use. If you are assembling this unit for someone else, give this manual to him or her and read and save for future. 5016039 Customer Support:(562)456-0507 / inquiry@hykolity.com...
-
Page 2: Safty Information
If the flame goes out while burning, turn the gas valve off. Wait 5 minutes before repeating the initial lighting procedure. Once you have a flame started, hold down the control knob for 1 minute. Customer Support:(562)456-0507 / inquiry@hykolity.com... - Page 3 WILL BE SUBJECT TO RADIANT HEAT AND COULD BE SERIOUSLY DAMAGED. ---- 47 .3 " 47.3" Combustible materials should not be within 47.3 inches of the top of the unit, or within 47.3 inches around the entire unit. Customer Support:(562)456-0507 / inquiry@hykolity.com...
-
Page 4: Part List
NOTE: Before beginning assembly of product, make sure all parts are present. Compare parts with package contents list and hardware contents list. If any parts are missing or damaged, do not attempt to assemble the product. Estimated Assembly Time: 30 minutes Tools Required for Assembly (not included): Phillips Screwdriver Customer Support:(562)456-0507 / inquiry@hykolity.com... - Page 5 PART LIST PARTS LIST � Item Description Reflector Panel Center Reflector Head Assembly Post Tank Housing Post Support Support Legs Regulator Base Wheel Assembly Heat Focusing Reflector Customer Support:(562)456-0507 / inquiry@hykolity.com...
- Page 6 Attach the 3 pcs support legs (G) to the top of the base (I) using 3 pcs M8 bolts (CC). STEP 4. Attach the post support (F) to the top of the support legs (G) using 6 pcs M6x30 Bolt (DD) and 6 pcs M6 nuts (BB). Customer Support:(562)456-0507 / inquiry@hykolity.com...
- Page 7 Tighten all screws tightly. STEP 8. Attach the reflector assembly made in step 7 to the top of the reflector studs (FF) on the head assembly (C). Fasten with six flat washers (HH) and three wing nuts (GG). Customer Support:(562)456-0507 / inquiry@hykolity.com...
- Page 8 Turn the cylinder valve on the tank clockwise to close the propane tank. Attach the regulator (H) to the cylinder valve by turning the regulator coupling nut clockwise. Make sure it is fastened securely and tighten connections by hand only. Customer Support:(562)456-0507 / inquiry@hykolity.com...
-
Page 9: Operation
To Extinguish Turn control knob clockwise to the "off" position. Close the cylinder valve on the propane gas tank if you don't intend to use it for a long time. Customer Support:(562)456-0507 / inquiry@hykolity.com... -
Page 10: Maintenance
Clean or replace the burner injector. injector. The emitter glows The base is not on a level surface. Place the heater on a level surface. uneven. The gas pressure is low. Replace the cylinder with a new cylinder. Customer Support:(562)456-0507 / inquiry@hykolity.com... - Page 11 Clean the reflector and flame screen. build-up. flame screen. Customer Service Thank you for ordering our product. If you have any questions, please feel free to contact us at (562)456-0507 or email to inquiry@hykolity.com. We always find ways to improve! Customer Support:(562)456-0507 / inquiry@hykolity.com...
