- Page 1 SATA Product Manual ST10000DM0004 ST8000DM0004 100804071, Rev. D January 2017...
- Page 2 Seagate, Seagate Technology, BarraCuda and the Spiral logo are registered trademarks of Seagate Technology LLC in the United States and/or other countries. PowerChoice and SeaTools are either trademarks or registered trademarks of Seagate Technology LLC or one of its affiliated companies in the United States and/or other countries. The FIPS logo is a cer- tification mark of NIST, which does not imply product endorsement by NIST, the U.S., or Canadian governments.
-
Page 3: Table Of Contents
Storage ................16 2.10.3 Seagate® Rescue™ Data Recovery Service Program Terms (for +Rescue models) ..17 2.11 Agency certification . - Page 4 S.M.A.R.T. commands............. . 31 Seagate BarraCuda Pro SATA Product Manual, Rev. D...
-
Page 5: Seagate® Technology Support Services
For information regarding online support and services, visit: http://www.seagate.com/contacts/ For information regarding Warranty Support, visit: http://www.seagate.com/support/warranty-and-replacements/ For information regarding data recovery services, visit: http://www.seagate.com/services-software/data-recovery-services/ For Seagate OEM, Distribution partner and reseller portals, visit: http://www.seagate.com/partners/ Seagate BarraCuda Pro SATA Product Manual, Rev. D... -
Page 6: Introduction
• Supports latching SATA cables and connectors. • Top Cover Attached motor for excellent vibration tolerance • Worldwide Name (WWN) capability uniquely identifies the drive. Seagate recommends validating the configuration with the selected HBA/RAID Note controller manufacturer to ensure use of full capacity is supported. -
Page 7: Drive Specifications
–304.8 m to 12,192 m (below mean sea level, max) (–1000 ft to 40,000+ ft) Operational Shock (max at 2 ms) Read 70 Gs / Write 40 Gs Non-Operational Shock (max at 2 ms) 250 Gs Seagate BarraCuda Pro SATA Product Manual, Rev. D... - Page 8 † Seagate does not recommend operating at sustained case temperatures above 60°C. Operating at higher temperatures will reduce useful life of the product. Seagate BarraCuda Pro SATA Product Manual, Rev. D...
-
Page 9: Formatted Capacity
Maximum Sustained transfer rate (MB/s) I/O data-transfer rate (MB/s max) 600 (Ultra DMA mode 5) Start/stop times Power-on to Ready (sec) (typ/max) 20/30 Standby to Ready (sec) (typ/max) 20/30 Ready to spindle stop (sec) (max) Seagate BarraCuda Pro SATA Product Manual, Rev. D... -
Page 10: Power Specifications
Maximum DC 0.60 0.31 Maximum DC (peak) 0.78 0.71 *During periods of drive idle, some offline activity may occur according to the S.M.A.R.T. specification, which may increase acoustic and power to operational levels Seagate BarraCuda Pro SATA Product Manual, Rev. D... -
Page 11: Conducted Noise
• Using 5V power, the drive is expected to operate with a maximum of 100mV peak-to-peak square-wave injected noise at up to 10MHz. Equivalent resistance is calculated by dividing the nominal voltage by the typical RMS read/write current. Note 2.5.3 Voltage tolerance Voltage tolerance (including noise): 12V ± 10% ±5% Seagate BarraCuda Pro SATA Product Manual, Rev. D... -
Page 12: Extended Power Conditions - Powerchoicetm
• Saved enabled state, and timer value • Current enabled state, and timer value S.M.A.R.T. Read Data Reports • Attribute 192 - Emergency Retract Count • Attribute 193 - Load/Unload Cycle Count Seagate BarraCuda Pro SATA Product Manual, Rev. D... - Page 13 Disable EPC Feature Set PowerChoice Supported Extended Power Condition Identifiers Power Condition Identifiers Power Condition Name Standby_z 01 - 80 Reserved Idle_a Idle_b Idle_c 84 - FE Reserved All EPC Power Conditions Seagate BarraCuda Pro SATA Product Manual, Rev. D...
-
Page 14: Environmental Limits
Non-operating –40° to 158°F (–40° to 70°C) package ambient with a maximum gradient of 36°F (20°C) per hour. This specification assumes that the drive is packaged in the shipping container designed by Seagate for use with drive. HDA Temp. -
Page 15: Shock
The maximum nonoperating vibration levels that the drive may experience without incurring physical damage or degradation in performance when subsequently put into operation are specified below. 2–500 Hz 2.27 Grms ref Linear Random Freq (Hz) .001 .001 Seagate BarraCuda Pro SATA Product Manual, Rev. D... -
Page 16: Acoustics
Test for Prominent Discrete Tones (PDTs) Seagate follows the ECMA-74 standards for measurement and identification of PDTs. An exception to this process is the use of the absolute threshold of hearing. Seagate uses this threshold curve (originated in ISO 389-7) to discern tone audibility and to compensate for the inaudible components of sound prior to computation of tone ratios according to Annex D of the ECMA-74 standards. -
Page 17: Reliability
None required. 2.10.2 Storage Maximum storage periods are 180 days within original unopened Seagate shipping package or 60 days unpackaged within the defined non-operating limits (refer to environmental section in this manual). Storage can be extended to 1 year packaged or unpackaged under optimal environmental conditions (25°C, <40% relative humidity non-condensing, and non-corrosive... -
Page 18: Seagate® Rescue™ Data Recovery Service Program Terms (For +Rescue Models)
US, please visit our website for numbers in your local and language: http://www.seagate.com/services-software/recover/resources/. An SRS representative will review your case to confirm your eligibility, and to assess whether your data may be recoverable by remote recovery services or whether you will need to send your device to SRS for in-lab servicing. - Page 19 Seagate reserves the right to refuse service to or the return of any storage devices that have been determined to violate these regulations.
-
Page 20: Agency Certification
Federal Communications Commission verification or certification of the device is required. Seagate has tested this device in enclosures as described above to ensure that the total assembly (enclosure, disk drive, motherboard, power supply, etc.) does comply with the limits for a Class B computing device, pursuant to Subpart J, Part 15 of the FCC rules. -
Page 21: Environmental Protection
DC 20402. Refer to publication number 004-000-00345-4. 2.12 Environmental protection Seagate designs its products to meet environmental protection requirements worldwide, including regulations restricting certain chemical substances. 2.12.1 European Union Restriction of Hazardous Substances (RoHS) Directive The European Union Restriction of Hazardous Substances (RoHS) Directive, restricts the presence of chemical substances, including Lead, Cadmium, Mercury, Hexavalent Chromium, PBB and PBDE, in electronic products, effective July 2006. -
Page 22: Corrosive Environment
When transporting or shipping a drive, use only a Seagate-approved container. Keep the original box. Seagate approved containers are easily identified by the Seagate Approved Package label. Shipping a drive in a non-approved container voids the drive warranty. Seagate repair centers may refuse receipt of components improperly packaged or obviously damaged in transit. Contact the authorized Seagate distributor to purchase additional boxes. -
Page 23: Configuring And Mounting The Drive
For installations which require cables, users can connect the drive as illustrated in Figure 3. Figure 3. Attaching SATA cabling Each cable is keyed to ensure correct orientation. BarraCuda Pro Serial ATA drives support latching SATA connectors. Seagate BarraCuda Pro SATA Product Manual, Rev. D... -
Page 24: Drive Mounting
.142±.015 2 2.000 C L OF DRIVE Figure 4. Mounting configuration dimensions (10TB & 8TB) models) The image is for mechanical dimension reference only and may not represent the actual drive. Note Seagate BarraCuda Pro SATA Product Manual, Rev. D... -
Page 25: Serial Ata (Sata) Interface
For detailed information about the Serial ATA interface, refer to the “Serial ATA: High Speed Serialized AT Attachment” specification. Hot-Plug compatibility BarraCuda Pro Serial ATA drives incorporate connectors which enable users to hot plug these drives in accordance with the Serial ATA Revision 3.2 specification. This specification can be downloaded from www.serialata.org. -
Page 26: Supported Ata Commands
Sanitize Device - Overwrite Ext / 0014 Sanitize Device - Freeze Lock Ext / 0020 Sanitize Device - Status Ext / 0000 Security Disable Password Security Erase Prepare Security Erase Unit Security Freeze Security Set Password Seagate BarraCuda Pro SATA Product Manual, Rev. D... - Page 27 Write DMA FUA Extended Write FPDMA Queued Write Log DMA Ext Write Log Extended Write Multiple Write Multiple Extended Write Multiple FUA Extended Write Sectors Write Sectors Without Retries Write Sectors Extended Write Uncorrectable Seagate BarraCuda Pro SATA Product Manual, Rev. D...
-
Page 28: Identify Device Command
Advanced PIO modes supported (modes 3 and 4 supported) 0003 Minimum multiword DMA transfer cycle time per word (120 ns) 0078 Recommended multiword DMA transfer cycle time per word (120 ns) 0078 Seagate BarraCuda Pro SATA Product Manual, Rev. D... - Page 29 If bit 0 is set to one, then the device supports SCT Command Transport. xxBD Bits 7:2 indicate individual SCT feature support. 207-254 ATA-reserved 0000 Integrity word xxA5 See the bit descriptions below for words 63, 84, and 88 of the Identify Drive data. Note Seagate BarraCuda Pro SATA Product Manual, Rev. D...
- Page 30 Ultra DMA mode 2 is currently active. Ultra DMA mode 3 is currently active. Ultra DMA mode 4 is currently active. Ultra DMA mode 5 is currently active. Ultra DMA mode 6 is currently active. Seagate BarraCuda Pro SATA Product Manual, Rev. D...
-
Page 31: Set Features Command
Disable use of SATA features Enable read look-ahead (read cache) feature (default). Report full capacity available At power-on, or after a hardware or software reset, the default values of the features are as indicated above. Note Seagate BarraCuda Pro SATA Product Manual, Rev. D... -
Page 32: Commands
S.M.A.R.T. Disable Operations S.M.A.R.T. Return Status If an appropriate code is not written to the Features Register, the Note command is aborted and 0x 04 (abort) is written to the Error register. Seagate BarraCuda Pro SATA Product Manual, Rev. D... - Page 33 ASIA/PACIFIC Seagate Singapore International Headquarters Pte. Ltd. 7000 Ang Mo Kio Avenue 5, Singapore 569877, 65-6485-3888 EUROPE, MIDDLE EAST AND AFRICA Seagate Technology SAS 16-18 rue du Dôme, 92100 Boulogne-Billancourt, France, 33 1-4186 10 00 Publication Number: 100804071, Rev. D...
