  • Page 1 FOCAL/RENAULT INSTALLATION OF LIVE/PREMIUM KITS FOR Megane 4 – April 2018...

  • Page 2: Recommendations Before Installation

    RECOMMENDATIONS BEFORE INSTALLATION Reset all car radio audio settings: o Ambience = Natural o Bass / Midrange / Treble settings = 0 o Loudness = OFF o Fader and Balance = Centred The speaker drivers require a break-in period (approximately 20 hours) before they reach optimal sound quality.
  • Page 3 I – UNBOXING AND LOCATION OF PARTS...
  • Page 4 I – UNBOXING AND LOCATION OF PARTS...
  • Page 5 I – UNBOXING AND LOCATION OF PARTS...
  • Page 6 I- UNBOXING AND LOCATION OF PARTS...
  • Page 7 I – UNBOXING AND LOCATION OF PARTS...
  • Page 8 II – ASSEMBLING THE FRONT SPEAKER DRIVERS 1. Equipment required for assembling the woofer...
  • Page 9 II – ASSEMBLING THE FRONT SPEAKER DRIVERS 2. Connections a. Insert the cable into the notch b. Before you screw, make sure that the two logos are aligned c. Screw the 4 screws D. Block the crossover...
  • Page 10 III – ASSEMBLING THE FRONT SPEAKER DRIVERS 1. Unclip the frontdoor panel a. Unclip and unscrew then remove the frontdoor panel...
  • Page 11 III – ASSEMBLING THE FRONT SPEAKER DRIVERS 2. Remove the original speaker driver Note : Keep the spacer riveted to the door frame. a. Pierce the 3 rivets’ head.
  • Page 12 III – ASSEMBLING THE FRONT SPEAKER DRIVERS 3. Installing the front speaker drivers a. Rivet on the door frame and connect the Focal speaker driver. Note : Some version may use screws. If so, do not use the rivet...
  • Page 13 IV – ASSEMBLING THE TWEETER 1. Equipment required for assembling 2. Remove the tweeter’s grille by the tweeter simply unclipping it...
  • Page 14 IV – ASSEMBLING THE TWEETER 3. Slot the tweeter into the spacer 4. Connect at position 2 making sure it’s the right way up Note: Dispose the parts in Note: Position 1 is not used this very position. in this set up...

  • Page 15: Installing The Tweeter

    V – INSTALLING THE TWEETER 1 Remove the tweeter grille 2 Remove the tweeter...
  • Page 16 V – INSTALLING THE TWEETER 3 Insert the crossover and connect it 4 Clip the tweeter into its housing then the grille...
  • Page 17 V – ASSEMBLING THE FRONT SPEAKER DRIVERS 1. Equipment required for assembling the woofer...
  • Page 18 V – ASSEMBLING THE FRONT SPEAKER DRIVERS 2. Connections a. Insert the cable into the notch b. Before you screw, make sure that the two logos are aligned c. Screw the 4 screws D. Block the crossover...
  • Page 19 VI – ASSEMBLING THE REAR SPEAKER DRIVERS 1. Unscrew Remove the door panel...
  • Page 20 VI – ASSEMBLING THE REAR SPEAKER DRIVERS 2. Remove the original speaker driver Note : Keep the spacer riveted to the door frame. a. Pierce the 3 rivets’ head.
  • Page 21 VI – ASSEMBLING THE REAR SPEAKER DRIVERS Installing the front speaker drivers a. Rivet on the door frame and connect the Focal speaker driver. Note : Some version may use screws. If so, do not use the rivet...
  • Page 22 VII – ASSEMBLING THE TWEETER 1. Equipment required for assembling 2. Remove the tweeter’s grille by the tweeter simply unclipping it...
  • Page 23 VII – ASSEMBLING THE TWEETER 3. Slot the tweeter into the spacer 4. Connect at position 2 making sure it’s the right way up Note: Dispose the parts in Note: Position 1 is not used this very position. in this set up...
  • Page 24 VIII – INSTALLING THE REAR TWEETER 1. Connect the crossover to the original connector Original connector 2. Clip the Focal tweeter Replaced by :...
  • Page 25 VIII – INSTALLING THE REAR TWEETER 3. Connect the crossover to the tweeter before putting the door panel back...

  • Page 26: Preparing The Subwoofer

    VII – PREPARING THE SUBWOOFER 1. Equipment required for installing the subwoofer Subwoofer cable with Heat shrinkable Power connector Ground cable Power cable Adapter remote control sleeve Head unit – subwoofer Hook-and-loop fasteners Ibus 2.1 Extension cable interconnect cable (e.g. Velcro®) Connectors...
  • Page 27 VII – PREPARING THE SUBWOOFER 1. Prepare subwoofer cable assembly a. Remove the b. Place the heat shrinkable c. Use a heat gun to heat the heat fuse and pod sleeve over the stripped parts shrinkable sleeve. of the cables.
  • Page 28 VII – PREPARING THE SUBWOOFER d. Connect the adapter to the extension cable. g. Keep slack for the cable’s passage on the e. Place the subwoofer without f. Tape the cables together side of the head unit. connecting it. every 20 cm.

  • Page 29: Installing The Subwoofer

    VIII – INSTALLING THE SUBWOOFER 1. Unclip the console’s upper part 2. Unplug the two lighted sidebars (if they exist) then remove them...
  • Page 30 VIII – INSTALLING THE SUBWOOFER 3. Remove the plastic covers on both side 4. Remove the outer part of the head unit...
  • Page 31 VIII – INSTALLING THE SUBWOOFER 5. Unscrew to push back the console Note : Unscrew on both side.
  • Page 32 VIII – INSTALLING THE SUBWOOFER 6. Push back the console then remove the plastic covers...
  • Page 33 VIII – INSTALLING THE SUBWOOFER Connection to 12 v cigar lighter( front or rear) 1. In the case shown below, rear connection 2. Connection to the head unit Connect to the head unit Connect to the speaker driver...
  • Page 34 VIII – INSTALLING THE SUBWOOFER 2. Passageway of the wires from front to rear Note : fix the wires under the carpet from the console’s exit Note : Fix the remote with some Velcro® (advised).
  • Page 35 VIII – INSTALLING THE SUBWOOFER 3. Ground wire connection( black wire ) a. Connect the ground wire to the rear ground slot...
  • Page 36 VIII – INSTALLING THE SUBWOOFER Subwoofer positionning a. Position the subwoofer behind the backseat on the left (It is advised to screw the subwoofer with the provided screws and rubber pads) Note : Fix the subwoofer with the provided Velcro®.
  • Page 37 VIII – INSTALLING THE SUBWOOFER b. Connect (rear) c. Connect (front – remote)
  • Page 38 VIII – INSTALLING THE SUBWOOFER d. Subwoofer settings.
  • Page 39 IX - ACCESSORIES a. Stickers : Put the provided stickers on to the tweeter’s grille. a. Front b. Rear...
