Focal IFRA165-4.1 Instructions Manual

For renault clio 5
Hide thumbs Also See for IFRA165-4.1:

Advertisement

Quick Links

Download this manual
FOCAL/RENAULT
INSTALLATION OF LIVE/PREMIUM KITS FOR
Clio 5 –
January 2019

Advertisement

loading
Need help?

Need help?

Do you have a question about the IFRA165-4.1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Focal IFRA165-4.1

Summary of Contents for Focal IFRA165-4.1

  • Page 1 FOCAL/RENAULT INSTALLATION OF LIVE/PREMIUM KITS FOR Clio 5 – January 2019...

  • Page 2: Recommendations Before Installation

    RECOMMENDATIONS BEFORE INSTALLATION Reset all car radio audio settings: o Ambience = Natural o Bass / Midrange / Treble settings = 0 o Loudness = OFF o Fader and Balance = Centered The speaker drivers require a break-in period (approximately 20 hours) before they reach optimal sound quality.
  • Page 3 I – UNBOXING AND LOCATION OF PARTS...
  • Page 4 I – UNBOXING AND LOCATION OF PARTS...
  • Page 5 I – UNBOXING AND LOCATION OF PARTS...
  • Page 6 I- UNBOXING AND LOCATION OF PARTS...
  • Page 7 I – UNBOXING AND LOCATION OF PARTS...
  • Page 8 II – ASSEMBLING THE FRONT SPEAKER DRIVERS 1. Equipment required for assembling the woofer...
  • Page 9 II – ASSEMBLING THE FRONT SPEAKER DRIVERS 2. Connections a. Insert the cable into the notch b. Before you screw, make sure that the two logos are aligned c. Screw the 4 screws D. Block the crossover...
  • Page 10 III – ASSEMBLING THE FRONT SPEAKER DRIVERS 1. Unclip the frontdoor panel a. Unclip and unscrew then remove the frontdoor panel...
  • Page 11 III – ASSEMBLING THE FRONT SPEAKER DRIVERS 2. Remove the original speaker driver Note : Keep the spacer riveted to the door frame. a. Pierce the 3 rivets’ head.
  • Page 12 III – ASSEMBLING THE FRONT SPEAKER DRIVERS 3. Installing the front speaker drivers a. Rivet on the door frame and connect the Focal speaker driver. Note : Some version may use screws. If so, do not use the rivet...
  • Page 13 IV – ASSEMBLING THE TWEETER 1. Equipment required for assembling 2. Remove the tweeter’s grille by the tweeter simply unclipping it...
  • Page 14 IV – ASSEMBLING THE TWEETER 3. Slot the tweeter into the spacer 4. Connect at position 2 Note : Position 1 is not used for this vehicle Note : The two parts must be displayed as shown above.
  • Page 15 V – CONNECTING THE TWEETER 1 Remove the tweeter grille 2 Remove the tweeter Note: Do not forget to put the screw back...
  • Page 16 V – CONNECTING THE TWEETER 3 Connect the crossover...
  • Page 17 VI – ASSEMBLING THE REAR SPEAKER DRIVERS Remove the door panel 1. Unscrew...
  • Page 18 VI – ASSEMBLING THE REAR SPEAKER DRIVERS 3. Remove the original speaker driver a. Pierce the 3 rivets’ head...
  • Page 19 VI – ASSEMBLING THE REAR SPEAKER DRIVERS Installing the rear speaker driver a. Rivet on the door frame and connect the Focal speaker driver. Note : Orientate the tweeter by turning it up or down...

  • Page 20: Preparing The Subwoofer

    VII – PREPARING THE SUBWOOFER 1. Equipment required for installing the subwoofer Subwoofer cable with Heat shrinkable Power connector Ground cable Power cable Adapter remote control sleeve Head unit – subwoofer Hook-and-loop fasteners Ibus 2.1 Extension cable interconnect cable (e.g. Velcro®) Connectors...
  • Page 21 VII – PREPARING THE SUBWOOFER 1. Prepare subwoofer cable assembly a. Remove the b. Place the heat shrinkable c. Use a heat gun to heat the heat fuse and pod sleeve over the stripped parts shrinkable sleeve. of the cables.
  • Page 22 VII – PREPARING THE SUBWOOFER d. Connect the adapter to the extension cable. g. Keep slack for the cable’s passage on the e. Place the subwoofer without f. Tape the cables together side of the head unit. connecting it. every 20 cm.

  • Page 23: Installing The Subwoofer

    VIII – INSTALLING THE SUBWOOFER 1. Remove the airbag cover on the side 2. Remove the screws on the glove box...
  • Page 24 VIII – INSTALLING THE SUBWOOFER 3. Connect to the head unit Connect to the head unit Connect to the speaker driver...
  • Page 25 VIII – INSTALLING THE SUBWOOFER 4. Wiring Remove the panel in order to get to the 12V socket, then connect to the power supply...
  • Page 26 VIII – INSTALLING THE SUBWOOFER 5. Remote location From the back seat Note : unscrew on each side.
  • Page 27 VIII – INSTALLING THE SUBWOOFER 3. Ground wire connection( black wire ) a. Connect the ground wire to the rear ground slot...
  • Page 28 VIII – INSTALLING THE SUBWOOFER Subwoofer positionning a. Position the subwoofer behind the backseat on the left (It is advised to screw the subwoofer with the provided screws and rubber pads) Note : Fix the subwoofer with the provided Velcro®.
  • Page 29 VIII – INSTALLING THE SUBWOOFER b. Connect (rear) c. Connect (front – remote)
  • Page 30 VIII – INSTALLING THE SUBWOOFER d. Subwoofer settings.
  • Page 31 IX - ACCESSORIES a. Stickers : Put the provided stickers onto the tweeters’ grille.
