  • Page 1 PACK DELTA 8000 4 zone control pack for hydraulic floor heating or ductable air conditioning Installation instructions...
  • Page 2: Table Of Contents

    Content 1/ Composition 1/ Composition ......................3 2/ Installation ......................4 Your PACK comprises: 2.1 DELTA 8000 BT ......................4 - 1 DELTA 8000 BT technical unit 2.2 DELTA 8000 RF ......................5 - 1 DELTA 8000 RF wireless/bus gateway 2.3 DELTA 8000 TA RF .....................6 - 4 DELTA 8000 TA RF room thermostats 2.4 TYDOM Home......................7 - 1 TYDOM Home and its connector...
  • Page 3: 2/ Installation

    2/ Installation 2.1 DELTA 8000 BT 2.2 DELTA 8000 RF ❶ Remove the cover ❶ Shut down the bus power supply. ❶ 230V~ 50 Hz ❷ Mount the unit with a set of screws/ ❷ ❸ Open the unit door by pushing 230V~ sprigs compatible with the substrate 50 Hz...
  • Page 4: Delta 8000 Ta Rf

    2/ Installation 2.3 DELTA 8000 TA RF 2.4 TYDOM Home Since the temperature measurement sensor is inside the unit, you must install the 2.4.1 Box contents thermostat flush-mounting box: A. Tydom Home - on an accessible wall at a height of 1.50 m B.
  • Page 5: 3/ Connection

    3/ Connection 3.1 DELTA 8000 BT Switch off the mains power before handling the device. ❶ Set switch 2 to the position ON. Heat (boiler or non-reversible heat Production pump) mode Heat/Cool (reversible heat pump) ❷ Connect the on/off control output, dry contact 2A Max, 230V~ GENERAL AUXILIARIES VALVE ACTUATORS...
  • Page 6: 4/ Wireless Association

    Th 1 Th 2 Th 3 Absence of dew point measurement or sensor with Associated outputs Controlled outputs a Delta Dore condensation sensor (For cooling only, Type of 'water Thermostat 1 Y1, Y2, Y3 shuts the system down if condensation is detected). monitoring' Thermostat 2...
  • Page 7: Associate The Tydom Application

    4/ Wireless association 5/ Installation configuration 5.1 DELTA 8000 BT configuration Press OK for the next step. On the TA RF, Underfloor heating ❶ From the OFF mode, press and hold the 2nd button Transmitter Heater from the left for 5 seconds. type Release.
  • Page 8: Delta 8000 Ta Rf

    5/ Installation configuration Correction of the measured 5.2 DELTA 8000 TA RF +/- 5°C in increments of 0.1°C (0°C by default) temperature 0 Setting display (default selection) Temperature displayed (after thermostat ❶ From the OFF mode. wakes up) 1 Display of the measured temperature. Press and hold the 2nd button from the left for 5 seconds.
  • Page 9: 6/ Additional Products (Optional)

    6/ Additional products (optional) 7/ Troubleshooting You can extend your installation by acquiring additional products. 7.1 Possible faults on the technical unit BUS 1 BUS 2 If you have 2-wire valves, you can extend your installation When a defect is detected on the system, the symbol flashes on the room to 8 DELTA 8000 TA RF per technical unit.
  • Page 10: Downgraded Mode

    7/ Troubleshooting 7.2 Downgraded mode Circulator LED The technical unit operates in downgraded mode (30% in Heat, OFF and Cool Status LED Burner LED mode), for each channel, when: Configuration - thermostat signal missing for over one hour (the red LED for the way blinks Valve output LEDs switches quickly),...
  • Page 11: Signals And Possible Faults On The Tydom Home

    7/ Troubleshooting  Reset to factory settings  7.4 Signals and possible faults on the TYDOM Home Press the button for 30 seconds until the LED stops flashing. Release. System status - DHCP mode System status - Clear product associations Flashing white System accessible locally and remotely, user connected System accessible locally and remotely Steady white System accessible locally, user connected Flashing orange...
  • Page 12: Restoring The Technical Unit To Factory Settings

    7/ Troubleshooting 7.5 Restoring the technical unit to factory settings 7.6 Initialising the room thermostat settings This menu restores the parameters CL01, CL03 and CL04 This menu restores the system to factory settings, except CF20, CF21 and CF05. to factory settings ❶ From the OFF mode. Simultaneously press the 1st With a room thermostat (RT) and 3rd buttons from the left (i) for 10 seconds.
  • Page 13: Deleting The Association Of The Gateway With A Room Thermostat

    7/ Troubleshooting 7.7 Deleting all the associations radio 7.8 Deleting the association of the gateway with  with a room thermostat a room thermostat ❶ Press and hold the left hand side button for 3 seconds ❶ From the OFF mode. Press and hold the 2nd button from the left for 5 seconds. until LED 1 flashes, then release. Release.
  • Page 14: 8/ Technical Characteristics

    8/ Technical characteristics Technical unit DELTA 8000 BT Wireless room thermotat DELTA 8000 TA RF • Main power supply 230V~/240V~, +/-10%, 50/60 Hz, • Powered with 2 batteries: • Valve power supply (24V~/= or 230V~/240V~): 4A Max for all valves - Alkaline 1.5V, LR03 (AAA), battery life 5 years or •...
