Control Panel Description

11
10
9
8
7
6
5
1. LED display
2. Micro SD card port
3. Next Track/FM channel key
4. Previous Track/FM channel key
5. Play/Pause key
6. Mode change Key
7. Echo control
8. Microphone 1 input jack
9. LED indicator
10. Bass control
11. Master volume control
12. Power ON/OFF switch
13. AC input port
14. External DC12V battery Input port
15. Treble control
16. Microphone 2 input jack
17. Mic volume control
18. Recording & play record key
Long Press to Recording
Short Press to Play Recorded File
19. Mic Priority On-Off key
20. Press this button to switch between 3
different lighting modes and on/off.
21. TWS Connection key
22. AUX IN
23. USB port
12
LED
4 3 2
13
14
1
23 22 21 20
15
16
17
18
19
