Dot Origin VTAP50 Installation Manual

Embedded reader board
Hide thumbs Also See for VTAP50:
Table of Contents

Advertisement

Quick Links

Download this manual

Installation Guide -
VTAP50 Embedded Reader Board
VTAP50 OEM module
Revised July 2024 v1.4

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VTAP50 and is the answer not in the manual?

Questions and answers

Related Manuals for Dot Origin VTAP50

Summary of Contents for Dot Origin VTAP50

  • Page 1   Installation Guide - VTAP50 Embedded Reader Board VTAP50 OEM module Revised July 2024 v1.4...
  • Page 2 If you need help to set up or use your VTAP50, beyond what is contained in this Installation Guide, then please contact our support team. Email: vtap-support@dotorigin.com Download the latest documentation and firmware from https://vtapnfc.com Telephone UK and Europe: +44 (0) 1428 685861...

  • Page 3: Table Of Contents

    VTAP MOBILE WALLET READERS Contents 1  Using this guide 2  How the VTAP50 works 2.1 Default operation 2.2 Start reading your own passes 2.3 Check status in BOOT.TXT 3  Mechanical installation 3.1 Power 3.2 Environment 3.3 Mounting points 3.4 Optional captive cable connection - RS-232 and USB 3.5 Optional FFC Connector - USB and TTL serial...
  • Page 4 The VTAP50 equipment is intended for use by suitably qualified integrators, who will integrate the VTAP50 OEM module (PCB) into their own hardware, without any changes or modifications to the VTAP50 OEM module device. (An optional enclosure can be supplied.) Components mounted on the VTAP50 PCB are not user-serviceable.
  • Page 5 If the identification number is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module, Contains FCC ID: 2A282-VTAP50. Co-location of this module with other transmitters that operate simultaneously are required to be evaluated using the multi-transmitter procedures.
  • Page 6 Si le numéro d'identification n'est pas visible lorsque le module est installé à l'intérieur d'un autre appareil, alors l'extérieur de l'appareil dans lequel le module est installé doit également afficher une étiquette faisant référence au module fourni, Contient IC : 30458-VTAP50. VTAP50 OEM MODULE ©...

  • Page 7: Using This Guide

    VTAP50 unit, when a new release is available. The firmware on a VTAP50 functions in exactly the same way as that used on a VTAP100, so you can refer to generic VTAP Configuration Guides.

  • Page 8: How The Vtap50 Works

    VTAP100, so you can refer to generic VTAP Configuration Guides. By default the VTAP50 is fully upgradable in the field. However, the VTAP50 can be locked in software or hardware, before deploying the unit, so that operation is no longer easily changed.

  • Page 9: Default Operation

    These steps demonstrate that the hardware can detect and interact with an OriginPass demo mobile NFC pass, which is ready to work with the default configuration of your VTAP50. 1. Obtain an OriginPass from Dot Origin by visiting https://originpass.com/VTAP/ and add it to Google or Apple Wallet.
  • Page 10 VTAP Application Note which explains more about ECC key pairs and how to generate your own keys.) This first time, you will need to connect the VTAP50 to your PC, using a USB cable. (If needed, you can make changes remotely in future over a virtual COM port or serial port, see VTAP Serial Integration Guide.)
  • Page 11 (There is a VTAP Application Note on Multiple Passes which explains more.) Put each parameter on a new line. Order of parameters does not matter to the VTAP50, but could help other people who need to edit the file. Start any comment lines in the config.txt file, that the VTAP50 should ignore, with a semicolon.
  • Page 12 Note: If an ST#KeySlot parameter is omitted, or set to 0, then authentication will be omitted and decryption will not be performed. In this case, Google Smart Tap data will be received and sent on by the VTAP50, only if the pass does not require authentication by the terminal.

  • Page 13: Check Status In Boot.txt

    VTAP MOBILE WALLET READERS 2.3 Check status in BOOT.TXT If you navigate to the VTAP50 in the computer's file system. It will appear as an attached mass storage device and list the files contained, including the BOOT.TXT file. Inspecting BOOT.TXT will give you essential information about your VTAP50 set up, at time of last reboot, which might be helpful when troubleshooting.
  • Page 14 'Boot time' - The time at boot, which defaults to 1970/00/00 00:00:00 if power is removed to reboot. If the configuration has been locked the BOOT.TXT file will end with the words LOCKED S/W or LOCKED H/W. VTAP50 OEM MODULE © DOT ORIGIN PAGE 8 INSTALLATION GUIDE...

  • Page 15: Mechanical Installation

    VTAP MOBILE WALLET READERS 3   Mechanical installation The VTAP50 unit for OEM integration comprises a PCB with an integral antenna around the perimeter of the board. Figure 3-1 VTAP50 components - v1 or v2 Hardware WARNING: Observe all Safety instructions when installing the VTAP50 PCB.

  • Page 16: Mounting Points

    The PCB has 2.7mm diameter mounting holes for fixing the unit. Use 2-4 small nuts and bolts to mount the board securely. Figure 3-2 VTAP50 PCB mounting holes - v1 or v2 Hardware The user’s smartphone should be able to tap within 10mm of the antenna on the PCB. The antenna position should be clearly marked and easily accessed, so that users can position their smartphone appropriately.

  • Page 17: Optional Captive Cable Connection - Rs-232 And Usb

    Figure 3-3 VTAP50 captive power cable or RS-232 connection - VTAP50 v1 Rev 2 or v2 Hardware onwards CAUTION: There are a small number of VTAP50 v1 Rev 1 units in circulation. Please be aware that the pins on v1 Rev 1 hardware are pairwise switched.
  • Page 18 DCE and DTE devices, so that the transmit pin on one connects to the receive pin on the other. The VTAP50 requires a 5V power supply, but not all RS-232 devices have 5V on pin 9. Either: Disconnect the USB cable before making the serial connection, if power will be provided by J1 (pins 1 and 3) and the serial cable/host.

  • Page 19: Optional Ffc Connector - Usb And Ttl Serial

    VTAP MOBILE WALLET READERS 3.5 Optional FFC Connector - USB and TTL serial The FFC connector is found on the under side of the VTAP50 PCB. Note: The Flexible Flat Cable (FFC) expansion connector is only suitable for USB and TTL use from VTAP50 v2 onwards.
  • Page 20 You can change the way the data is presented (eg with prefixes and postfixes) to suit your target receiving device/application. Note: TTL serial is also available from the expansion header used to connect external LEDs or antennas, from VTAP50 v2 onward. VTAP50 OEM MODULE © DOT ORIGIN...

  • Page 21: Optional External Leds

    VTAP MOBILE WALLET READERS 4   Optional external LEDs The VTAP50 v1 board does not have feedback LEDs, which are present on the VTAP50 v2 board. An external RGB LED can be configured to show a default colour permanently, and then automatically change colour (or flash) in response to a successful pass read, successful card read or other error conditions.
  • Page 22 15mA per LED output at 5V, so the maximum current required is 350mA. External LEDs should be decoupled, with 10μF bulk capacitance per LED along the LED path) The VTAP50 can support both common cathode and common anode, by changing the LEDSelect setting in the config.txt file.

  • Page 23: Permanently Disable On-Board Leds

    LEDs, if they are not also required for your application. Where fitted, the two serial on-board LEDs are visible on the underside of the VTAP50 board: Turning to the top of the VTAP50 board, you can identify the associated pads:...

  • Page 24: Optional External Antenna

    VTAP MOBILE WALLET READERS 5   Optional external antenna The VTAP50-OEM has an option to snap off the on-board antenna and connect an external antenna, with a suitable matching circuit, to the VTAP50 OEM module. Dot Origin can provide support for integrating external off-the-shelf or custom NFC antennas with VTAP50 OEM module readers.
  • Page 25 CAUTION: Always ensure sufficient clearance between the VTAP antenna and other RF transmitters to avoid electromagnetic interference between equipment. The clearance required varies from antenna to antenna, depending on antenna size, power and sensitivity. VTAP50 OEM MODULE © DOT ORIGIN PAGE 19 INSTALLATION GUIDE...

  • Page 26: Module Integration Instructions - Fcc/Ised

    6   Module integration instructions - FCC/ISED The VTAP50 OEM module has been designed to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference.

  • Page 27: Antennas

    A list of tested external antennas is provided in Annex . If any external antenna is attached to the VTAP50, that new arrangement will require a corresponding tuning circuit and FCC/ISED approval. Contact vtap- support@dotorigin.com for details about tuning circuits and FCC/ISED approval for the...

  • Page 28: Hardware Lock To Disable Usb Mass Storage Device

    USB mass storage device, only a keyboard (or keyboard and virtual COM port). When you remove the jumper across LOCK and restart the VTAP50, it will be detected as a USB mass storage device and you can make firmware or configuration changes again.

  • Page 29: Find Your Hardware Version

    VTAP MOBILE WALLET READERS 8   Find your hardware version If you need to report a problem with your VTAP50 or find the right reference diagram you will need to know your hardware version. If you can connect your VTAP50 to a PC, you can easily check the BOOT.TXT file.

  • Page 30: Disposal

    9   Disposal For safety and sustainability, it is the responsibility of the integrator to ensure that when equipment containing a VTAP50 reaches the end of its life, it is recycled in accordance with WEEE Regulations within the EU. VTAP50 (PCB and cables) should not be disposed of in general waste. If you wish to discard electrical and electronic equipment (EEE), please contact your supplier for further information.

  • Page 31: A  Tested External Antennas

    82mm x 22mm FCC/ISED certified Note: If any external antenna is attached to the VTAP50, that new arrangement will require a corresponding tuning circuit and EMC approvals. Contact vtap-support@dotorigin.com for details about tuning circuits and EMC approvals for the tested external antennas.
