COOLING THERMOSTAT Model PSY3 V1
DESCRIPTION
PSY3 is an air conditioning control thermostat. It controls a temperature and has three relays: compressor 30A, fan 5A, carter resistance 5A as well as a buzzer activation
due to an alarm. The sensor is a PTC scale -50 ÷ + 110 °C (-58 ÷ + 230 °F). The controller has a serial input and can connect to the KIOUR CAMIN modbus network for full
monitoring and data logging of the device.
STARTING UP THE DEVICE
At the startup of the device, the temperature controller performs a self-check for 7sec and the room's temperature is displayed. Do not touch the screen during self-check. By
pressing the two buttons
([
], [
we turn ON or turn OFF the controller (images
SWITCHING ON/OFF THE DEVICE
By pressing more than 3sec the button [
INDICATIONS AND BUTTON OPERATIONS OUTSIDE THE PARAMETER'S MENU
Indications
compressor ON
fan ΟΝ
resistance ON
locked keyboard
alarm ΟΝ
malfunction ON
PROGRAMMING THE PARAMETERS
By pressing [
] we enter or exit the parameter's menu.
The first parameter "SPo" is displayed and with the [
By pressing [SET] the value of the parameter is displayed and with the [
By pressing [
] or [SET] we confirm the new value and the name of the parameter is displayed.
TECHNICAL SPECIFICATIONS
Power supply: 230VAC 50/60Hz / Maximum power consumption: 3W
It is recommended to use an external fuse - power supply safety switch (not included): 0.5A
Cabinet's temperature sensor PTC 1Κ 25
Alarm buzzer / Serial Input
Relay compressor 250VAC 30A resistive load 2HP / Relays fan and resistance 250VAC 5A
Operating temperature: -15÷+70°C / Storage temperature: -20÷+80°C
The device is mounted through panel hole 29x71mm and is restrained with two plastic side brackets / Connection with terminal blocks 18A
IP protection 65 (on the front) / Device cleaning: Only neutral detergents and water are used
SERIAL INPUT
PSY3 can connect to the key programmer or to the data logger Mini Logger or to the KIOUR CAMIN network or to any modbus network.
 Key programmer: controller's parameter values can be saved or retrieved from the programming key. Plug in the programming key to the controller and press at the same
time [SET]+[
]. The device connects to the key and the message "Eo" is displayed. By pressing [
"ro" = read O.K. or "rF" = read Fail is displayed. By pressing [
displayed. In case of failure (rF or YF) reenter the key to the serial input and repeat the procedure from the beginning. The key can connect to all KIOUR devices. If you try
to read the parameters of a different device, message "rF" is displayed. At any time, we can perform the aforesaid operation. After 10sec the key is disconnected.
 Data logger Mini Logger: the controller is connected to the data logger via cable and by programming the parameter Add = 1. Automatically, based on selected minutes,
the data logger writes to a microSD memory card the controller's temperatures, status and alarms.
 CAMIN network: the controller can connect to the CAMIN network via an interface NET-INS-485. CAMIN is an PC software application designed to collect information,
watch and fully control a net of KIOUR devices while sending SMS and email in case of an alarm. The maximum length of the net can be 1000 meters.
] at the same time for 3 seconds the countdown starts and
below). The keyboard locks automatically after 50sec without activity.
] we switch ON or OFF .
button
], [
] we scroll into the parameters based on the parameter's table below.
C / Accuracy: 0.5°C
o
] the device uploads the parameters to the key and the message "Yo" = Write O.K. or "YF" = Write Fail is
the temperature controller unlocks
Operations outside the parameter menu
pressed once
enter parameter's menu
temperature scale °C/°F and mute the
buzzer
-
-
], [
] we adjust the value.
] the device downloads the parameters from the key and the message
(images
below). By pressing
pressed mode than 3 sec
-
device ON/OFF
-
-
[
] for 3sec
