MEDUMAT Standard
Ventilating the patient
Selecting emergency mode
1. Briefly press the On/Off button.
2. Select emergency mode:
• Emergency Paediatric
• Emergency Child
• Emergency Adult
Selecting previous patient
1. Briefly press the On/Off button.
2. Select Previous patient field.
If you do not select a menu within 20 seconds, the device automatically
switches to the Previous patient menu and immediately begins
ventilation of the patient. In this case, the device uses the ventilation
mode and ventilation parameters set for the last patient to be
ventilated. To switch off the countdown before the 20 seconds have
elapsed, move one of the navigation knobs.
Selecting a new patient
1. Briefly press the On/Off button.
2. Select New patient field.
3. Select height and gender or navigate
to the Height field and turn the
navigation knob further to select the
desired patient group.
4. Press the navigation knob next.
5. Select a ventilation mode.
6. If necessary: Adjust the ventilation
parameters and press start.
Changing the ventilation mode
Requirements:
• The device is switched on.
• A ventilation mode is set.
1. Briefly press the menu button.
2. Select the Mode field.
3. Select a ventilation mode.
4. Adjust the ventilation parameters
and press start.
© 2020 ORTUS TECHNOLOGY LTD. All Rights Reserved.
user guide
2
CPR mode
Performing CPR ventilation
Requirements:
• The device is switched on.
• The MEDUtrigger is connected to the device.
• A ventilation mode for a new patient is set.
1. Briefly press the CPR button.
The device switches to the mode CPR 30:2/CPR 15:2/CPR
IPPV (depending on the preset). The green LEDs on the
MEDUtrigger light up.
2. If necessary:
Change algorithm:
• 30:2
• 15:2
• Continuous
3. Press and hold the MEDUtrigger
button during the ventilation
phase until two mechanical
breaths are performed.
4. To exit the CPR mode, press the CPR button again.
Pausing the ventilation
Requirements:
• Cardiac rhythm analysis or
defibrillation is being performed.
• The device is switched on.
• The CPR mode is set.
• Continuous ventilation is activated.
1. Select the Pause field.
The ventilation is paused for 50 seconds.
RSI mode
Performing RSI ventilation
Requirements:
• The device is switched on.
• The MEDUtrigger is connected to the device.
• RSI was set as the ventilation mode for a new patient.
The Demand function is automatically activated.
1. For the function Manual,
navigate to the field Demand.
2. Select the Manual field.
3. To perform continuous
ventilation following successful
airway management, select the
Contin. field. The device
switches to IPPV mode.
To enable the selection of the function Manual, a MEDUtrigger must
be connected. Otherwise, this function will not be displayed.
