Summary of Contents for Ortus Aeonmed VG70
- Page 1 Aeonmed VG70(E) UK unboxing and setup instructions Version 1.0...
-
Page 2: Purpose Of This Document
VG70(E) • To provide a mechanism for registering VG70(E) products into the UK Support & Warranty cover provided by Ortus Medical * * Registration of product is required for any manufacturer backed support and warranty claims... - Page 3 VG70(E) UK Packaging The VG70(E) UK deliveries are packaged in two boxes: Box 1 (Smaller) • VG70(E) ICU Ventilator • VG70(E)Consumables/Accessories box • Dimensions (W x D x H) 81 x 69 x 115cm • Gross Weight 25kg / Net weight 15kg Box 2 (Larger) •...
- Page 4 Packing List / Inspection certificate Example Packing list • Within Box 1 is a Packing list and Inspection Certificate. • Please check off each item delivered from the Packing list when unboxing. • Items 23 and 24 are packaged in Box 2. •...
- Page 5 Assembly Instructions – Step 1 – Trolley Assembly • Unbox and remove packaging from the larger of the two boxes (Box 2) until the trolley as shown in photo 1-A. • The top of the trolley contains the ventilator mounting base plate. Unscrew the black locating screw from its transit position in photo 1-B and re-insert from under the trolley base plate as shown in photo 1-C.
- Page 6 Assembly Instructions – Step 2 – Main unit attachment to trolley • Unbox and remove the packaging from the smaller of the two boxes (Box 1) and separate into the three parts; Ventilator main unit, ventilator screen and the Accessories / Consumables box as shown in photo 2-A. •...
- Page 7 Assembly Instructions – Step 3 – Screen Attachment to Main unit • Remove the packaging from ventilator screen and place this on top of the main unit as shown in Photo 3-A. • Connect the ventilator screen display cable to the main unit and using a Philips screwdriver secure the cable with the small white cable clamp as shown in photo 3-B.
- Page 8 Assembly Instructions – Step 4 – Battery Installation • Rotate the ventilator on its cart around, such that the rear of the main unit can be accessed and remove the 4 Philips screws holding the battery cover in place (photo 4-A). •...
- Page 9 Assembly Instructions – Step 5 – Hospital Oxygen Connection • Locate the Oxygen Inlet filter from the accessories / consumables box; this is contained in a plastic bag which should be removed (photo 5-A). • Install the Oxygen Inlet filter at the rear of the Ventilator main unit, tightening the threaded connector until hand tight against the oxygen inlet ensuring it is orientated as in photo 5-B.
- Page 10 Assembly Instructions – Step 6 – Power Supply Connection • Locate the Two black power cords (1 x UK Mains Plug to IEC female connector and 1 x IEC female to IEC male connector) from within the accessories / consumables box and remove the cable ties (photo 6-A). •...
- Page 11 Assembly Instructions – Step 7 – Setup of Arm for Patient Circuits • Included in the accessories / consumables box is a Patient circuit support arm (large brown box) packaged as shown in photo 7-A, and a small black house mounting bracket also shown in photo 7-A. •...
- Page 12 Assembly Instructions – Step 8 – Setup of included Humidifier • The VG70(E) is supplied with a Humidifier to ensure that it can be used out of the box to treat patients (the supplied configuration should be reviewed by local operators as it may lack features depending on intended use). •...
- Page 13 Assembly Instructions – Step 9 – Setup of included Patient Circuit • The VG70(E) is supplied with a Reusable Patient circuit to ensure that it can be used out of the box to treat patients (the supplied configuration should be reviewed by local operators prior to us as it may not meet their requirements).
- Page 14 Annex A – Typical VG70(E) Accessory / Consumables box contents – Key components 1. Humidifier 2. Arm for Patient circuit 3. Humidifier Chamber 4. Test Lung 5. Patient Hose Circuit 6. IEC female to IEC male connector 7. UK Mains Plug to IEC female connector 8.
- Page 15 Annex B – Typical VG70(E) Accessory / Consumables box contents – Spares/Additional Items 1. 2 x Spare Breathing Bacterial Filters 2. Nebulizer set with tubing 3. Airway connector 4. Air Inlet Filter element 5. User Manual 6. Circuit hose support bracket (small) 7.
- Page 16 Annex C - Product Acceptance Test Log Completion Once assembled in order to register the product please complete the VG70 Acceptance log and email a copy medsupport@ortus.co.uk within 30 days The VG70 Acceptance log (example left) can be downloaded here: http://www.theortusgroup.com/vg70/...
