Aston Global SEN984.00-72 Installation And Owner's Manual

Shower enclosure
Hide thumbs

Advertisement

Quick Links

Download this manual
IN TALLATION AND-
NER'
MANUAL
h - er En le ure Model Number: EN9" .00-72''x35''
Please carefully read these instructions before you begin to install the products.
IMPORTANT:
ASTON reserves the right to alter, modify or redesign products at any time without prior notice. For the
latest up-to-date technical drawings,manuals,warranty information or any other details, please refer to the
HYPERLINK http://www.astonbath.com/ www.astonbath.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the SEN984.00-72 and is the answer not in the manual?

Questions and answers

Related Manuals for Aston Global SEN984.00-72

Summary of Contents for Aston Global SEN984.00-72

  • Page 1 IN TALLATION AND- NER' MANUAL h - er En le ure Model Number: EN9" .00-72''x35'' Please carefully read these instructions before you begin to install the products. IMPORTANT: ASTON reserves the right to alter, modify or redesign products at any time without prior notice. For the latest up-to-date technical drawings,manuals,warranty information or any other details, please refer to the HYPERLINK http://www.astonbath.com/ www.astonbath.com...

  • Page 4: Before You Start

    Before you start Thank you for purchasing our shower enclosure. We hope it will provide you with years of satisfying use and enjoyment. Please read this manual carefully because it contains information and instructions about the proper installation of the unit. If you do not follow certain conditions of installation and maintenance, your warranty may be affected.
  • Page 5 Detailed Diagram of Shower Door Components \11 111111> M4x40 =717\ x..,; \11111111> M5x40 111111111> ::JJ::P M4x40 ��x3J Number Description Number Description Door Stopper Bumper Strip Anti-water Strip Top Rail Door Handle Large Fixed Glass Sliding Door Screw Pack 1 Rail End Screw Pack 2 Screw Pack 3 Wall Mount...
  • Page 6 view drawing to identify all parts in the parts listing. Before discarding the packaging check for any parts or small hardware bags that may have been overlooked.
  • Page 7 Installation Guide Please read and follow the installation instructions and guidelines in this section. Failure to follow the recommended instructions and installation techniques may lead to possible damage to the unit or the surrounding area. This can affect warranty claims. ATTENTION: This unit requires assembly.
  • Page 8 Reverse Door opening This shower enclosure can be assembled so that the sliding door opens from Left to Right, or Right to Left. The drawings below illustrate the shower door opening from Left to Right. Note the location of the fixed glass panel and return glass panel for the shower door opening from Left to Right.
  • Page 9 Shower Door Installation Install all of the wall material or materials you intend to use before installing the glass clamps and return glass panel, this includes all moisture resistant wall board or rock board, tile, stone or other wall covering. ATTENTION: A minimum of two people are required for the next assembly steps.
  • Page 10 3. Remove pre-installed screw from pre-assembled Glass Clamp (7). Attach the Glass Clamps (7) to wall and shower floor using M4x40 screws in Screw Pack 1. The Glass Clamps (7) should be positioned so that the single hole is facing toward the inside of shower.
  • Page 11 5. Measure the width of the shower opening at the top between the fixed glass and the wall. Note this is dimension "X". See Fig.5 for details. 6. The following equation is used to determine the length to be cut from the rail in order to fit the shower opening.
  • Page 12 7. Slide Door Stopper (1) onto end of Top Rail (2). The bumpers on Door Stopper (1) should be positioned on the top of Top Rail for final installation. Note: One door stopper comes pre-assembled on top rail between fixed glass bolt assembly. See Fig.
  • Page 13 Fig. 11...
  • Page 14 Position the top rail/ fixed glass assembly into place in your shower. Loosen the set screws in rail mount next to Return Glass Panel (23). Next connect rail mount to stainless steel fitting by threading rail mount and stainless steel fitting together and tighten into place.
  • Page 15 Loosen set screws in Rail End (5) and remove from Top Rail (2). Next remove Wall Mount (6) from Rail End (5). Position Wall Mount (6) onto marked location on shower wall and mark pilot hole drilling location. NOTE: If your surface is prone to cracking or chipping then it is recommended that you pilot drill first using a smaller drill bit, and then step up...
  • Page 16 The set screw Slide Rail End (5) onto Top Rail (2) and locations in rail end loosely tighten into place. Note: The set are not centered. screws in rail end are not centered, and one Assemble per end of rail end is threaded. The Rail End drawing.
  • Page 17 Fig. 21...
  • Page 18 \(-2 Remove the set screw from the back of Small Fixed Glass Bolt Assembly (21). - d_ Place the Small Fixed Glass Bolt Assembly (21) on the top rail between the Rail End (5) and Door stopper (1). _}\_ Loosely tighten the set screw. See Fig.22 for details.
  • Page 19 Remove the Small Fixed Glass (19) from (2), Top Rail and set the Small Fixed Glass (19) aside. Using the appropriate drill bit for your ¾ 6 " base surface drill hole locations with diameter drill bit and install the plastic Fig.
  • Page 20 Insure plastic sliding door glide is in place in underside of Sliding Door Track Divider (8) and positioned to proper location for 10mm glass thickness. See Fig.28 for details. Fig. 28 Position the Sliding Door Track Divider (8) into position as seen in Fig.29 and mark the 2 shower base hole positions.
  • Page 21 Assemble the Upper Roller Assemblies (9) onto Sliding Door (4). -=:- Note: The door handle mounting holes ( 0) should be positioned to left. The Upper Roller Assemblies (9) will be on the outside ®j of Sliding Door (4). The sliding door should be to the inside of shower area.

  • Page 22: End View

    The rollers for this unit have a built in cam adjustment to adjust the plumb of sliding of roller assembly door. using the small hex, Locate the small hole in outside edge of while holding the roller assembly and insert a small hex large hex wrench wrench into hole opening.
  • Page 23 The Door Threshold is used to prevent water from seeping out while bathing. Install the threshold according to these instructions. Measure the distance between the Small Fixed glass (20) and the Large Fixed Glass (3). See Fig.36 for details. Fig.36 Cut the threshold bar (11) to to the size of : (X) -1'1/4".Remove any sharp edges or burrs after cutting Door Threshold bar...
  • Page 24 Add a small amount of silicone sealant to bottom of threshold bar assembly and place into position. See Fig.40 for details. Fig.40 Using the hardware from screw pack 3 install the threshold bar assembly. Install the decorative screw plug covers into Threshold End Caps (12).
  • Page 25 Adjust both door Stoppers (1) to ensure they are positioned upright and the Glass Door (4) can move to the maximum opening and closing range. Tighten the set screws in Door Stopper (1) to fasten them in place on Top Rail (2). Fig.

  • Page 26: Care And Maintenance

    Care and Maintenance As with any other luxury item, maintenance and care are critical to the long lasting quality and enjoyment of your shower door and tray. The proper care and maintenance outlined in this section are necessary to ensure the longevity of the unit.
  • Page 27 ASTON GLOBAL INC. - Limited Warranty This warranty applies to products purchased from Aston Global Inc. after May 1, 2017. Aston Global Inc., a Texas Corporation ("Aston"), provides the following warranty coverage for shower doors and enclosures, bathtubs, shower panels and related components (The Products).
  • Page 28 PARTS ONLY WARRANTY This warranty is extensive in that it covers replacement of all defects. LABOR CHARGES AND/OR DAMAGE INCURRED DURING INSTALLATION, REPAIR, OR REPLACEMENT, AS WELL AS ANY OTHER KIND OF ANCILLARY COST, LOSS OR DAMAGE ARE EXCLUDED. COMMERCIAL USE AND OTHER EXCLUSIONS This warranty excludes all industrial, commercial and business usage.
  • Page 29 Aston product installations and repairs must be performed by either an Aston authorized agent or a licensed, insured and experienced professional contractor - installation or repairs performed by any other party shall void the warranty. This warranty shall not apply to breakage or damages caused by normal wear and tear, fault, carelessness, abuse, misuse, misapplication, improper maintenance, alteration or modification of the unit, as well as chemical or natural corrosion, accident, fire, flood, act of God or any other...
  • Page 30 RESIDENTIAL INSTALLATIONS SHOWER DOORS and ENCLOSURES GLASS: Limited Lifetime Aston warrants the glass of shower doors, tub doors and shower enclosures to be free from defects in workmanship and materials under normal residential use for the life of the product. StarCast Protective Coating by EnduroShield: Ten (10) Years, provided by PCT Global LLC.
  • Page 31 DRAIN, OVERFLOW AND ACCESSORIES: Limited Lifetime Aston warrants the freestanding tub Drain, Overflow and Accessories in Polished Chrome and Brushed Stainless Steel finishes to be free from defects in workmanship and materials under normal residential use for two (2) years. The warranty for any part in Oil-rubbed Bronze finish shall be limited to one (1) year.
  • Page 32 HARDWARE: One (1) Year Aston warrants shower door, tub door and shower enclosure hardware (i.e. handles, rollers, hinges, profiles, clips, guides, brackets, towel and support bars) to be free from defects in workmanship and materials under normal commercial use for one (1) year. SHOWER BASES: One (1) Year Aston warrants shower bases to be free from defects in workmanship and materials under normal commercial use for one (1) year.
  • Page 33 SHOWER PANELS: One (1) Year Aston warrants shower panels to be free from defects in workmanship and materials under normal commercial use for a period of one (1) year from the initial date of purchase. STEAM SHOWERS: One (1) Year Aston warrants steam showers panels to be free from defects in workmanship and materials under normal commercial use for a period of one (1) year from the initial date of purchase.
