HUAWEI 4G Router B311s-220
V100R001
Product Description
Issue
01
Date
2017-12-12
HUAWEI TECHNOLOGIES CO., LTD.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the B311s-220 and is the answer not in the manual?

Questions and answers

Related Manuals for Huawei B311s-220

Summary of Contents for Huawei B311s-220

  • Page 1 HUAWEI 4G Router B311s-220 V100R001 Product Description Issue Date 2017-12-12 HUAWEI TECHNOLOGIES CO., LTD.
  • Page 2 Notice The purchased products, services and features are stipulated by the contract made between Huawei and the customer. All or part of the products, services and features described in this document may not be within the purchase scope or the usage scope. Unless otherwise specified in the contract, all statements, information, and recommendations in this document are provided "AS IS"...
  • Page 3 The document is an invitation to offer but not an offer. It is intended to describe the general features and functions of a product. The features and functions of certain products may vary with the requirements of customers. History Issue Date Details 2017-12-12 Initial official release. Huawei Proprietary and Confidential Issue 01 (2018-05-10) Copyright © Huawei Technologies Co., Ltd.
  • Page 4 High Speed Packet Access HSPA+ High Speed Packet Access Evolution GPRS General Packet Radio Service Global System for Mobile Communications IEEE Institute of Electrical and Electronics Engineers Huawei Proprietary and Confidential Issue 01 (2018-05-10) Copyright © Huawei Technologies Co., Ltd.
  • Page 5 RTCP Real-time Transport Control Protocol Real-time Transport Protocol SAMBA System for Advanced Mobile Broadband Applications Secondary Component Carrier Service Control Point SDRAM Synchronous Dynamic Random Access Memory Huawei Proprietary and Confidential Issue 01 (2018-05-10) Copyright © Huawei Technologies Co., Ltd.
  • Page 6 Wireless Encryption Protocol Wi-Fi Wireless Fidelity Wi-Fi Multimedia WPA/WPA2-PSK Wi-Fi Protected Access/Wi-Fi Protected Access II - Pre-Shared Key WPA2-PSK Wi-Fi Protected Access II - Pre-Shared Key Wi-Fi Protected Setup Huawei Proprietary and Confidential Issue 01 (2018-05-10) Copyright © Huawei Technologies Co., Ltd.

  • Page 7: Table Of Contents

    3.6.2 IPv6 Only (CLAT) ..............................13 3.7 Multi-APN .................................. 13 3.8 HiLink ..................................14 3.9 Customer management ............................... 14 3.9.1 WebUI ..................................14 3.9.2 HUAWEI SmartHome APP ............................. 14 3.10 Operator maintenance ............................... 15 3.11 HOTA ..................................15 Huawei Proprietary and Confidential Issue 01 (2018-05-10)
  • Page 8 5.1.1 Standards and Communication Protocols of the Product ..................18 5.1.2 Standards and Communication Protocols of the Wireless Uu Interface ..............18 6 Packing List ..........................19 Huawei Proprietary and Confidential Issue 01 (2018-05-10) Copyright © Huawei Technologies Co., Ltd.

  • Page 9: Product Overview

    Product Description 1 Product Overview Product Overview The HUAWEI 4G Router B311s-220 is a Long Term Evolution (LTE) wireless gateway for multiple users in household or small office environments. It enables users to access the Internet. The B311s-220 supports 3GPP Release 9 with UE downlink/uplink category 4. The supported service functions are as follows: ...

  • Page 10: Technical Specifications

    HUAWEI 4G Router B311s-220 Product Description 2 Technical Specifications Technical Specifications 2.1 Hardware Specifications Table 2-1 Technical specifications of the B311s-220 main unit Item Description Technical 3GPP Release 9 standard IEEE 802.3/802.3u WLAN IEEE 802.11b/g/n Working B1/B3/B7/B8/B20 band/frequency UMTS B1/B8...
  • Page 11 Flash slowly: A pairable HiLink device is detected. Flash quickly: HiLink pairing is in progress. Off: Wi-Fi is disabled.  The indicator starts to flash slowly only when B311s-220 detects a new HiLink device.  HiLink devices include Honor routers, Honor set-up boxes, Honor handsets (EMUI 5.0 and later), and more.

  • Page 12: Antenna Specifications

    2.2.1 Build-in LTE Antenna Table 2-2 LTE antenna specifications Item Description Frequency FDD LTE  B1: UL 1920–1980 MHz DL 2110–2170 MHz  B3: UL 1710–1785 MHz DL 1805–1880 MHz Issue01 (2018-05-10) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 13 B8: -3 dB  B20: -2 dB UMTS:  B1: -2.5 dB  B8: -3 dB Main antenna gain LTE:  B1/B3/B7B8/B20: 1~2 dBi UMTS:  B1/B8: 1~2 dBi Issue01 (2018-05-10) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 14: Build-In Wi-Fi Antenna

    APN management network APN auto adapter Gateway Router  Supports the default route: 0.0.0.0.  Supports manual configuration of LAN IP addresses.  Supports Address Resolution Protocol (ARP). Issue01 (2018-05-10) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 15  EDGE: DL 236.8Kbps, UL 236.8 Kbps  GPRS: DL 85.6 Kbps, UL 85.6 Kbps WLAN 802.11b/g/n Supports multi APNs (Optional, one for data, and one for TR-069). Issue01 (2018-05-10) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 16 Supports export of current diagnosis results and operation logs.  HUAWEI View data traffic usage and SMS. SmartHome  Manage connected devices.  Change CPE's SSID and password. Issue01 (2018-05-10) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 17 All major versions of Chrome in the last year (53.0 with latest updates).  Safari 10.0 with latest updates (MACOS). Your computer's hardware system should meet or exceed the recommended system requirements for the installed OS version. Issue01 (2018-05-10) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 18: Services And Applications

    3.1 Data Services The B311s-220 can access the Internet through mobile networks and Ethernet networks. By connecting to the B311s-220 using Wi-Fi or a network cable, users can obtain access to high-speed Internet services and establish a local area network (LAN).

  • Page 19: Accessing The Internet Through An Ethernet Network

    Product Description 3 Services and Applications 3.1.2 Accessing the Internet through an Ethernet Network The B311s-220's LAN/WAN port can be connected to a wall-mounted Ethernet port using a network cable. Figure 3-2 Accessing the Internet through an Ethernet network 3.2 SMS The B311s-220 supports message writing/sending/receiving and group sending (up to 50 -contacts at a time).

  • Page 20: Wi-Fi Authentication

    Internet LTE VPN Client VPN Server L2TP/ PPTP 3.4.2 VPN Pass-Through The B311s-220 supports L2TP/PPTP/IPsec VPN pass-through for the LAN side device. The LAN side device can create a VPN tunnel to the VPN server. VPN Tunnel Internet L2TP VPN Client...

  • Page 21: Ipv6 Only And Ipv4V6 Dual Stack

    However, IPv6 devices are not affected. 3.7 Multi-APN The B311s-220 supports the establishment and maintenance of three APNs. These three APN connections isolate data, and remote management services on an operator's network. The B311s-220 supports an independent APN for CPE internal/VoIP/TR-069.

  • Page 22: Hilink

    3.9.2 HUAWEI SmartHome APP Scan the QR code (can be found in the Quick Start Guide and Web UI), or search for Huawei SmartHome in the Google Play Store or Apple App Store to download the HUAWEI SmartHome APP and configure the router from your phone.

  • Page 23: Operator Maintenance

    The B311s-220 supports Operator maintenance through the TR-069. Operator remote manages the CPE software update/parameters configuration via TR-069. 3.11 HOTA The B311s-220 supports the HOTA feature, which allows users to remotely update the device firmware through the HOTA server. Issue01 (2018-05-10) Huawei Proprietary and Confidential Copyright ©...

  • Page 24: System Structure And Scenario Constraints

    Figure 4-1 System structure The following describes the modules shown in Figure 4-1.  LTE access function: The B311s-220 adopts the LTE access technology at the WAN side.  LAN access function: One 10/100/1000 Mbps high-speed Ethernet ports are provided at the LAN side.

  • Page 25: Scenario Constraints

    (SOHOs). The B311s-220 is not an enterprise-grade product. It cannot be used by medium- or large-sized enterprises or in scenarios with high network reliability requirements, such as banks, securities agencies, traffic control, and communications device backhaul.

  • Page 26: Technical References

    RFC792, RFC950, RFC1256 RFC793 RFC768 DHCP RFC1531, RFC1533 RFC1631, RFC2663, RFC3022, RFC3027 VoIP RFC3261,RFC2327,RFC1889,RFC1890,RFC3550 5.1.2 Standards and Communication Protocols of the Wireless Uu Interface This device supports 3GPP Release 9. Issue01 (2018-05-10) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 27: Packing List

    Quantity Remarks Wireless Gateway Standard Power supply adapter Standard Quick Start Standard Ethernet cable Standard Warranty card Optional The HUAWEI B311s-220 wireless gateway has an optional external antenna. Issue01 (2018-05-10) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
