Operating Instructions
Vacuum type leak detector
Type: Eurovac 04-1 (LAZ-04/1)
Product No.: 43660
Technical Approval of the German
Institute for Building Technology: Z-65.22-4
Read instructions before using device!
Observe all safety information!
Keep instructions for future use!
Version: 12.2007
ID No.: 854.001.0108
Mess-, Regel- und
Überwachungsgeräte
für Haustechnik,
Industrie und Umweltschutz
Lindenstraße 20
DE-74363 Güglingen
Telefon: +49(0)7135-102-0
Service: +49(0)7135-102-211
Telefax: +49(0)7135-102-147
E-Mail: info@afriso.de
Internet: www.afriso.de
Leak detectors
Z-65.22-4
