- Page 1 The instruction manual is an integral part of the product Wood burning stove E530 T ST INSTRUCTIONS FOR INSTALLATION, USE AND MAINTENANCE...
- Page 2 TRONIC FORMAT on our company website (www.piazzetta.com), under “Products”, on the specific product characteristics page. This document is the property of Gruppo Piazzetta S.p.A. and no part of it may be reproduced or disclosed to third parties, whol- ly or in part, without written permission All rights reserved by Gruppo Piazzetta S.p.A..
-
Page 3: Table Of Contents
INSTRUCTIONS FOR INSTALLATION, USE AND MAINTENANCE CONTENTS GENERAL INFORMATION PRODUCT INFORMATION Product description Part identification Product identification data Characteristics Accessories upon request Technical data Sizes FUEL GENERAL INFORMATION REGARDING THE SYSTEM Installation room Fresh air intake Chimney Chimney terminal Flue pipe PREPARATIONS FOR INSTALLATION Handling Unpacking... -
Page 4: General Information
(authorized technical assistance centre). in the sections " FAULTS " or " MESSAGES - - Gruppo Piazzetta S.p.A. cannot be held liable for situations of SAFETY WARNINGS - ANOMALIES ". risk, defects, damage, product malfunctioning or for damage... - Page 5 INSTRUCTIONS FOR INSTALLATION, USE AND MAINTENANCE Product use may cause some surfaces to During the operation and/or cooling phase, become extremely hot (the glass, the exter- slight creaking noises may be heard. This nal surfaces, the handles, the smoke outlet is not considered a defect, but is a conse- passage).
-
Page 6: Product Information
INSTRUCTIONS FOR INSTALLATION, USE AND MAINTENANCE PRODUCT INFORMATION Do not use the appliance as an incinerator or in any way other than that for which it was designed. PRODUCT DESCRIPTION Do not use the appliance if the glass or seals ■... -
Page 7: Part Identification
INSTRUCTIONS FOR INSTALLATION, USE AND MAINTENANCE PART IDENTIFICATION Combustion air control (secondary) Combustion chamber Metal structure Ceramic glass Door handle Door Smoke deflector Smoke deflector (in Skamolex) Back panel (in Skamolex) 10 Side panel (in Skamolex) 11 Grille 12 Grate 13 Ash drawer 14 Combustion air control (primary) 15 Cladding... -
Page 8: Product Identification Data
INSTRUCTIONS FOR INSTALLATION, USE AND MAINTENANCE PRODUCT IDENTIFICATION DATA CHARACTERISTICS Each product is identified in the following way: Structure: - IDENTIFICATION DATA PLATE (1) with the model (A) and ap- - in steel pliance performance specifications Cladding: - SERIAL NUMBER PLATE (2) with the serial number of the ap- - in painted steel pliance (B) Firebox:... -
Page 9: Technical Data
INSTRUCTIONS FOR INSTALLATION, USE AND MAINTENANCE TECHNICAL DATA Model E530 T ST Type SL270-02 (n4) Unit of meas- Description at nominal heat output urement Fuel Wood logs Type of appliance (Designation) Heat Output Heat input Space heat output Hourly fuel consumption kg/h 2,19 Efficiency... -
Page 10: Sizes
INSTRUCTIONS FOR INSTALLATION, USE AND MAINTENANCE (values in mm) SIZES E530 T ST Fig. 4 2123 1220 150 mm A Smoke outlet DT2006746_H072744EN0_00... -
Page 11: Fuel
INSTRUCTIONS FOR INSTALLATION, USE AND MAINTENANCE Unsuitable fuel FUEL Never use damp wood or wood with pitch. The following must not be used: waste (refuse), waste paper, pa- The characteristics and quality of the wood considerably affect per briquettes, plywood or chipboard, fibrous panels, packaging, product autonomy, efficiency, atmospheric emissions and correct painted wood or wood covered with synthetic material, plastic product operation. -
Page 12: General Information Regarding The System
INSTRUCTIONS FOR INSTALLATION, USE AND MAINTENANCE GENERAL INFORMATION The existence of more than one appliance is only per- REGARDING THE SYSTEM mitted if allowed by the regulations and manufacturer of each individual appliance. Below is some general information regarding the system, appli- If the existence of more than one appliance is permit- ■... -
Page 13: Fresh Air Intake
INSTRUCTIONS FOR INSTALLATION, USE AND MAINTENANCE The connecting pipe for the combustion air inlet of the appliance must comply with the following requirements: In the appliance installation room: - have a diameter equal to or greater than the diameter of the it is not permitted to install liquid fuel appliances with ■... -
Page 14: Chimney Terminal
INSTRUCTIONS FOR INSTALLATION, USE AND MAINTENANCE CHIMNEY TERMINAL The chimney terminal is the part which is positioned on the top of the flue to ease the dispersion of combustion products into the atmosphere. In brief, remember that the chimney terminal: - must have a useful outlet section of not less than twice that of H (*) the flue... - Page 15 INSTRUCTIONS FOR INSTALLATION, USE AND MAINTENANCE The connecting flue pipe must not cross rooms where it is prohibited to install combustion appliances, nor in other rooms divided into compartments for fire or with the hazard of fire, or in rooms and/or spaces that can- not be inspected.
-
Page 16: Preparations For Installation
INSTRUCTIONS FOR INSTALLATION, USE AND MAINTENANCE After having removed the material protecting the appliance, re- PREPARATIONS FOR INSTALLATION move all the retainers securing the appliance to the pallet and then remove it from the pallet. Product installation and maintenance must be carried out exclusively by qualified personnel with sufficient knowledge of the product itself. -
Page 17: Installation
INSTRUCTIONS FOR INSTALLATION, USE AND MAINTENANCE INSTALLATION Keep any combustible or heat-sensitive products such as wooden furniture, curtains, carpets, fabric, clothing, ornaments and flammable liquids well away from the For all installation and maintenance interventions product while it is in operation (where not indicated, which require access to inside the cladding, the smoke minimum of 100 cm). -
Page 18: Installation Kit And Accessories
Additional requirements for the connecting flue pipe For the installation of any KIT and ACCESSORIES, please Gruppo Piazzetta S.p.A. supplies pipes and bends for the connect- refer to the instructions provided with the kits or acces- ing flue pipe, all of which are approved and specifically sized for sories. -
Page 19: Start-Up And Operating Test
INSTRUCTIONS FOR INSTALLATION, USE AND MAINTENANCE START-UP AND OPERATING TEST BEFORE STARTING-UP THE APPLIANCE A start-up and operational test must be carried out by a special- ized qualified technician to check that the appliance and all other Before commissioning the appliance: connected system elements operate correctly. -
Page 20: Information Regarding The First Start-Up
INSTRUCTIONS FOR INSTALLATION, USE AND MAINTENANCE 10.1 INFORMATION REGARDING THE FIRST 10.2 OPENING THE DOOR START-UP Only open the door during operation to load fuel and when there are only embers on the grate. Before the first start-up, remove all accessories supplied Opening the door when there is a lively or intense (see the “... -
Page 21: Combustion Air Control
INSTRUCTIONS FOR INSTALLATION, USE AND MAINTENANCE 10.3 COMBUSTION AIR CONTROL The flame, combustion duration and quality and appliance ther- mal power are all determined by adjusting the combustion air. Given that combustion varies according to the type of fuel used, its size, the load mass, the system characteristics, the chimney vacuum and the atmospheric and climatic conditions, experience will teach you which is the most suitable setting. - Page 22 INSTRUCTIONS FOR INSTALLATION, USE AND MAINTENANCE Start-up Fuel load Load the firebox as follows: When a sufficient bed of embers has formed, proceed to load - set the combustion air control to the start-up position (refer to more fuel: the section " COMBUSTION AIR CONTROL ") - make sure that any controls or smoke regulating valves in the - make sure that any controls or smoke regulating valves in the product or system are open...
-
Page 23: Fuel Dimensions And Layout
INSTRUCTIONS FOR INSTALLATION, USE AND MAINTENANCE 10.6 OVERHEATING AND SHUTTING DOWN Do not open the firebox door during operation. In the case of overheating or if any parts of the appliance or con- Do not introduce liquid fuel into the appliance, even if ■... -
Page 24: Cleaning And Maintenance
INSTRUCTIONS FOR INSTALLATION, USE AND MAINTENANCE 11.1 SCHEDULED MAINTENANCE 11 CLEANING AND MAINTENANCE Scheduled maintenance must be carried out at least For all installation and maintenance interventions ONCE A YEAR and in any case, before the commission- which require access to inside the cladding, the smoke ing of the appliance after a long period of inactivity. -
Page 25: Cleaning The Painted Metal Parts
INSTRUCTIONS FOR INSTALLATION, USE AND MAINTENANCE 11.3 CLEANING THE GLASS Recommended interval Interventions which may be carried out by the user During start-up it is possible that tar may accumulate on the glass which will disappear when optimal combustion is reached. If this Glass 1 day does not happen, it is recommended that the glass is cleaned dai-... - Page 26 INSTRUCTIONS FOR INSTALLATION, USE AND MAINTENANCE - turn the side panel (1) 11.5 CLEANING THE SMOKE CHAMBER A vacuum cleaner which is suitable for use with ash is needed when carrying out this type of cleaning oper- ation. For the disposal of ashes, please refer to the section DISPOSAL OF ASHES ".
-
Page 27: Disposal Of Ashes
INSTRUCTIONS FOR INSTALLATION, USE AND MAINTENANCE - lift and support the smoke deflectors (3) 11.6 DISPOSAL OF ASHES - turn the smoke deflectors (3) one at a time by turning the bot- tom part outwards Ash from natural (non-treated) wood burned in stoves or open fireplaces is composed mainly of calcium, silicon, potassium and magnesium. -
Page 28: When Not In Use
INSTRUCTIONS FOR INSTALLATION, USE AND MAINTENANCE 12 WHEN NOT IN USE 13 FAULTS When shutting the appliance down at the end of the season or if a long period of inactivity is anticipated, proceed as follows: All work is to be carried out when the fire is out, the - clean the firebox and remove ash from the appliance appliance has cooled down completely and with the - carry out all the operations described in the section "... - Page 29 INSTRUCTIONS FOR INSTALLATION, USE AND MAINTENANCE Smoke escapes from the firebox in adverse weather Condensation forms conditions POSSIBLE CAUSES ACTION POSSIBLE CAUSES ACTION Interventions which may be carried out by the user Operations which require the intervention of the T.A.C. Start-up procedure not suffi- Refer to the section “...
- Page 30 INSTRUCTIONS FOR INSTALLATION, USE AND MAINTENANCE The firebox does not heat up Noisy fan (if present) POSSIBLE CAUSES ACTION POSSIBLE CAUSES ACTION Interventions which may be carried out by the user Operations which require the intervention of the T.A.C. The amount of fuel used is in- Use the amount of fuel indicat- Powder or foreign bodies in Checking and cleaning the fan...
-
Page 31: Disposal Of Product At End Of Product Life
INSTRUCTIONS FOR INSTALLATION, USE AND MAINTENANCE 14 DISPOSAL OF PRODUCT AT END OF PRODUCT LIFE The owner is exclusively responsible for destroying and disposing of the product in compliance with the regulations in force as re- gards safety and respecting/protecting the environment. Contact the relevant authorities for information regarding local regulations. -
Page 32: Reference Standards
INSTRUCTIONS FOR INSTALLATION, USE AND MAINTENANCE 15 REFERENCE STANDARDS Country of application: The European Union EN 1443 Chimneys - General requirements EN 1457-1 Chimneys - Clay/ceramic flue liners - Part 1: Flue liners operation under dry conditions – Requirements and test methods EN 1457-2 Chimneys - Clay/ceramic flue liners - Part 2: Flue liners operating under wet conditions - Requirements and test... -
Page 33: Appendix
INSTRUCTIONS FOR INSTALLATION, USE AND MAINTENANCE 16 APPENDIX Identification data plate: key Please read and comply with the instructions for installation, use and maintenance. Model = Model Type = Type DoP = Declaration of performance Design.App. = Type of appliance (Designation) N.Body = Notified body Pnom = Nominal heat output Ppart = Part load heat output... - Page 34 INSTRUCTIONS FOR INSTALLATION, USE AND MAINTENANCE DT2006746_H072744EN0_00...
- Page 35 INSTRUCTIONS FOR INSTALLATION, USE AND MAINTENANCE DT2006746_H072744EN0_00...
