- Page 1 EM-TF-BB-AM5728 Hardware User Manual V1.0...
- Page 2 Technology Co. Ltd. ⚫ Shenzhen Emtop Technology has the copyright of this document and reserves all rights. Any part of the document should not be modified, distributed or duplicated in any approach and form with the written permission issued by Emtop Technology Co., Ltd.
- Page 3 EM-TF-BB-AM5728-HardwareUM-V1.0 Version History Version Description Author Date V1.0 Initial Jack Lei 2018.07.12 2 / 52...
-
Page 4: Table Of Contents
EM-TF-BB-AM5728-HardwareUM-V1.0 Content 1. Product Overview ..........................1 1.1 Brief introduction............................1 1.2 Block Diagram ..............................1 1.3 Packing List ..............................2 1.4 Product Features ............................2 1.5 Board Component Locations ......................... 2 1.6 Product Dimensions ............................4 1.7 Component Height............................5 1.8 B2B Connector Specification.......................... - Page 5 EM-TF-BB-AM5728-HardwareUM-V1.0 2.2.11 mini PCIe ..................................31 2.2.12 mSATA ..................................33 2.2.13 PCIe .................................... 35 2.2.14 DIDO ................................... 37 2.2.15 Button..................................38 2.2.16 DIP Switch ................................... 39 2.2.17 LED....................................40 2.2.18 RTC ..................................... 40 2.2.19 BEEP ................................... 40 2.2.20 Expansion Interface ..............................41 3.
-
Page 6: Product Overview
It is based on TI AM572x SOC evaluation board. In the small size of EM-TF-SOM-AM5728 board but there are many resources in the EM-TF-BB-AM5728 board, the interface include Giga Ethernet, USB2.0, USB3.0, HDMI, Audio, PCIE, mini PCIE, mSATA, LCD, Camera, Micro SD card, CAN, RS485, DIDO, GPMC. Also there are SPI, I2C, UART, GPIO bus in the expansion pin header. -
Page 7: Packing List
EM-TF-BB-AM5728-HardwareUM-V1.0 1.3 Packing List 1X EM-TF-SOM-AM5728 1X EM-TF-BB-AM5728 1X Quick Start Guide 1X Power Supply(Option) 1.4 Product Features Electrical Features Operating Temperature: -40~85°C（Industrial）. Power Supply: 7-28V/12V@2A（Power Adapter） Operating Humidity: 20% ~ 90%（no condensation） Interface 1X DC Jack + 1X2PIN 3.81mm Terminal Block 2X Giga Ethernet（RJ45）... - Page 8 EM-TF-BB-AM5728-HardwareUM-V1.0 Figure1- 2 EM-TF-BB-AM5728 Top 3 / 52...
-
Page 9: Product Dimensions
EM-TF-BB-AM5728-HardwareUM-V1.0 Figure1- 3 EM-TF-BB-AM5728 Bottom 1.6 Product Dimensions 4 / 52... -
Page 10: Component Height
EM-TF-BB-AM5728-HardwareUM-V1.0 Figure1- 4 PCB Dimension (Unit: mm) 1.7 Component Height 5 / 52... -
Page 11: B2B Connector Specification
Chapter2. Hardware System Description This section mainly descripted the structure and the interface of the hardware system. 2.1 Installation and BOOT 2.1.1 Installation Install the EM-TF-SOM-AM5728 board on the EM-TF-BB-AM5728 board correctly. And connect the device that used. 6 / 52... - Page 12 EM-TF-BB-AM5728-HardwareUM-V1.0 Figure2- 1 Assembly 7 / 52...
-
Page 13: Boot Setting
EM-TF-BB-AM5728-HardwareUM-V1.0 Figure2- 2 Device connection 2.1.2 BOOT Setting EM-TF-BB-AM5728 can be set the system boot from Micro SD card or eMMC. But it boot from Micro SD card default. 2.2 2.2 Interface Description This section descripted all function blocks and the signals definition on the connector in detail, in order to be understood the EM-TF-BB-AM5728 board. - Page 14 EM-TF-BB-AM5728-HardwareUM-V1.0 Figure2- 3 B2B Connector Location Signals definition on the B2B Connector 9 / 52...
- Page 15 EM-TF-BB-AM5728-HardwareUM-V1.0 Table2- 1 J2 Signals Definition Pin Signal Name IO Voltage(V) Description Pin Signal Name Voltage(V) Description VIN1A_DE0 Camera 1 Power Down RGMII0_TXC RGMII0 Transmit Clock VIN1A_HSYNC0 I Camera 1 Horizontal Sync RGMII0_TXCTL RGMII0 Transmit Enable VIN1A_VSYNC0 I Camera 1 Vertical Sync...
- Page 16 EM-TF-BB-AM5728-HardwareUM-V1.0 Table2- 2 J3 Signals Definition Pin Signal Name IO Voltage(V) Description Pin Signal Name Voltage(V) Description UART9_TXD RS485 PORT2 Transmit Data Output GPIO7_8 Touch Panel Reset UART9_RXD RS485 PORT2 Receive Data Input GPIO7_11 Touch Panel INT UART9_RTSN GPIO7_10 Audio Codec Reset...
- Page 17 EM-TF-BB-AM5728-HardwareUM-V1.0 Table2- 3 J4 Signals Definition Pin Signal Name IO Voltage(V) Description Pin Signal Name Voltage(V) Description 5V_VDD_SOM Power for SOM Board 5V_VDD_SOM Power for SOM Board GPMC_CLK GPMC Clock output 5V_VDD_SOM Power for SOM Board GPMC_BEN0 GPMC lower-byte enable active low...
-
Page 18: Power Input
MCASP2_AHCLKX Master Clock I/O PORZ Power On Reset Button SOM_DET2 SOM Board Detect 2.2.2 Power Input EM-TF-BB-AM5728 used a DC-Jack or a 3.81mm pitch 2pins terminal block for the power input interface. The voltage can be 7-28V. 13 / 52... -
Page 19: Lcd/Hdmi
The LVDS signals connect to LCD module through a 40 pins FPC connector (J10). The LCD module power solution designed in the EM-TF-BB-AM5728, so it is not need the power solution on LCD module. It support 7 inch LCD module SPF-PH102600T009-IBC03_001[1](I2C interface touch panel) and SPF-PH102600T009-... - Page 20 EM-TF-BB-AM5728-HardwareUM-V1.0 IBC04_001[1](USB interface touch panel). Also it reserved connector that definition by Emtop to compatible others LCD module. Figure2- 6 LCD FPC Connector Figure2- 7 LCD I2C Interface TP Connector 15 / 52...
- Page 21 EM-TF-BB-AM5728-HardwareUM-V1.0 Figure2- 8 LCD USB Interface TP Connector Table2- 5 LCD Signals Pin Signal Name Description Pin Signal Name Description VCOM_LVDS Common Power TXOUT3+ LVDS differential data3+ 3V3_VDDB Digital Power 3V3_VDDB Digital Power No connection No connection No connection MCASP1_AXR0 Reset...
- Page 22 EM-TF-BB-AM5728-HardwareUM-V1.0 Table2- 6 LCD TP Signals HDMI J13 is the standard 19 pins HDMI connector in EM-TF-BB-AM5728 board. 17 / 52...
- Page 23 EM-TF-BB-AM5728-HardwareUM-V1.0 Figure2- 9 HDMI Connector 18 / 52...
-
Page 24: Camera
HDMI_CLKN_C HDMI_CEC_C Other HDMI_SCL_C HDMI_SDA_C 5V_HDMI Power 5V HDMI_HPD_C Hot Plug Detect 2.2.4 Camera EM-TF-BB-AM5728 supports two cameras at the same time. The two cameras are identical. J7/J29 is the 26 pins FPC connector for cameras. 19 / 52... - Page 25 EM-TF-BB-AM5728-HardwareUM-V1.0 Figure2- 10 Camera Connector 20 / 52...
-
Page 26: Gig Ethernet
Parallel data7 OV1_XCLK Clock input 2.2.5 Gig Ethernet The EM-TF-BB-AM5728 has two Giga Ethernet PYH AR8035-AL1B solutions. It is powerful for Ethernet interface. 1. RJ-45 J27/J28 is RJ45 connector of Giga Ethernet. The signals definition as below: 21 / 52... - Page 27 EM-TF-BB-AM5728-HardwareUM-V1.0 Figure2- 11 RJ45 Connector 22 / 52...
-
Page 28: Micro Sd-Card
EM-TF-BB-AM5728-HardwareUM-V1.0 Table2- 9 RJ45 Signals Pin Signal Name Description Pin Signal Name Description MII0_TRP0 Differential DATA0+ 10 MII0_TRN3 Differential DATA3- MII0_TRN0 Differential DATA0- 11 MII0_LED_LINK LED_Link+ MII0_TRP1 Differential DATA1+ 12 LED_Link- MII0_TRN1 Differential DATA1- 13 MII0_LED_ACT LED_ACT- MII0_CT TCT(NC) MII0_LED_YEL... -
Page 29: Usb
EM-TF-BB-AM5728-HardwareUM-V1.0 Micro SD-Card signals definition: Table2- 10 Micro SD-Card signal definition 2.2.7 USB There are two USB2.0 interface, one USB3.0 interface and one mini USB interface for debug in the EM-TF-BB- AM5728 board. The USB2.0 connector is dual stack. 1. USB2.0... - Page 30 EM-TF-BB-AM5728-HardwareUM-V1.0 Figure2- 13 Dual Stack USB2.0 Connector Table2- 11 USB2.0 Interface Pin Signal Name Description VBUS1 USB2.0 Power USB2.0 DA- USB2.0 DA+ VBUS2 USB Power USB2.0 DB- USB2.0 DB+ Shield Shield Shield Shield 2. USB3.0 25 / 52...
- Page 31 EM-TF-BB-AM5728-HardwareUM-V1.0 Figure2- 14 USB3.0 Connector Table2- 12 USB3.0 interface 3. Mini-USB Debug port 26 / 52...
-
Page 32: Rs485&Can
EM-TF-BB-AM5728-HardwareUM-V1.0 Figure2- 15 mini USB Connector Table2- 13 Mini-USB interface 2.2.8 RS485&CAN There are two RS485s and two CANs in EM-TF-BB-AM5728. The four terminal blocks are the same as 3pin 3.81mm. 27 / 52... -
Page 33: Gpmc
EM-TF-BB-AM5728-HardwareUM-V1.0 Figure2- 16 3Pin Terminal Block Table2- 14 RS485&CAN interface 2.2.9 GPMC EM-TF-BB-AM5728 supports 12 bit address and 16 bit data GPMC bus through a 2x25pin, 2.0mm pitch Box Header. 28 / 52... - Page 34 EM-TF-BB-AM5728-HardwareUM-V1.0 Figure2- 17 2x25 Box Header 29 / 52...
-
Page 35: Audio
2.2.10 Audio TLV320AIC3104IRHB is the audio Codec for line out and microphone input in the EM-TF-BB-AM5728. The two connectors are the same except the color. The green one is for line out and the pink one is for microphone input. -
Page 36: Mini Pcie
EM-TF-BB-AM5728-HardwareUM-V1.0 Figure2- 18 3.5mm Audio Connector Table2- 16 Audio/MIC interface 2.2.11 mini PCIE The mini PCIE slot is used for 4G module in EM-TF-BB-AM572. And the J25/J26 are used for populating the SIM card. 31 / 52... - Page 37 EM-TF-BB-AM5728-HardwareUM-V1.0 Figure2- 19 mini PCIE Connector 32 / 52...
-
Page 38: Msata
EM-TF-BB-AM5728-HardwareUM-V1.0 Table2- 17 mini PCIE interface Pin Signal Name Description Pin Signal Name Description GPIO4_12 Wake up MPCIE_3P3V Power UIM_PWR SIM Card Power UIM_DATA SIM Card Data REFCLK- NC.Pull up UIM_CLK SIM Card Clock REFCLK+ NC.Pull up UIM_RESET SIM Card Reset... - Page 39 EM-TF-BB-AM5728-HardwareUM-V1.0 Figure2- 20 mSATA Connector 34 / 52...
-
Page 40: Pcie
SATA1_RXP0 3V3_VDDA Power Differential SATA1_RXN0 mSATA Transmit SATA1_TXP0 Differential SATA1_TXN0 3V3_VDDA 3V3_VDDA Power 3V3_VDDA Power Shield Shield Shield Shield 2.2.13 PCIE There is a standard PCIE x 4 connector(J14), but it only supports two channels in EM-TF-BB-AM5728. 35 / 52... - Page 41 EM-TF-BB-AM5728-HardwareUM-V1.0 Figure2- 21 PCIE x 4 Connector 36 / 52...
-
Page 42: Dido
A30 NC B30 NC A31 GND B31 GPIO7_7 PCIE Present Detect A32 NC B32 GND 2.2.14 DIDO There are two channels DI and DO interface in EM-TF-BB-AM5728. All the signals are placed on 8pins 3.81 pitch terminal blocks. 37 / 52... -
Page 43: Button
EM-TF-BB-AM5728-HardwareUM-V1.0 Figure2- 22 8Pins Terminal Block Table2- 20 DI/DO interface Pin Signal Name Description NO1- DO 1- NO1+ DO 1+ NO2- DO 2- NO2+ DO 2+ DI_1+ DI 1+ DI_1- DI 1- DI_2+ DI 2+ DI_2- DI 2- 2.2.15 Button There are three buttons in the EM-TF-BB-AM572. -
Page 44: Dip Switch
EM-TF-BB-AM5728-HardwareUM-V1.0 Figure2- 23 Button 2.2.16 DIP Switch The two DIP Switch are used for system boot setting. The system boots from Micro SD-Card default. Figure2- 24 DIP Switch Table2- 21 Boot configure BOOT[5:0] BOOT DEVICE 39 / 52... -
Page 45: Led
2.2.18 RTC The super capacitor is used for RTC circuit. Also it reserved a connector for external battery. Figure2- 25 Super Capacitor 2.2.19 BEEP There is a beep in the EM-TF-BB-AM5728. The beep is controlled by GPIO5_19. 40 / 52... -
Page 46: Expansion Interface
EM-TF-BB-AM5728-HardwareUM-V1.0 Figure2- 26 BEEP 2.2.20 Expansion Interface The expansion interface is connected to 2 x 20 pins 2.54mm pitch pin header. Figure2- 27 2x20Pin Header 41 / 52... -
Page 47: Other Device Description
EM-TF-BB-AM5728-HardwareUM-V1.0 Table2- 23 Expansion interface Pin Signal Name Description Pin Signal Name Description VIN1A_D15 VIN1A_D23 VIN1A_D14 VIN1A_D22 GPIO VIN1A_D13 VIN1A_D21 VIN1A_D12 VIN1A_D11 VIN1A_D20 GPIO VIN1A_D10 VIN1A_D19 VIN1A_D18 VIN1A_D9 VIN1A_D17 GPIO GPIO VIN1A_D8 VIN1A_D16 I2C5_SCL TIMER4 PWM Output I2C5_SDA UART10_TXD UART... -
Page 48: Usb2514Bi
EM-TF-BB-AM5728-HardwareUM-V1.0 Wi-Fi, Bluetooth functionalities. The highly integrated module makes the possibilities of web browsing, VoIP, Bluetooth headsets applications. With seamless roaming capabilities and advanced security, also could interact with different vendors’ 802.11a/b/g/n/ac Access Points in the wireless LAN. The wireless module complies with IEEE 802.11 a/b/g/n/ac standard and it can achieve up to a speed of 433.3Mbps with single stream in 802.11ac draft to connect to the wireless LAN. - Page 49 EM-TF-BB-AM5728-HardwareUM-V1.0 Chapter3. Appendix This section described the software of EM-TF-BB-AM5728. 3.1 Software EM-TF-BB-AM5728 support Linux only. Linux 《EM-TF-EVK-AM5728 Linux Software Released Description》 《EM-TF-EVK-AM5728 Software User Manual》 《EM-TF-EVK-AM5728 Software Development Instruction》 44 / 52...
-
Page 50: Technical Support And Warranty
⚫ Customers encounter issues related to their own applications ⚫ Customers encounter issues caused by any unauthorized alter to the source code provided by Emtop Technology. 4.2 Warranty 1） 12-month free warranty on the PCB under normal conditions of use since the sales of the product;... - Page 51 3） Within the period of warranty, the freight for sending products from customers to Emtop Technology should be paid by customers; the freight from Emtop to customers should be paid by us. The freight in any direction occurs after warranty period should be paid by customers;...
-
Page 52: Contact Information
EM-TF-BB-AM5728-HardwareUM-V1.0 Chapter5. Contact Information Technical Support Email: support@Emtop-tech.com Email: sales@Emtop-tech.com Company Information Wabsite: http://www.emtop-tech.com 47 / 52...
