Appendix I Error code

△
Caution:
!
In false alarm state, the alarm code will flash once per second on the display on
the ECU and PCU.
Display Description
System initialization
01
error
System
02
communication error
03 Machine type error
Connection
05
interruption of BMS
09 Pedal failure alarm
Height limit lever
10
triggered
Upper and lower limits
11
are abnormal
(Chassis lift button)
12
pressed incorrectly
MCU 1
14
communication failure
MCU 2
15
communication failure
16 BMS failure
Pothole protection
18
error
23 Lifting limit triggered
Lowering proportional
27
valve failure
Pressure sensor
31
failure
32 Angle sensor failure
Light load not
33
calibrated
34 Decline after overload
Calibration of no load
35
and full load
36 Low battery voltage
Calibration error, and
38
re-calibration required
GPS communication
40
failure
Level 1 vehicle
41
locking via GPS
Handle left button
42 pressed before
starting
Handle right button
43 pressed before
starting
ZAPI 1 fault
44 (Parameter setting
failure of AC pump
Service Manual of Scissors Mobile Elevating Work Platform
Machine reaction
Stop all actions
Stop all actions
Stop all actions
No lifting, no walking
No lifting, no walking
No lifting, no walking
No limit
Stop all chassis
controls
No lifting, no walking
No lifting, no walking
No lifting, no walking
No lifting, no walking
No traveling
No lifting, no walking
No lifting, no walking
No lifting, no walking
No lifting
No reaction
No reaction
High-speed walking
prohibited
No lifting
No reaction
No lifting
No reaction
No reaction
No reaction
Troubleshooting guidance
Restart equipment or replace ECU
Check the connection between communication lines and
other cables. If the fault still cannot be eliminated, please
replace the PCU or ECU.
Enter the parameter adjustment menu and modify the
machine parameters.
Check whether the CAN bus is in poor contact or replace
the lithium battery
Release the foot switch. If it is invalid, check the connection
status of the pedal harness (for short circuit, etc.)
The alarm can be cancelled by lowering
Recalibrate the upper limit or the outdoor limit
Check whether the chassis lift or lower button is pressed at
power-up, or replace the ECU
Check CAN bus for poor contact or modify electric drive
type
Check CAN bus for poor contact or modify electric drive
type
Check whether the CAN bus is in poor contact or replace
the lithium battery
Pothole protection error: check whether the pothole
protection is enabled and check the pothole protection limit
switch. Check the lower limit switch and wiring.
This reminder can be canceled in case of drop
Check or replace the lowering proportional valve
Check the sensor wiring and the sensor itself, and check
whether the sensor is not installed but the weighing function
is turned on.
Check the sensor wiring and the sensor itself, and check
whether the sensor is not installed but the weighing function
is turned on.
Calibrate the light load, or turn off the double load function.
This fault is only saved and not displayed. It is used to
remind the operator.
Re-calibrate no load and full load
If battery power is low, charge it in time; If the battery
power is normal, check the wiring or replace the ECU.
Conduct re-calibration
Check CAN bus for poor contact or replace GPS equipment
Unlock or connect GPS equipment
Make sure nothing presses the key on the handle. If so,
consider replacing the handle or PCU.
Make sure nothing presses the key on the handle. If so,
consider replacing the handle or PCU.
Replace the motor drive or contact the motor drive
manufacturer
