Summary of Contents for ServerLIFT SL-1000X
- Page 1 Operator’s Manual ServerLIFT ® Electric Data Center Lift Serial #: 17453 N 25th Ave | Phoenix, AZ 85023 | TEL: 602.254.1557 | FAX: 602.254.1975...
- Page 2 NOTICE ONLY ORIGINAL SERVERLIFT REPLACEMENT PARTS SHALL BE USED FOR ANY REPAIR. ServerLIFT SL-1000X Data Center Lift Operator’s Manual...
-
Page 3: Table Of Contents
(602) 254-1557 | Fax: (602) 254-1975 Service & Support: Shipping/Receiving: Client Services (Sales): support@serverlift.com shipping@serverlift.com solutions@serverlift.com © ServerLIFT Corporation. All Rights Reserved. 05-2023 P/N: SL-1 r.A05 Information in this document subject to change without notice. ServerLIFT SL-1000X Data Center Lift Operator’s Manual ®... -
Page 4: Introduction
® IMPORTANT: Keep these instructions with SL-1000X data center lift. ® • Do not stand or ride on any part of the SL-1000X data center lift. ® • Never lift or move the SL-1000X data center lift with a pallet truck, ®... -
Page 5: Legend
9. Serial Number Plate 3. Strap Hooks 10. Pallet Bolt Holes 4. Handle Bars 11. Power Cord Sleeve 5. Platform Mast 12. Power Cord 6. Easy-Glide Shelf Handle 13. Panel Access Door Latch ServerLIFT SL-1000X Data Center Lift Operator’s Manual ® ®... - Page 6 17. Battery Charge Test Button 24. Pallet Bolt Holes 18. Battery Charge Level Indicator 25. Operator’s Manual Sleeve 19. Panel Access Door 26. Upper Panel Cover 20. Stabilizer Brake Release Pedal 27. TouchSTOP™ Sensor ServerLIFT SL-1000X Data Center Lift Operator’s Manual ® ®...
-
Page 7: Set Up
Operator's Manual for future reference. 3. Perform Pre-operation Inspection. 4. Perform Function Tests. Pre-operation Inspection Check SL-1000X data center lift for signs of damage. Fully ® document any damage with photos, location, and description. Promptly contact ServerLIFT Service &... - Page 8 Set Up www.serverlift.com If Battery is not fully charged, recharge it before continuing Set Up (see Battery Charging on page 27). Note: Charge the Battery whenever the SL-1000X data ® center lift is not in active use to maximize battery life.
- Page 9 3. Press Up/Down Control Switch to move Platform UP. Test full range of motion up and down. Platform will automatically stop in fully extended and fully retracted positions. If Platform does not travel full range of motion consistently, contact ServerLIFT ® Service and Support.
- Page 10 7. Lower Platform down. Turn off unit power by turning key to OFF ( O ) position. Release Stabilizer Brake. WARNING NEVER raise or lower platform with shelf out of neutral (center) position. ServerLIFT SL-1000X Data Center Lift Operator’s Manual ® ®...
-
Page 11: Instructions
4. Make sure Stabilizer Brake engages and locks in place. Both Stabilizer Brake Pads must be installed and engage floor correctly (see Stabilizer Brake Operation on page 12). SL-1000X Data Center Lift Operating Steps Position the lift Engage Stabilizer Brake... -
Page 12: Stabilizer Brake Operation
The lift should not move. If the lift moves, the Stabilizer Brake is not functioning properly. Contact ServerLIFT Service ® and Support. Note: Without equipment on the platform, average force is all that is needed to fully depress Stabilizer Brake. -
Page 13: Applying Load To The Platform
WARNING at Edge of LOAD at Center Extended LOAD of the Platform Platform 1000 SL-1000X ® MAX. LOAD (454 (182 Edge of Platform Center of Platform Front Caster Swivel Lock Operation UNLOCKED To unlock Front Caster, pull out ring and turn 90 degrees in either direction. -
Page 14: Safety Directions
Pinch Point Hazard • Keep hands clear of moving parts and open sections during operation. • Hands should only be on handle bars and/or on designated locations needed for operation. ServerLIFT SL-1000X Data Center Lift Operator’s Manual ® ®... -
Page 15: Attachments
IT equipment out of boxes and off of skids. It features a lightweight design that is capable of lifting up to 700lb (318kg). The LE-1000X™ may be used only with the SL-1000X ® data center lift model. - Page 16 2 in remaining three hook locations as shown. 3. Insert Swing Arm into both pivot brackets as shown. 4. Secure Spherical Rod Ends of Swing Arm to pivot brackets with Locking Pins. Spherical Rod End ServerLIFT SL-1000X Data Center Lift Operator’s Manual ® ®...
- Page 17 Attachments www.serverlift.com Attaching Lift Extension to the SL-1000X® lift 1. Engage the Stabilizer Brake and turn power ON. 2. Raise Platform to a height of at least 1.5ft (0.5m) above Caster Wheel mounts. 3. With Swing Arm rotated towards closed end of Lift...
- Page 18 1. Ensure that Adjustment Screws are completely loosened. 2. Make sure Lift Extension is fully inserted into Platform Frame. Front surface of Catches should touch Platform Frame. 3. If Swing Arm Hook is still under-engaged, remove Lift Extension from the SL-1000X lift. ® ServerLIFT SL-1000X Data Center Lift Operator’s Manual...
- Page 19 4. Repeat with the second Sling on the other side of the LE-1000X Lift Extension. CAUTION Center of gravity of the load must be centered in between 2” min 2” min Center Of Gravity Sling Hooks. ServerLIFT SL-1000X Data Center Lift Operator’s Manual ® ®...
- Page 20 9. Disengage Swing Arm, remove Lift Extension from the data center lift, and safely set aside Lift Extension. 10. Slide equipment from table onto the Platform and Easy-Glide Shelf and follow Operating Steps 5 - 17 (Page 11). ServerLIFT SL-1000X Data Center Lift Operator’s Manual ® ®...
-
Page 21: Rl-500™ Platform Riser
Attachments www.serverlift.com RL-500™ Platform Riser The ServerLIFT RL-500™ Platform Riser attachment enables ® users to install servers at the top of any rack in areas where equipment positioning is a challenge. These situations include: • Low ceilings clearance or obstructions •... -
Page 22: Rs-500X™ Rail Lift
Four holes on Platform Riser top plate are provided for convenient storage of Thumbscrews and Washers when not in use. RS-500X™ Rail Lift The ServerLIFT RS-500X™ Rail Lift attachment enables users to ® position and support servers at an angle for installation or removal from slotted or drop-in rails. - Page 23 RS-500X™ Rail Lift can be secured to the ® Platform Shelf in one of two positions, allowing the Operator the choice of using it from the left or right side of the SL-1000X unit. ® The RS-500X™ Rail Lift can also be used in conjunction with the RL-500™...
- Page 24 RL-500 Riser Using the Rail Lift 1. Ensure that the RS-500X™ Rail Lift is attached to the Easy- Glide Shelf or the RL-500™ Platform Riser as needed per the above directions. ServerLIFT SL-1000X Data Center Lift Operator’s Manual ® ®...
- Page 25 8. Once all nailheads are lined up in their respective rail slots, lower the Platform so equipment is fully supported by the rails. Reverse these steps for un-racking server equipment. ServerLIFT SL-1000X Data Center Lift Operator’s Manual ® ®...
-
Page 26: Maintenance
Inspect Pulleys Every 12 months Flush and Change Winch Oil* Every 12 months (suggested)* * Oil replacement kits and directions are available from ServerLIFT Service & Support. ® Note: Units covered under optional Extended Warranty and Service contracts have all above maintenance checks... -
Page 27: Battery Charging
Maintenance www.serverlift.com Battery Charging The SL-1000X data center lift is equipped with a rugged, compact ® battery charger that recharges the onboard 12V 80Ah VRLA battery. The charger is automatic and simply needs to be plugged in to a suitable power supply or standard outlet, up to 240V. -
Page 28: Panel Access Door
1. Make sure Power Cord is unplugged. 2. Press Battery Charge Test Button on Main Control Panel, activating Battery Charge Level Indicator. 3. There are 3 charge zones on Level Indicator: DISCHARGED ServerLIFT SL-1000X Data Center Lift Operator’s Manual ® ®... -
Page 29: Battery Replacement
VRLA (valve-regulated lead-acid), AGM (Absorbed glass mat) battery. It is sealed and spill-proof. Replacements are commonly available from suppliers of high performance marine or UPS style batteries, or directly through ServerLIFT Service & ® Support. Bring old battery with you to supplier for comparison and safe disposal. - Page 30 168mm 215mm 23.83kg Note: ONLY batteries with INTERNAL terminals will fit inside the ServerLIFT SL-1000X data center lift. Batteries ® with external terminals will not work and may cause fire or explosion. 1. Open Panel Access Door. 2. A zip-tie installed to hold the...
-
Page 31: Stabilizer Brake Boot Replacement
Stabilizer Brake Boot Replacement 1. Pull top corners of old boot out and down to remove from Stabilizer Brake Pad. 2. Press new boot on until it snaps in to place. Removal Installation ServerLIFT SL-1000X Data Center Lift Operator’s Manual ® ®... -
Page 32: Pulley And Cable Inspection
3. Inspect Lower Pulley from undercarriage of the lift. Note: Lower Pulley only be visible from undercarriage when Platform is completely lowered. If inspection reveals any pulley irregularities or damage, discontinue use of the lift and contact ServerLIFT Service & Support immediately. ® ServerLIFT SL-1000X Data Center Lift Operator’s Manual... -
Page 33: Specifications
Seamless install from the platform into the rails Smart Controls • Precise height adjustment with proprietary microprocessor-controlled lifting system • Dual side controls allow single operator to align equipment while facing the rack ServerLIFT SL-1000X Data Center Lift Operator’s Manual ® ®... - Page 34 Specifications www.serverlift.com Telescoping Mast • SL-1000X Lift 1000lb (452kg) to 9’ / 2.76m) ® • Quickly raise equipment to the top of travel in under 1 minute TouchSTOP™ Sensor • Proprietary sensing technology cuts power to machine on contact with ceiling, lights, cable trays, or other overhead obstructions •...
-
Page 35: Dimensions And Capacity
Specifications www.serverlift.com Dimensions and Capacity, SL-1000X ® Overall Height Working Dimensions Metric [198.12] Platform Height, Extended 8.73’ 2.66m 78.00 Platform Height, Lowered 5.21” 13.2cm Shelf Movement per side 6.0” 15.2cm Movable Platform Width 14.0” 35.6cm Platform Width 24” 61.0cm Total Platform Depth 21”... -
Page 36: Troubleshooting
Make sure there are no obstructions between pin Locking pin not engaging and groove. Adjust caster wheel until engagement with caster groove. occurs. Detailed directions for this adjustment available from ServerLIFT Service & Support. ® Caster groove or locking Replace worn or damaged hardware. - Page 37 Wiring not connected to Open Panel Access Door. Check that all Main Circuit Board. connections to Main Circuit Board are secure. Main Circuit Board Contact ServerLIFT Service & Support for ® damaged. replacement part. Replace Circuit Board. Upper and/or Lower Limit Follow Raises But Does Not Lower and Lowers Switches are activated.
- Page 38 Limit Switch plunger is not stuck in depressed position. Make sure Tension Swing Arm is engaging/depressing the switch plunger. Main Circuit Board Contact ServerLIFT Service & Support for ® damaged. replacement part. Replace Circuit Board. Platform Lowers But Does Not Raise...
- Page 39 Press handle down. Attempt to shift Shelf from its position. sideways. Path of shelf is obstructed. Locate and remove obstruction(s). Check under Platform for damaged part(s). Locking mechanism is Contact ServerLIFT Support for replacement ® damaged. part. Keylock Spins 360 Degrees Possible Cause...
-
Page 40: Warranty
Warranty www.serverlift.com SERVERLIFT® DATA CENTER LIFT LIMITED WARRANTY LIMITED WARRANTY COVERAGE The limited warranty covers defects in materials and workmanship of the ServerLIFT ® SL-1000X data center lift (collectively “Equipment”). The warranty is not transferable and ® must be registered at https://serverlift.com/register. The warranty applies only to the... - Page 41 For warranty assistance call ServerLIFT Corporation at 1-602-254-1557 between 9:00 a.m. and 5:00 p.m. Mountain Standard Time, Monday through Friday (excluding observed holidays), email support@serverlift.com or visit http://serverlift.com/support/. As part of the terms of this warranty, you may be required, as needed, to assist ServerLIFT ’s ®...
-
Page 42: Ce Declaration
Manufacturer: ServerLIFT Corporation 17453 N 25th Ave Phoenix, AZ 85023 USA 602-254-1557 www.serverlift.com Model numbers: SL-1000X , SL-1000XI™ ® Max. Load Capacity: 454 kg (1000 lbs) Type of equipment: Server and IT equipment lifting machine We declare that the product identified above meets the requirements of the... -
Page 43: Fcc Declaration
FCC Declaration www.serverlift.com Declaration of Conformity Client: ServerLIFT Corporation Model numbers: SL-1000X , SL-1000XI™ ® Type of equipment: Lifting device for IT equipment for use in data centers Manufacturer: ServerLIFT Corporation 17453 N 25th Ave, Phoenix, AZ 85023 USA 602-254-1557 Report Date: March 1 and 4, 2019 Test Performed By: Compatible Electronic Inc. - Page 44 ServerLIFT Corporation. All Rights Reserved. SL, ServerLIFT, SL-1000X, SL-500X, SL-500FX, SL-350X, and TouchSTOP are trademarks of ServerLIFT Corporation 17453 N 25th Ave | Phoenix, AZ 85023 | TEL: 602.254.1557 | FAX: 602.254.1975...
