- Page 1 Operator’s Manual ServerLIFT Manual Crank Lift Serial #: 17453 N 25th Ave | Phoenix, AZ 85023 | TEL: 602.254.1557 | FAX: 602.254.1975...
- Page 2 As a certified ISO:9001 and ISO:14001 manufacturer, ServerLIFT has made a commitment to our customers, suppliers, and community, to continuously improve and to deliver products and services that meet or exceed the highest standards for quality and minimizing environmental impact.
-
Page 3: Table Of Contents
17453 N 25th Ave | Phoenix, AZ USA 85023 (602) 254-1557 | Fax: (602) 254-1975 Service & Support: Shipping/Receiving: Sales: support@serverlift.com shipping@serverlift.com sales@serverlift.com © ServerLIFT Corporation. All Rights Reserved. 05-2020 P/N: SL-3 r.D07 Information in this document subject to change without notice. SL-350X ServerLIFT Operator’s Manual ®... -
Page 4: Introduction
Do not stand or ride on any part of the ServerLIFT device. • Never lift or move the ServerLIFT device with a pallet truck, jack, or forklift. Use the pallet, ramp, and packaging originally received with the unit for transporting it. -
Page 5: Legend
7. Casters - Free Swivel Easy-Tilt Glide Shelf 8. Serial Number Plate 3. Strap Hooks 9. Platform SmartTILT 4. Platform Mast Adjustment 5. Easy-Glide Shelf Handle 10. Accessory Attachment Holes SL-350X ServerLIFT Operator’s Manual ® ServerLIFT SL-350X Data Center Lift Operator's Manual ®... - Page 6 11. Pallet Bolt Holes 15. Stabilizer Brake Pad 12. Winch (Up/Down) Handle 16. Operator’s Manual Sleeve 13. Stabilizer Brake Release Pedal 17. Handle Bars 14. Stabilizer Brake Pedal SL-350X ServerLIFT Operator’s Manual ® ServerLIFT SL-350X Data Center Lift Operator's Manual ®...
-
Page 7: Set Up
ServerLIFT Service & Support if any damage is present. SAVE PALLET, RAMP, HARDWARE AND PACKING CARTON! They are needed for moving the ServerLIFT unit to other locations. Function Tests Function Tests are designed to discover malfunctions before machine is used. Tests should be performed before normal operation. Before testing, select an area that is solid, level and free of obstructions. - Page 8 Set Up www.serverlift.com 2. Attempt to move the ServerLIFT machine. It should be locked in place and not be able to move. If it rolls at all, or Stabilizer Brake does not lock in DOWN position, contact ServerLIFT Service and Support.
- Page 9 • Operate with hand power only. Do not operate ServerLIFT device with a motor of any kind. If Winch Handle cannot be cranked easily with one hand, it is probably over-loaded.
- Page 10 4. Test full movement of Easy- Glide Shelf in both directions. If shelf does not travel entire range of motion consistently or does not lock at incremental adjustment locations, contact ServerLIFT Service and Support. DOWN 5. Return Shelf to neutral (center) Platform Tilt Angle position.
-
Page 11: Instructions
11. Load server from Platform and Easy-Glide Shelf into rack 12. Lower Platform to lowest position 13. Release Stabilizer Brake * especially critical when moving the ServerLIFT unit across uneven or not level ground SL-350X ServerLIFT Operator’s Manual ® ServerLIFT SL-350X Data Center Lift Operator's Manual ®... -
Page 12: Stabilizer Brake Operation
WARNING • Always engage Stabilizer Brake before raising, lowering, or sliding Easy-Glide Shelf • Engage Stabilizer Brake whenever ServerLIFT unit is not in motion • ServerLIFT unit will/should not move with Stabilizer Brake engaged SL-350X ServerLIFT Operator’s Manual ®... -
Page 13: Applying Load To The Platform
90 degrees in either direction. Allow ring to align in vertical groove as shown. Ensure caster is in line with base frame arm and pointing backward. An audible click indicates the lock is engaged. SL-350X ServerLIFT Operator’s Manual ® ServerLIFT SL-350X Data Center Lift Operator's Manual ®... -
Page 14: Safety Directions
• Do not stand under overhanging load. • Do not exceed rated load capacity. • Do not stack loads. • Do not support ladder against ServerLIFT unit. • Do not use on uneven or graded surface Collision Hazards • Only lower load in areas clear of personnel and obstructions. -
Page 15: Attachments
PL-500X™ Platform Extension The ServerLIFT PL-500X Platform Extension brings the reach of any ServerLIFT unit down to the floor, so it can safely and precisely handle equipment at bottom rack positions. The Platform Leveler can adjust the angle of the equipment up or down for precise server alignment. - Page 16 Attachments www.serverlift.com Installing the Counterweight Kit 1. Remove plastic caps on rear of ServerLIFT unit as shown. 2. Insert Counterweight Posts (open end down) into holes and over the screws and nuts inside ServerLIFT Base support tube. 3. Place first Counterweight onto Counterweight Post as shown.
- Page 17 Attaching Platform Extension to the ServerLIFT Unit 1. See "Front Caster Swivel Lock Operation" on page 13 and Incorrect prepare the ServerLIFT unit by locking the Front Casters in the backward position as shown. Incorrect Correct 2. Engage ServerLIFT Stabilizer Brake and turn power ON.
- Page 18 Attachments www.serverlift.com 1. Raise the ServerLIFT Platform so the bottom plate of the Platform is in-line with the top of the PL-500X Support Arms. 2. Roll the ServerLIFT unit forward so the PL-500X horizontal arm brackets completely engage on top of the ServerLIFT Platform Bottom Plate as shown.
- Page 19 1. Rotate Swing Arm as shown and engage the Swing Arm Hook over the front edge of the ServerLIFT Platform Column. Adjust the length of the Swing Arm, and thereby the desired angle of the PL-500X Platform, by rotating the hex bolt at the end of the arm hook assembly using the ratchet provided.
- Page 20 4. Hook loose loop end of the sling to the front sling hook on the same side. 5. Repeat with the second sling and sling hooks on the other side. SL-350X ServerLIFT Operator’s Manual ® ServerLIFT SL-350X Data Center Lift Operator's Manual ®...
- Page 21 6. Remove Sling Hooks from Platform Extension. 7. Transfer server from table onto PL-500X Platform or remove Platform Extension from ServerLIFT unit to transfer server onto ServerLIFT Platform. 8. Follow "Operating Steps" on page 11. SL-350X ServerLIFT Operator’s Manual ®...
-
Page 22: Le-500X™ Lift Extension
IT equipment out of boxes and off of skids. They feature a lightweight design that is capable of lifting up to 500 lb (227 kg.) The LE-500X may be used with the ServerLIFT SL-500X or SL-350X devices. - Page 23 2. Raise Platform to a height of at least 1.5 ft (0.5 m) above Caster Wheel mounts. 3. Insert Lift Extension onto ServerLIFT Platform as shown. Lift Extension Catches should insert on top of Platform Bottom Plate with top of Lift Extension Frame Arms resting against underside of the Platform Bottom Plate.
- Page 24 3. Hook loose loop end of the Sling to the front Sling Hook on the same side of the LE-500X Lift Extension. SL-350X ServerLIFT Operator’s Manual ® ServerLIFT SL-350X Data Center Lift Operator's Manual ®...
- Page 25 5. Remove Lift Extension from ServerLIFT unit, and safely set aside Lift Extension. 6. Slide equipment from table onto ServerLIFT Platform and Easy-Glide Shelf and follow "Operating Steps" on page 11. CAUTION Center of gravity of the load must be centered in between 2”...
-
Page 26: Rl-500™ Platform Riser
• Ten foot (3 meter) tall racks • Drop in rails The ServerLIFT RL-500 Platform Riser features a lightweight yet rugged design, and is compatible with all current and past models of ServerLIFTs. Included with the RL-500 Platform Riser (1) Platform Riser... -
Page 27: Rs-500X™ Rail Lift
The ServerLIFT RS-500X Rail Lift attachment enables users to position and support servers at an angle for installation or removal from slotted or drop-in rails. The ServerLIFT RS-500X Rail Lift features a low profile yet rugged design, and is compatible with all current and past models of SL-350X ServerLIFT Operator’s Manual... - Page 28 The ServerLIFT RS-500X Rail Lift can be secured to the ServerLIFT Platform Shelf in one of two positions, allowing the Operator the choice of using it from the left or right side of the SL-350X ServerLIFT device. The RS-500X Rail Lift can also be used in conjunction with the RL-500 Platform Riser.
- Page 29 Attachments www.serverlift.com 3. Place the RS-500X Rail Lift onto ServerLIFT Easy-Glide Shelf or RL-500 Platform Riser. Line up the four holes in the base plate of Rail Lift with threaded holes on ServerLIFT Easy-Glide Shelf or RL-500 Platform Riser. 4. Secure the RS-500X Rail Lift to Shelf with Thumbscrews in all four locations as shown below.
- Page 30 8. Once all nailheads are lined up in their respective rail slots, lower the Platform so equipment is fully supported by the rails. Reverse these steps for un-racking server equipment. SL-350X ServerLIFT Operator’s Manual ® ServerLIFT SL-350X Data Center Lift Operator's Manual ®...
-
Page 31: Maintenance
Every 12 months Inspect Pulleys Every 12 months Note: Units covered under optional Extended Warranty and Service contracts have all above maintenance checks performed as part of ServerLIFT’s warranty service visit. SL-350X ServerLIFT Operator’s Manual ® ServerLIFT SL-350X Data Center Lift Operator's Manual... -
Page 32: Stabilizer Brake Boot Replacement
Debris or foreign objects interfering with operation • Missing Handle Nut and/or Spring Discontinue use of ServerLIFT if any Winch damage is discovered upon inspection, and contact ServerLIFT Service & Support immediately. Do not attempt to repair or change Winch. -
Page 33: Pulley Inspection
Uneven spooling of Cable on Winch Drum • Distortion, kinking, uneven strands, crushed parts, unevencablediameter,orstrandscomingoff Discontinue use of ServerLIFT device if any Cable damage is discovered upon inspection, and contact ServerLIFT Service & Support immediately. Do not attempt to repair or change Cable. Pulley Inspection When inspecting pulleys, listen for squeaking, look for cracks, extreme wear, loose connections, and bent/damaged pulley guards. -
Page 34: Specifications
Enables safe use in contained and open environments without any modifications or adjustments Locking Stabilizing Brake System • Restricts unit from moving during installation • Increases side-to-side stability SL-350X ServerLIFT Operator’s Manual ® ServerLIFT SL-350X Data Center Lift Operator's Manual ®... -
Page 35: Dimensions And Capacity
Specifications www.serverlift.com Dimensions and Capacity, SL-350X Working Dimensions Metric Shelf tilts over 2° for alignment Platform Height, Extended 8.0’ 2.44m Platform Height, Lowered 5.3” 13.5cm Shelf Movement per side 6.0” 15.2cm Movable Platform Width 14.6” 36.8cm Platform Length 24” 61.0cm Total Platform Width 21”... -
Page 36: Troubleshooting
Locking pin not engaging and groove. Adjust caster wheel until engagement with caster groove. occurs. Detailed directions for this adjustment available from ServerLIFT Service & Support. Caster groove or locking Replace worn or damaged hardware. pin worn or damaged. Easy-Glide Shelf Does Not Side Shift... - Page 37 Troubleshooting www.serverlift.com ServerLIFT Unit Does Not Move/Roll Possible Cause Solution Brake is engaged. Disengage Stabilizer Brake. Obstruction with caster Remove obstruction. wheel. Caster wheel(s) damaged. Replace damaged hardware. ServerLIFT Does Not Swivel/Turn Possible Cause Solution Front Swivel Lock(s) Disengage Swivel Lock(s).
- Page 38 Adjust platform angle in the other direction. direction. SmartTILT mechanism Adjust platform angle in the other direction. If over-torqued in one unable to adjust, contact ServerLIFT Service & direction. Support. Platform cannot be adjusted DOWN when it is in Platform is in the lowest it's lowest position.
-
Page 39: Warranty
Will be free from defects in materials and workmanship. Will perform substantially in accordance with ServerLIFT’s published specifications. ServerLIFT will ship any parts that are in-warranty at no charge in accordance with the Limited Warranty Return & Repair Policy listed below. ServerLIFT will provide repair or replacement instructions as needed. - Page 40 • Description of the problem and/or desired service action. In the event of a return or repair that is determined to occur at ServerLIFT’s facilities, you will be issued a Warranty Repair Authorization (WRA) or case number and shipping instructions.
-
Page 41: Ce Declaration
Manufacturer: ServerLIFT Corporation 17453 N 25th Ave Phoenix, AZ 85023 USA 602-254-1557 www.serverlift.com Model numbers: SL-350X , SL-350XI ® ® Type of equipment: Server and IT equipment lifting machine We declare that the product identified above meets the requirements of the... - Page 42 ServerLIFT Corporation. All Rights Reserved. SL, ServerLIFT, SL-1000X, SL-500X, SL-500FX, SL-350X, and TouchSTOP are trademarks of ServerLIFT Corporation 17453 N 25th Ave | Phoenix, AZ 85023 | TEL: 602.254.1557 | FAX: 602.254.1975...
