- Page 1 Operator’s Manual ServerLIFT Electric Data Center Lift Serial #: 17453 N 25th Ave | Phoenix, AZ 85023 | TEL: 602.254.1557 | FAX: 602.254.1975...
- Page 2 As a certified ISO:9001 and ISO:14001 manufacturer, ServerLIFT has made a commitment to our customers, suppliers, and community, to continuously improve and to deliver products and services that meet or exceed the highest standards for quality and minimizing environmental impact.
-
Page 3: Table Of Contents
Contents www.serverlift.com Introduction Included with the SL-500X device Legend Set Up Before you begin Pre-operation Inspection Function Tests Instructions Before operating the ServerLIFT unit Operating Steps Stabilizer Brake Operation Applying Load To The Platform Front Caster Swivel Lock Operation Safety Directions Attachments PL-500X™... -
Page 4: Introduction
Do not stand or ride on any part of the ServerLIFT device. • Never lift or move the ServerLIFT device with a pallet truck, jack, or forklift. Use the pallet, ramp, and packaging originally received with the unit for transporting it. -
Page 5: Legend
11. Power Cord Sleeve 4. Handle Bars 12. Power Cord 5. Platform Mast 13. Panel Access Door Latch 6. Easy-Glide Shelf Handle 14. Platform SmartTILT Adjustment 7. Casters - Swivel/Lock 15. Accessory Attachment Holes ServerLIFT SL-500X Data Center Lift Operator’s Manual ®... - Page 6 19. Battery Charge Test Button 26. Pallet Bolt Holes 20. Battery Charge Level Indicator 27. Operator’s Manual Sleeve 21. Panel Access Door 28. Upper Panel Cover 22. Stabilizer Brake Release Pedal 29. TouchSTOP™ Sensor ServerLIFT SL-500X Data Center Lift Operator’s Manual ®...
-
Page 7: Set Up
Service & Support if any damage is present. SAVE PALLET, RAMP, HARDWARE AND PACKING CARTON! They are needed for moving the ServerLIFT unit to other locations. Function Tests Function Tests are designed to discover malfunctions before machine is used. Tests should be performed before normal operation. Before testing, select an area that is solid, level and free of obstructions. - Page 8 Stabilizer Brake does not lift the back wheels up, contact ServerLIFT Service and Support. 2. Attempt to move the ServerLIFT machine. It should be locked in place and not be able to move. If it rolls at all, or Stabilizer Brake does not lock in DOWN position, contact ServerLIFT Service and Support.
- Page 9 Platform will automatically stop in fully extended and fully retracted positions. If Platform does not travel full range of motion consistently, contact ServerLIFT Service and Support. Note: Clicking or ratcheting noises are normal when raising/ lowering Platform.
- Page 10 If shelf does not travel entire range of motion consistently or does not lock at incremental adjustment locations, contact ServerLIFT Service and Support. 6. Return Shelf to neutral (center) position. 7. Test operation and range of motion of the SmartTILT...
-
Page 11: Instructions
17. Power the ServerLIFT unit OFF (O) 18. Release Stabilizer Brake 19. Charge ServerLIFT unit when not in use * especially critical when moving the ServerLIFT unit across uneven or not level ground ServerLIFT SL-500X Data Center Lift Operator’s Manual... -
Page 12: Stabilizer Brake Operation
• Always engage Stabilizer Brake before raising, lowering, or sliding Easy-Glide Shelf ™ • Engage Stabilizer Brake whenever ServerLIFT unit is not in motion • ServerLIFT unit will/should not move with Stabilizer Brake engaged ServerLIFT SL-500X Data Center Lift Operator’s Manual... -
Page 13: Applying Load To The Platform
90 degrees in either direction. Allow ring to align in vertical groove as shown. Ensure caster is in line with base frame arm and pointing backward. An audible click indicates the lock is engaged. ServerLIFT SL-500X Data Center Lift Operator’s Manual ®... -
Page 14: Safety Directions
• Do not stand under overhanging load. • Do not exceed rated load capacity. • Do not stack loads. • Do not support ladder against ServerLIFT unit. • Do not use on uneven or graded surface Collision Hazards • Only lower load in areas clear of personnel and obstructions. -
Page 15: Attachments
PL-500X™ Platform Extension The ServerLIFT PL-500X Platform Extension brings the reach of any ServerLIFT unit down to the floor, so it can safely and precisely handle equipment at bottom rack positions. The Platform Leveler can adjust the angle of the equipment up or down for precise server alignment. - Page 16 Attachments www.serverlift.com Installing the Counterweight Kit 1. Remove plastic caps on rear of ServerLIFT unit as shown. 2. Insert Counterweight Posts (open end down) into holes and over the screws and nuts inside ServerLIFT Base support tube. 3. Place first Counterweight onto Counterweight Post as shown.
- Page 17 Attaching Platform Extension to the ServerLIFT unit 1. See "Front Caster Swivel Lock Operation" on page 13 and Incorrect prepare the ServerLIFT unit by locking the Front Casters in the backward position as shown. Incorrect Correct 2. Engage ServerLIFT Stabilizer Brake and turn power ON.
- Page 18 Attachments www.serverlift.com 4. Raise the ServerLIFT Platform so the bottom plate of the Platform is in-line with the top of the PL-500X Support Arms. 5. Roll the ServerLIFT unit forward so the PL-500X horizontal arm brackets completely engage on top of the ServerLIFT Platform Bottom Plate as shown.
- Page 19 6. Rotate Swing Arm as shown and engage the Swing Arm Hook over the front edge of the ServerLIFT Platform Column. Adjust the length of the Swing Arm, and thereby the desired angle of the PL-500X Platform, by rotating the hex bolt at the end of the arm hook assembly using the ratchet provided.
- Page 20 Platform Plate as shown. 5. Hook loose loop end of the sling to the front sling hook on the same side. 6. Repeat with the second sling and sling hooks on the other side. ServerLIFT SL-500X Data Center Lift Operator’s Manual ®...
- Page 21 12. Remove Sling Hooks from Platform Extension. 13. Transfer server from table onto PL-500X Platform or remove Platform Extension from ServerLIFT unit to transfer server onto ServerLIFT Platform. 14. Follow "Operating Steps" on page 11. ServerLIFT SL-500X Data Center Lift Operator’s Manual...
-
Page 22: Le-500X™ Lift Extension
IT equipment out of boxes and off of skids. They feature a lightweight design that is capable of lifting up to 500 lb (227 kg.) The LE-500X may be used with the ServerLIFT SL-500X or SL-350X devices. - Page 23 2. Raise Platform to a height of at least 1.5 ft (0.5 m) above Caster Wheel mounts. 3. Insert Lift Extension onto ServerLIFT Platform as shown. Lift Extension Catches should insert on top of Platform Bottom Plate with top of Lift Extension Frame Arms resting against underside of the Platform Bottom Plate.
- Page 24 3. Hook loose loop end of the Sling to the front Sling Hook on the same side of the LE-500X Lift Extension. ServerLIFT SL-500X Data Center Lift Operator’s Manual ®...
- Page 25 8. Remove Lift Extension from ServerLIFT unit, and safely set aside Lift Extension. 9. Slide equipment from table onto ServerLIFT Platform and Easy-Glide Shelf and follow "Operating Steps" on page 11. CAUTION Center of gravity of the load must be centered in between 2”...
-
Page 26: Rl-500™ Platform Riser
• Ten foot (3 meter) tall racks • Drop in rails The ServerLIFT RL-500 Platform Riser features a lightweight yet rugged design, and is compatible with all current and past models of ServerLIFTs. Included with the RL-500 Platform Riser (1) Platform Riser... -
Page 27: Rs-500X™ Rail Lift
The ServerLIFT RS-500X Rail Lift features a low profile yet rugged design, and is compatible with all current and past models of ServerLIFT SL-500X Data Center Lift Operator’s Manual... - Page 28 The ServerLIFT RS-500X Rail Lift can be secured to the ServerLIFT Platform Shelf in one of two positions, allowing the Operator the choice of using it from the left or right side of the ServerLIFT SL-500X device. The RS-500X Rail Lift can also be used in conjunction with the RL-500 Platform Riser.
- Page 29 Attachments www.serverlift.com 1. Place the RS-500X Rail Lift onto ServerLIFT Easy-Glide Shelf or RL-500 Platform Riser. Line up the four holes in the base plate of Rail Lift with threaded holes on ServerLIFT Easy-Glide Shelf or RL-500 Platform Riser. 2. Secure the RS-500X Rail Lift to Shelf with Thumbscrews in all four locations as shown below.
- Page 30 8. Once all nailheads are lined up in their respective rail slots, lower the Platform so equipment is fully supported by the rails. Reverse these steps for un-racking server equipment. ServerLIFT SL-500X Data Center Lift Operator’s Manual ®...
-
Page 31: Maintenance
Every 12 months Flush and Change Winch Oil* Every 12 months (suggested)* * Oil replacement kits and directions are available from ServerLIFT Service & Support. Note: Units covered under optional Extended Service and Warranty contracts have all above maintenance checks (except for battery replacement) performed as part of ServerLIFT’s annual service visit. -
Page 32: Battery Charging
Maintenance www.serverlift.com Battery Charging The SL-500X data center lift is equipped with a rugged, compact ® battery charger that recharges the onboard 12V 80Ah VRLA battery. The charger is automatic and simply needs to be plugged in to a suitable power supply or standard outlet, up to 240V. -
Page 33: Panel Access Door
1. Make sure Power Cord is unplugged. 2. Press Battery Charge Test Button on Main Control Panel, activating Battery Charge Level Indicator. 3. There are 3 charge zones on Level Indicator: DISCHARGED ServerLIFT SL-500X Data Center Lift Operator’s Manual ®... -
Page 34: Battery Replacement
• Testing Battery charge with Power Cord plugged in will yield false results. Battery Replacement The ServerLIFT SL-500X data center lift uses an onboard low- maintenance, VRLA (valve-regulated lead-acid), AGM (Absorbed glass mat) battery. It is sealed and spill-proof. Replacements are commonly available from suppliers of high performance marine or UPS style batteries, or directly through ServerLIFT Service &... - Page 35 215 mm 23.83 kg Note: ONLY batteries with INTERNAL terminals will fit inside the ServerLIFT SL-500X data center lift. Batteries with external terminals will not work and may cause fire or explosion. 1. Open Panel Access Door. 2. A zip-tie installed to hold the...
-
Page 36: Stabilizer Brake Boot Replacement
11. Close Panel Access Door. 12. Verify ServerLIFT is receiving power from new Battery by turning it ON and cycling Platform up and down. Check that Battery Charge Level Indicator shows FULL when tested. -
Page 37: Pulley And Cable Inspection
Distortion, kinking, uneven strands, crushed parts, uneven cable diameter, or strands coming off Discontinue use of ServerLIFT device if any cable damage is discovered upon inspection, and contact ServerLIFT Service & Support immediately. Do not attempt to repair or change cable. -
Page 38: Specifications
Seamless install from the platform into the rails Smart Controls • Precise height adjustment with proprietary microprocessor-controlled lifting system • Dual side controls allow single operator to align equipment while facing the rack ServerLIFT SL-500X Data Center Lift Operator’s Manual ®... - Page 39 Specifications www.serverlift.com Telescoping Mast • SL-500X Lift 500 lb (227 kg) to 8’ or 2.45 m • Quickly raise equipment to the top of travel in under 1 minute TouchSTOP™ Sensor • Proprietary sensing technology cuts power to machine on contact with ceiling, lights, cable trays, or other overhead obstructions •...
-
Page 40: Dimensions And Capacity
Specifications www.serverlift.com Dimensions and Capacity, SL-500X Working Dimensions Metric Overall height Platform Height, Extended 7.86’ 2.40 m 176.25 cm Platform Height, Lowered 5.37” 13.6 cm 69.39 in Shelf Movement per side 6.0” 15.2 cm Movable Shelf Width 14.6” 36.8 cm Platform Width 24”... -
Page 41: Troubleshooting
Locking pin not engaging and groove. Adjust caster wheel until engagement with caster groove. occurs. Detailed directions for this adjustment available from ServerLIFT Service & Support. Caster groove or locking Replace worn or damaged hardware. pin worn or damaged. ServerLIFT SL-500X Data Center Lift Operator’s Manual... - Page 42 Adjust platform angle in the other direction. direction. SmartTILT mechanism Adjust platform angle in the other direction. If over-torqued in one unable to adjust, contact ServerLIFT Service & direction. Support. Platform cannot be adjusted DOWN when it is in Platform is in the lowest it's lowest position.
- Page 43 Open Panel Access Door. Check that all Main Circuit Board. connections to Main Circuit Board are secure. Main Circuit Board Contact ServerLIFT Service & Support for damaged. replacement part. Replace Circuit Board. Upper and/or Lower Limit Follow Raises But Does Not Lower and Lowers Switches are activated.
- Page 44 Limit Switch plunger is not stuck in depressed position. Make sure Tension Swing Arm is not engaging/depressing the switch plunger. Contact ServerLIFT Service & Support for Damaged Circuit Board. replacement part. Replace Circuit Board. Platform Lowers But Does Not Raise...
-
Page 45: Warranty
Will be free from defects in materials and workmanship. Will perform substantially in accordance with ServerLIFT’s published specifications. ServerLIFT will ship any parts that are in-warranty at no charge in accordance with the Limited Warranty Return & Repair Policy listed below. ServerLIFT will provide repair or replacement instructions as needed. - Page 46 • Description of the problem and/or desired service action. In the event of a return or repair that is determined to occur at ServerLIFT’s facilities, you will be issued a Warranty Repair Authorization (WRA) or case number and shipping instructions.
-
Page 47: Ce Declaration
Manufacturer: ServerLIFT Corporation 17453 N 25th Ave Phoenix, AZ 85023 USA 602-254-1557 www.serverlift.com Model numbers: SL-500X , SL-500XI™, SL-500FX™, SL-500FXI™ ® Max. Load Capacity: 227 kg (500 lbs) Type of equipment: Server and IT equipment lifting machine We declare that the product identified above meets the requirements of the... - Page 48 Manufacturer: ServerLIFT Corporation 17453 N 25th Ave Phoenix, AZ 85023 USA 602-254-1557 www.serverlift.com Model numbers: SL-500X , SL-500XI™, SL-500FX™, SL-500FXI™ ® Max. Load Capacity: 227 kg (500 lbs) Type of equipment: Server and IT equipment lifting machine We declare that the product identified above meets the requirements of the...
-
Page 49: Fcc Declaration
FCC Declaration www.serverlift.com Declaration of Conformity Client: ServerLIFT Corporation Model numbers: SL-500X , SL-500XI™ ® Type of equipment: Lifting device for IT equipment for use in data centers Manufacturer: ServerLIFT Corporation 17453 N 25th Ave, Phoenix, AZ 85023 USA 602-254-1557 Report Date: March 1 and 4, 2019 Test Performed By: Compatible Electronic Inc. - Page 50 ServerLIFT Corporation. All Rights Reserved. SL, ServerLIFT, SL-1000X, SL-500X, SL-500FX, SL-350X, and TouchSTOP are trademarks of ServerLIFT Corporation 17453 N 25th Ave | Phoenix, AZ 85023 | TEL: 602.254.1557 | FAX: 602.254.1975...
