Specifications
CAN
2-CH
USB
1-CH Type-C and 1-CH USB Host3.0
Ethernet
1-ch 1GB PHY
SDMMC
2-CH
SPDIF TX
2-CH
SPDIF RX
2-CH
I2C
9-CH
I3C
2-CH
SPI
5-CH
CAN
2-CH
UART
11-CH, 1-CH(DEBUG)
PWM
4-CH
ADC IN
2-CH
Board Dimension
57.5 x 44mm
1.5 CM3576 PCB Dimension
1.6 CM3576 Pin Definition
Pin
Signal
1
VCC_SYS
2
VCC_SYS
3
VCC_SYS
4
PWRON_L
5
VCC_3V3_S3
Customize the embedded system based on
Description or functions
System Power Input
System Power Input
System Power Input
Power Key input
3.3V GPIO Power output
7
GPIO serial
IO Voltage
3.4V-5.5V
3.4V-5.5V
3.4V-5.5V
3.4V-5.5V
Max 500mA
Your Idea
3.3V
