Installation Instructions

Instrucciones de Instalación /

Instructions d'installation /

Installationsanleitung /

Istruzioni per l'installazione

USB-C 3.2 Gen 1 Active Extension

Cable, 5 m (16.4 ft.)

Cable de extensión activo USB-C 3.2 Gen 1, 5 m

Rallonge active USB-C 3.2 Gen 1, 5 m

USB-C 3,2 Gen 1 Aktives Verlängerungskabel, 5 m

Cavo di prolunga attivo USB-C 3.2 Gen 1, 5 m

Note: For power applications stronger than 770mA, you must

connect a compatible DC 5V external power supply or cable

with a barrel connector of 3.5 x 1.35 x 7.5 mm (positive pin,

negative sleeve), sold separately.
