- Page 1 Manual Conveyor Toaster Model: CT280/400 MAN CT280/400 ADV CT280/400 STD CT400 STD P, CT400 ADV P CT550 STD P, CT550 ADV P Type code: ACT-23; SCT-23 Version 9.1...
-
Page 2: Table Of Contents
CT280/CT400 STD ........................11 Repairs and spare parts ......................12 Specifications for spare parts ......................12 Spare parts CT280 ADV ......................13 Spare parts CT280 STD ......................14 Spare parts CT400 ADV ......................15 Spare parts CT400 STD ....................... 16 Spare parts CT550 STD P ...................... - Page 3 Daily cleaning ........................... 26 Disposal..............................26 Packaging ............................26 When the Appliance is no longer required..................26 EU DECLARATION OF CONFORMITY ......................27...
-
Page 4: General
Introduction Original user instructions These instructions are FKI Fast Food Teknik's original instructions for the appliance. The purpose of these instructions These instructions are intended to ensure the correct installation, use, handling, and maintenance of the Combi Toaster. Hereinafter referred to as “the appliance”. -
Page 5: Appliance Label
1.1.4.1 Dimensions and weight Model Outer dimensions W x D x H Weight in kg 412 x 545 x 430 mm CT280 ADV 21,5 412 x 545 x 430 mm CT280 STD 412 x 545 x 430 mm CT280 MAN... -
Page 6: Modification
These instructions and the appliance itself are provided with important safety information that must always be read and always observed. FKI Fast Food Teknik A/S denies any and all liability for non-compli- ance with these safety instructions, for inappropriate use of the appliance or the use of incorrect settings. -
Page 7: Personal Safety Equipment
Personal safety equipment is recommended that gloves and goggles are worn when working with the appliance, as the surfaces of the Combi Toaster are hot and there may be a risk of hot grease. Potential hazards When the appliance is in use, the user should be aware that the appliance is hot. Do not touch the warm surfaces or the conveyor band transporting the bread through the appliance without wear- ing protective gloves. -
Page 8: Transport/Installation/Fastening
Transport/installation/fastening Transport The appliance is supplied in transport packaging and should only be transported in the same way if it is moved. WARNING: The machine must not be moved during operation. Moving and setting up the appliance must be performed by two or more people! RISK of injury! Wear protective gloves and safety footwear during unpacking and installation... -
Page 9: Fixation
Any replacement of the power cord must be performed by an authorised technician to avoid the risk of personal injury - RISK of electric shock. Only use oil-resistant cables! Fixation The appliance does not need to be secured. It is equipped with adjustable legs to ensure stable and easy installation. -
Page 10: Operation
3 Operation Before first use Before start-up, remove all packaging and protective plastic from the appliance and dispose of it in accordance with currently applicable regulations (see section 5.1). Carefully read section 2 about safety before connecting the appliance. Before start-up, clean the appliance as shown in section CT280/CT400 ADV As a starting point the Conveyor Toaster is delivered in sensor mode with two... -
Page 11: Ct280/Ct400 Std
ECO Function without sensor If you wish the sensor deactivated, this can be done by having the Conveyor Toaster turned on and holding down the ECO button for three seconds. The conveyor toaster turns off. The next time the Conveyor Toaster is turned on, the sensor will be inactive, this can be noticed by the fact that there is no longer a red light on the black plate to the left of the band. -
Page 12: Repairs And Spare Parts
Repairs and spare parts Repairs should only be carried out by authorized service personnel with knowledge of electrical equipment. Specifications for spare parts... -
Page 13: Spare Parts Ct280 Adv
Spare parts CT280 ADV Part No. Pcs. Description 13-80285 Cabinet parts CT280 ADV 83-08458 Conveyor belt 83-08596 Insulator set for Quartz tube 83-08595 Quartz tube 83-08654 Heating element (Spiral) 83-09531 Drive Shaft UT280 72-03508 Terminal Block 2-POL Porcelain 83-08616 Chainwheel Cog NAV 05B1 Z13 Ø8 M5 Pinol 83-08584 Chainwheel Cog M8X3 Z10 Ø8 PINOL M4... -
Page 14: Spare Parts Ct280 Std
Spare parts CT280 STD Part No. Pcs. Description 13-80280 Cabinet parts CT280 STD 83-08458 Conveyor belt 83-08596 Insulator set for Quartz tube 83-08595 Quartz tube 83-08654 Heating element (Spiral) 83-09531 Drive Shaft UT280 83-08616 Chainwheel Cog 05B1 Z13 Ø8 M5 Pinol 83-06595 Gearmotor SAIA UT 280/400 83-08584... -
Page 15: Spare Parts Ct400 Adv
Spare parts CT400 ADV VARE NUMMER BENÆVNELSE 13-80405 Cabinet Parts CT400 ADV 83-08879 Conveyor belt 83-08596 Insulator set for Quartz tube 83-08883 Quartz tube 83-08654 Heating element (Spiral) 83-09533 Drive Shaft UT400 72-03508 Terminal 2-POL PORCELÆN 83-08616 Chainwheel 05B1 Z13 Ø8 M5 pinol 83-08584 chainwheel M8X3 Z10 Ø8 PINOL M4 83-10027... -
Page 16: Spare Parts Ct400 Std
Spare parts CT400 STD VARE NUMMER BENÆVNELSE 13-80400 Cabinet Parts CT400 STD 83-08879 Conveyor belt 83-08596 Insulator set for Quartz tube 83-08883 Quartz tube 83-08654 Heating element (Spiral) 83-09533 Drive Shaft UT400 83-08616 Chainwheel 05B1 Z13 Ø8 M5 pinol 83-06595 GEARMOTOR SAIA UT 280/400 83-08584 chainwheel M8X3 Z10 Ø8 PINOL M4... -
Page 17: Spare Parts Ct550 Std P
Spare parts CT550 STD P VARE NUM- BENÆVNELSE 13-80550 Cabinet parts CT550 STD 83-10343 Conveyor belt 559x1,83x12,7MM (920mm) 83-08596 insutator FOR QUARTTUBE 83-08595 QUARTSTUBE 83-08654 Heatelement 72-03508 Termainal 2-POL 83-08616 chainwheel 05B1 Z13 Ø8 M5 pinol 83-08584 chainwheel M8X3 Z10 Ø8 PINOL M4 83-10027 GEARMOTOR UT-V, DME34B5500B 24Vdc 72-07021... -
Page 18: Spare Parts Ct550 Adv P
Spare parts CT550 ADV P VARE NUM- BENÆVNELSE 13-80555 Cabinet parts CT550 ADV 83-10343 Conveyor belt 559x1,83x12,7MM (920mm) 83-08596 insutator FOR QUARTTUBE 83-08595 QUARTSTUBE 83-08654 Heatelement 72-03508 Termainal 2-POL 83-08616 chainwheel 05B1 Z13 Ø8 M5 pinol 83-08584 chainwheel M8X3 Z10 Ø8 PINOL M4 83-10027 GEARMOTOR UT-V, DME34B5500B 24Vdc 72-07021... -
Page 19: Electrical Diagrams
Electrical diagrams... -
Page 26: Cleaning
4 Cleaning General Remember to use personal safety equipment. see 2.1 Before using the appliance for the first time, wipe all surfaces that will be in contact with food with a damp cloth. Do not use cleaning products that contain acid. Daily cleaning Clean any excess cooking grease off the Appliance several times a day. - Page 27 6 EU DECLARATION OF CONFORMITY...
- Page 28 Byghøjvej 5 · Verninge · DK-5690 Tommerup · Tel. +45 6475 1066 · info@fki.dk · www.fki.dk...
