- Page 1 Instructions for use Unitoaster Model: UT280/400 UT280V/400V UT280EV/400EV UT280V BB/400V BB Type code: SCT-06 Version 2.2 – September 2021...
-
Page 2: Table Of Contents
Contents Introduction ............................... 3 General .............................. 3 Appliance description ........................3 Manufacturer ..........................3 Appliance label ..........................4 Technical specifications and power consumption ............... 4 Modification ..........................5 Safety ................................. 5 Personal safety equipment ........................ 6 Potential hazards ..........................6 Who may use the Appliance ...................... -
Page 3: Introduction
1 Introduction Original user instructions These instructions are FKI Fast Food Teknik's original instructions for Unitoaster. The purpose of these instructions These instructions are intended to ensure the correct installation, use, handling and maintenance of Unitoaster. Hereinafter referred to as “the Appliance”. -
Page 4: Appliance Label
Appliance label 1.1.3.1 Type designation SCT-06 Technical specifications and power consumption 1.1.4.1 Dimensions and weight Model designation Width x depth x height Weight in kg 410 x 510 x 420 mm UT280 410 x 510 x 420 mm UT280V 410 x 510 x 420 mm UT280EV 410 x 510 x 420 mm UT280V BB... -
Page 5: Modification
These instructions and the appliance itself are provided with important safety information that must always be read and observed at all times. FKI Fast Food Teknik a/s disclaims any and all liability for non- compliance with these safety instructions, for inappropriate use of the appliance or the use of incorrect set-... -
Page 6: Personal Safety Equipment
Personal safety equipment We recommend that gloves are worn when working with the Appliance. When cleaning the Appliance, gloves and safety glasses should be worn as the surfaces of the Appliance are very hot. Potential hazards When the Appliance is in use, the user should be aware that the Appliance is hot. Do not touch the hot surfaces or conveyor that pulls the bread through the Appliance unless wearing protective gloves. -
Page 7: Transport/Installation/Fixation
Transport/installation/fixation Transport The Appliance is delivered secured to a transport pallet and should only be transported in the same way if moved. WARNING: Do not move the Appliance during operation. Moving and setting up the Appliance must be performed by two or more peo- ple! RISK of injury! Wear protective gloves and safety footwear during unpacking and installation. -
Page 8: Fixation
Any replacement of the power cord must be performed by an authorised technician to avoid the risk of personal injury – RISK of electric shock. Only use oil-resistant cables! Fixation The Appliance does not need to be secured. It is equipped with adjustable legs to ensure stable and easy installation. -
Page 9: Servicing
Servicing The Appliance must always be switched off and disconnected from the power source before com- mencing repairs. Repairs to the Appliance must only be performed by authorised personnel. 3 Operation Before first use Before start-up, remove all packaging and protective plastic from the Appliance and dispose of it in accordance with currently applicable regulations (see section 5.1). - Page 10 ECO-Variable model: The Appliance is available in an energy-friendly variant (EV) where conveyor and heating elements are started/stopped automatically using a touch-free sensor. This variant starts when bread is placed on the conveyor and turns off again after about two minutes. A new two minute period activates whenever bread is placed on the conveyor.
-
Page 11: Repairs And Spare Parts
Repairs and spare parts Repairs should only be carried out by authorised service personnel with knowledge of electrical equipment. Specifications for spare parts Spare parts diagrams UT280/400 Pos. Part no. Pcs. Description 83-08595 Quartz tube UT 280 – Ø11 x 320 mm 83-08883 Quartz tube UT 400 –... - Page 12 83-08654 Heat coil 115V – 500W 83-08596 Insulation kit 83-41017 Breaker switch, rotary 83-07908 Switch 83-06453 Dimmer plug, black 83-06546 Bread drawer UT 280 83-06581 Bread drawer UT 400 83-08652 Handle for bread drawer cover 83-06526 Cover for bread drawer UT 280 (extra equipment) 83-06587 Cover for bread drawer UT 400 (extra equipment) 81-06028...
- Page 13 UT280V/400V Pos. Part no. Pcs. Description 83-08595 Quartz tube UT 280 – Ø11 x 320 mm 83-08883 Quartz tube UT 400 – Ø11 x 440 mm 83-08654 Heat coil 115V – 500W 83-08596 Insulation kit 83-41017 Breaker switch, rotary 83-07908 Switch 83-10029 Regulator...
- Page 14 83-07680 Terminal block 4-pole 83-08078 Chain 83-08584 Cog, bottom z10 83-08616 Cog, top z13 83-10028 Power supply 240VAC 12V 83-08688 Bronze bearing 83-06523 Reflector panel UT280 83-06616 Reflector panel UT400...
- Page 15 UT280EV/400EV Pos. Part no. Pcs. Description 83-08595 Quartz tube UT 280 – Ø11 x 320 mm 83-08883 Quartz tube UT 400 – Ø11 x 440 mm 83-08654 Heat coil 115V – 500W 83-08596 Insulation kit 83-41017 Breaker switch, rotary 72-03521 Cable retainer PG11, steel 83-10029 Regulator...
- Page 16 83-06587 Cover for bread drawer UT 400 (extra equipment) 81-06028 Legs black(Bumpers) 83-06595 Gear drive 83-07608 Terminal block 3-POLE 6.0mm2 83-08078 Chain 83-08584 Cog, bottom z10 83-08616 Cog, top z13 83-08688 Bronze bearing 83-06523 Reflector panel UT280 83-06616 Reflector panel UT400 88-00231 Solid state relay 480V single phase 35A 72-00111...
-
Page 17: Electrical Diagrams
Electrical diagrams... -
Page 23: Cleaning
4 Cleaning General Remember to use personal safety equipment. see 2.1 Before using the appliance for the first time, wipe all surfaces that will be in contact with food with a damp cloth. Do not use cleaning products that contain acid. Daily cleaning Clean any excess cooking grease off the Appliance several times a day. -
Page 24: Eu Declaration Of Conformity
6 EU DECLARATION OF CONFORMITY... - Page 25 Byghøjvej 5 · Verninge · DK-5690 Tommerup · Denmark · Tel. +45 6475 1066 · info@fki.dk · www.fki.dk...
