Any and all information, including, among others, wordings, pictures, graphs are the properties of

Hangzhou EZVIZ Software Co., Ltd. (hereinafter referred to as "EZVIZ"). This user manual (hereinafter

referred to as "the Manual") cannot be reproduced, changed, translated, or distributed, partially or

wholly, by any means, without the prior written permission of EZVIZ. Unless otherwise stipulated,

EZVIZ does not make any warranties, guarantees or representations, express or implied, regarding to

the Manual.

About this Manual

The Manual includes instructions for using and managing the product. Pictures, charts, images and

all other information hereinafter are for description and explanation only. The information contained

in the Manual is subject to change, without notice, due to firmware updates or other reasons. Please

find the latest version in the

™ website (http://www.ezviz.com).

Revision Record

New release – January, 2023

Trademarks Acknowledgement

™,

™, and other EZVIZ's trademarks and logos are the properties of EZVIZ in various

jurisdictions. Other trademarks and logos mentioned below are the properties of their respective

owners.

Legal Disclaimer

TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THE PRODUCT DESCRIBED, WITH

ITS HARDWARE, SOFTWARE AND FIRMWARE, IS PROVIDED "AS IS", WITH ALL FAULTS AND ERRORS,

AND EZVIZ MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WITHOUT LIMITATION,

MERCHANTABILITY, SATISFACTORY QUALITY, FITNESS FOR A PARTICULAR PURPOSE, AND

NON-INFRINGEMENT OF THIRD PARTY. IN NO EVENT WILL EZVIZ, ITS DIRECTORS, OFFICERS,

EMPLOYEES, OR AGENTS BE LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR

INDIRECT DAMAGES, INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF BUSINESS PROFITS,

BUSINESS INTERRUPTION, OR LOSS OF DATA OR DOCUMENTATION, IN CONNECTION WITH

THE USE OF THIS PRODUCT, EVEN IF EZVIZ HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH

DAMAGES.

TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO EVENT SHALL EZVIZ'S TOTAL

LIABILITY FOR ALL DAMAGES EXCEED THE ORIGINAL PURCHASE PRICE OF THE PRODUCT.

EZVIZ DOES NOT UNDERTAKE ANY LIABILITY FOR PERSONAL INJURY OR PROPERTY DAMAGE AS

THE RESULT OF PRODUCT INTERRUPTION OR SERVICE TERMINATION CAUSED BY: A) IMPROPER

INSTALLATION OR USAGE OTHER THAN AS REQUESTED; B) THE PROTECTION OF NATIONAL OR

PUBLIC INTERESTS; C) FORCE MAJEURE; D) YOURSELF OR THE THIRD PARTY, INCLUDING WITHOUT

LIMITATION, USING ANY THIRD PARTY'S PRODUCTS, SOFTWARE, APPLICATIONS, AND AMONG

OTHERS.

REGARDING TO THE PRODUCT WITH INTERNET ACCESS, THE USE OF PRODUCT SHALL BE WHOLLY

AT YOUR OWN RISKS. EZVIZ SHALL NOT TAKE ANY RESPONSIBILITES FOR ABNORMAL OPERATION,

PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER ATTACK, HACKER ATTACK,

VIRUS INSPECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER, EZVIZ WILL PROVIDE

TIMELY TECHNICAL SUPPORT IF REQUIRED.SURVEILLANCE LAWS AND DATA PROTECTION

LAWS VARY BY JURISDICTION. PLEASE CHECK ALL RELEVANT LAWS IN YOUR JURISDICTION

BEFORE USING THIS PRODUCT IN ORDER TO ENSURE THAT YOUR USE CONFORMS TO THE

APPLICABLE LAW. EZVIZ SHALL NOT BE LIABLE IN THE EVENT THAT THIS PRODUCT IS USED WITH

ILLEGITIMATE PURPOSES.

IN THE EVENT OF ANY CONFLICTS BETWEEN THE ABOVE AND THE APPLICABLE LAW, THE LATTER

PREVAILS.

Table of Contents

Need help?

Do you have a question about the DL01 Pro and is the answer not in the manual?

Questions and answers

Summary of Contents for Ezviz DL01 Pro

Page 1 INDIRECT DAMAGES, INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF BUSINESS PROFITS, BUSINESS INTERRUPTION, OR LOSS OF DATA OR DOCUMENTATION, IN CONNECTION WITH THE USE OF THIS PRODUCT, EVEN IF EZVIZ HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO EVENT SHALL EZVIZ’S TOTAL LIABILITY FOR ALL DAMAGES EXCEED THE ORIGINAL PURCHASE PRICE OF THE PRODUCT.
Page 2: Table Of Contents
2� Start Installation �� 9 3� Battery Installation and Replacement �� 10 Add Lock to EZVIZ ��11 1� Add Lock to EZVIZ �� 11 2� Calibrate the Lock �� 13 3� Link Bluetooth Door Sensor �� 14 4� Installation Complete �� 15 Bluetooth Key Management ��15...
Page 3: Instruction
Instruction • The installation of EZVIZ Smart Lock (hereinafter referred as to "lock") impacts its normal operation and service life. It is recommended to let professionals install. • The lock is designed for indoor use only. • It is recommended to remove the lock if your house is under decoration, and reinstall it after decoration in case of lock damage and service life reduction.
Page 4 2� Basics Smart Lock Key Knob Battery Belt Front Cover Battery Slot Key Slot Mounting Hole Mounting Hole Matching Key (LED Indicator Ring)
Page 5 • When you need to change batteries, drag the belt and the batteries will pop out. • Press once, the lock will be locked/unlocked. • In initialization condition, press and hold for 3s to add to EZVIZ App. Matching Key • Remove the batteries, press and hold the Matching Key and install the batteries...
Page 6 Get the EZVIZ App 1. Connect your mobile phone to Wi-Fi (suggested). 2. Download and install the EZVIZ app by searching “EZVIZ” in the App Store or Google Play 3. Launch the app and register an EZVIZ user account. EZVIZ App If you have already used the app, please make sure that it is the latest version.
Page 7: 1� Install Mounting Plate
The lock is mounted on the inside of the existing lock cylinder. There are two different types of mounting plates to choose depending on your cylinder: If the lock cylinder is with button, you can purchase the EZVIZ adapter for lock cylinder with button for installation.
Page 8 • Mounting Plate B Cylinder with more than 3mm overhang on the inside of the door : fix the mounting plate B to the cylinder with screws by the supplied hexagon wrench. Please fix the screws that already in the mounting plate carefully and without great physical effort to avoid damaging the cylinder. 3~30mm 3~30 mm...
Page 9: 2� Insert The Key Into The Lock
2� Insert the Key into the Lock The lock is supposed to enable keyless door opening. For lock to be compatible with the key, the following conditions must apply: - The key must not be thicker than 5 mm. - The length of the key head including the neck must be less than 40 mm for lock to be compatible (The key head is the part of the key which people opening the door grasps.
Page 10: 3� Mount The Lock Body
3� Mount the Lock Body Attach the lock body to the mounting plate with three screws (PM3×16) by the supplied plus driver, (take Mounting Plate A for example). 4� Insert Batteries Insert 4 AA-sized batteries into the slot. Please pay attention to positive and negative poles when insert the batteries.
Page 11: Install The Bluetooth Door Sensor
2. Remove the battery insulation strip as instructed in the figure below. Battery Insulation Strip • When the battery level is low, the low battery notification will be pushed to the EZVIZ app to remind you to replace batteries. • If you need to replace batteries, please purchase two CR1632 batteries.
Page 12: 3� Battery Installation And Replacement
<20mm Installation Instruction Groove 3� Battery Installation and Replacement 1� Install Battery Tear off the battery insulation, put the battery into the baseplate and insert it to the end. 2� Replace Battery Remove the battery from baseplate and replace battery with the Lithium Battery CR1632 purchased by a regular manufacturer.
Page 13: Add Lock To Ezviz
1� Add Lock to EZVIZ 1. Log in to your account through EZVIZ app, tap the device adding icon and then the QR code scanning interface will be displayed. 2. Scan the QR code on the back of the smart lock's front cover or on the user manual.
Page 14 LED indicator ring is solid orange, all parameters will be restored to factory settings. • During adding configuration EZVIZ may ask for the Bluetooth permission includes the scanning, adding and using Bluetooth devices. Please click Yes to grant this permission.
Page 15: 2� Calibrate The Lock
2� Calibrate the Lock • Automatic Calibration After adding the lock to EZVIZ, you need to calibrate the installation state according to the wizard on the page. 1. Choose the lock type. Lock type Please choose your lock type Doorlock with latch bolt Doorlock without latch bolt 2.
Page 16: 3� Link Bluetooth Door Sensor
2. After set the lock type successfully. Check out your lock and confirm it is locked or unlocked when the door lock knob turned clockwise. 3. Turn the key knob and record the number of turns does it need to unlock (lock tongue retracted). 3�...
Page 17: 4� Installation Complete
• If you have no accessory of the keypad, the installation of lock is completed. 1. After the installation complete, you can unlock the door on the EZVIZ app from outside the door. 2. Launch the EZVIZ app, tap your lock and slide right to unlock as shown below.
Page 18: Operation And Management
EZVIZ app. 3. Unclosed Door Alarm After enabling the Reminder of Door Not Closed in Alarm Settings in the EZVIZ app, a push reminder will be sent to you if the door is not closed within the set time.
Page 19: Operations On The Ezviz App
The app interface may be different due to version update, and the interface of the app you installed on your phone shall prevail. 1� Detail Page When you launch the EZVIZ app and tap your lock, you can view and manage the lock as needed on the detail page. Icon Description Slide right to unlock.
Page 20: 2� Settings
Battery Check to the storage of the battery of the lock. If you want to remotely control your door lock, you will need to use it with a gateway. Please purchase a EZVIZ gateway and follow these steps: 1. Log in to the EZVIZ app.
Page 21 Bluetooth keys, cards, passwords so manual input is not required. • Change the management code: you can change the code if needed. Device Information You can see the device information here. Delete device Tap to delete the lock from your EZVIZ account.
Page 22: Maintenance
There is magnetic field ensuring that there is no interference of abrupt door or abnormal locking interference around the lock. change of magnetic field in the surrounding when opening the door. environment. For additional information about the device, please refer to www.ezviz.com/eu.
Page 23 INFORMATION FOR PRIVATE HOUSEHOLDS 1. Separate collection of waste equipment: Electrical and electronic equipment that has become waste is referred to as waste equipment. Owners of waste equipment must dispose of it separately from unsorted municipal waste. In particular, waste equipment does not belong in household waste, but in special collection and return systems.
