Any and all information, including, among others, wordings, pictures, graphs are the properties of

Hangzhou EZVIZ Software Co., Ltd. (hereinafter referred to as "EZVIZ"). This user manual (hereinafter

referred to as "the Manual") cannot be reproduced, changed, translated, or distributed, partially or

wholly, by any means, without the prior written permission of EZVIZ. Unless otherwise stipulated,

EZVIZ does not make any warranties, guarantees or representations, express or implied, regarding to

the Manual.

About this Manual

The Manual includes instructions for using and managing the product. Pictures, charts, images and

all other information hereinafter are for description and explanation only. The information contained

in the Manual is subject to change, without notice, due to firmware updates or other reasons. Please

find the latest version in the

™ website (http://www.ezviz.com).

Revision Record

New release – January, 2022

Trademarks Acknowledgement

™,

™, and other EZVIZ's trademarks and logos are the properties of EZVIZ in various

jurisdictions. Other trademarks and logos mentioned below are the properties of their respective

owners.

Legal Disclaimer

TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THE PRODUCT DESCRIBED, WITH

ITS HARDWARE, SOFTWARE AND FIRMWARE, IS PROVIDED "AS IS", WITH ALL FAULTS AND ERRORS,

AND EZVIZ MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WITHOUT LIMITATION,

MERCHANTABILITY, SATISFACTORY QUALITY, FITNESS FOR A PARTICULAR PURPOSE, AND

NON-INFRINGEMENT OF THIRD PARTY. IN NO EVENT WILL EZVIZ, ITS DIRECTORS, OFFICERS,

EMPLOYEES, OR AGENTS BE LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR

INDIRECT DAMAGES, INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF BUSINESS PROFITS,

BUSINESS INTERRUPTION, OR LOSS OF DATA OR DOCUMENTATION, IN CONNECTION WITH

THE USE OF THIS PRODUCT, EVEN IF EZVIZ HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH

DAMAGES.

TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO EVENT SHALL EZVIZ'S TOTAL

LIABILITY FOR ALL DAMAGES EXCEED THE ORIGINAL PURCHASE PRICE OF THE PRODUCT.

EZVIZ DOES NOT UNDERTAKE ANY LIABILITY FOR PERSONAL INJURY OR PROPERTY DAMAGE AS

THE RESULT OF PRODUCT INTERRUPTION OR SERVICE TERMINATION CAUSED BY: A) IMPROPER

INSTALLATION OR USAGE OTHER THAN AS REQUESTED; B) THE PROTECTION OF NATIONAL OR

PUBLIC INTERESTS; C) FORCE MAJEURE; D) YOURSELF OR THE THIRD PARTY, INCLUDING WITHOUT

LIMITATION, USING ANY THIRD PARTY'S PRODUCTS, SOFTWARE, APPLICATIONS, AND AMONG

OTHERS.

REGARDING TO THE PRODUCT WITH INTERNET ACCESS, THE USE OF PRODUCT SHALL BE WHOLLY

AT YOUR OWN RISKS. EZVIZ SHALL NOT TAKE ANY RESPONSIBILITES FOR ABNORMAL OPERATION,

PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER ATTACK, HACKER ATTACK,

VIRUS INSPECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER, EZVIZ WILL PROVIDE

TIMELY TECHNICAL SUPPORT IF REQUIRED.SURVEILLANCE LAWS AND DATA PROTECTION

LAWS VARY BY JURISDICTION. PLEASE CHECK ALL RELEVANT LAWS IN YOUR JURISDICTION

BEFORE USING THIS PRODUCT IN ORDER TO ENSURE THAT YOUR USE CONFORMS TO THE

APPLICABLE LAW. EZVIZ SHALL NOT BE LIABLE IN THE EVENT THAT THIS PRODUCT IS USED WITH

ILLEGITIMATE PURPOSES.

IN THE EVENT OF ANY CONFLICTS BETWEEN THE ABOVE AND THE APPLICABLE LAW, THE LATTER

PREVAILS.

Table of Contents

Need help?

Do you have a question about the DL01S and is the answer not in the manual?

Questions and answers

Summary of Contents for Ezviz DL01S

Page 1 INDIRECT DAMAGES, INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF BUSINESS PROFITS, BUSINESS INTERRUPTION, OR LOSS OF DATA OR DOCUMENTATION, IN CONNECTION WITH THE USE OF THIS PRODUCT, EVEN IF EZVIZ HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO EVENT SHALL EZVIZ’S TOTAL LIABILITY FOR ALL DAMAGES EXCEED THE ORIGINAL PURCHASE PRICE OF THE PRODUCT.
Page 2: Table Of Contents
3� Mount the Lock Body �� 8 4� Instert Batteries �� 8 Add Lock to EZVIZ ��9 1� Add Lock to EZVIZ �� 9 2� Calibrate the Lock �� 10 3� Install the Door Sensor �� 11 4� Installation Complete �� 12 Bluetooth Key Management ��13...
Page 3: Instruction
Instruction • The installation of EZVIZ Smart Lock (hereinafter referred as to "lock") impacts its normal operation and service life. It is recommended to let professionals install. • The lock is designed for indoor use only. • It is recommended to remove the lock if your house is under decoration, and reinstall it after decoration in case of lock damage and service life reduction.
Page 4: Overview
Overview 1� Lock Key Knob Front Cover Battery Belt Battery Slot Key Slot Matching Key (LED Indicator Ring）...
Page 5: 2� Door Sensor
Get the EZVIZ App 1. Connect your mobile phone to Wi-Fi (suggested). 2. Download and install the EZVIZ app by searching for “EZVIZ” in the App Store or Google Play 3. Launch the app and register an EZVIZ user account.
Page 6: Installation Instructions
Installation Instructions Make sure your existing lock allows you to fully insert the keys from both sides to unlock. Please tap to watch the installation video.
Page 7: 1� Install Mounting Plate
1� Install Mounting Plate The lock is mounted on the inside of the existing lock cylinder. There are two different types of mounting plates to choose depending on your cylinder: Mounting Plate A Cylinder with less than 3mm overhang on the inside of the door: The lock is glued to your door with special adhesive pads.
Page 8 Mounting Plate B Cylinder with at least 3mm overhang on the inside of the door : fix the mounting plate B to the cylinder with screws by the supplied hexagon wrench. Please fix the screws carefully and without great physical effort to avoid damaging the cylinder.
Page 9: 2� Insert The Key Into The Lock
2� Insert the Key into the Lock The lock is supposed to enable keyless door opening. For lock to be compatible with the key, the following conditions must apply: - The key must not be thicker than 4 mm. - The length of the key head including the neck must be less than 37 mm for lock to be compatible (The key head is the part of the key which people opening the door grasps.
Page 10: 3� Mount The Lock Body
3� Mount the Lock Body Attach the lock body to the mounting plate with three screws (PM3×16) by the supplied plus driver, (take Mounting Plate A for example). 4� Instert Batteries Insert 4 AA-sized batteries into the slot. Please pay attention to positive and negative poles when insert the batteries.
Page 11: Add Lock To Ezviz
1� Add Lock to EZVIZ 1. Log in to your account through EZVIZ app, tap the device adding icon and then the QR code scanning interface will be displayed. 2. Scan the QR code on the back of the front cover.
Page 12: 2� Calibrate The Lock
2� Calibrate the Lock Automatic Calibration After adding the lock to EZVIZ, you need to calibrate the installation state according to the wizard on the page. 1. Please open the door and keep the lock tongue retracted and click the Next Step.
Page 13: 3� Install The Door Sensor
1. Please stand inside the door and attach the door sensor to the door frame and close to the lock. Please note that the center of the door sensor should be parallel to EZVIZ logo on the cover, as shown in the figure below.
Page 14: 4� Installation Complete
If your door protrudes beyond the door frame, it is recommended to attach the door sensor on the other side of the door frame. Please note that the center of the door sensor should be parallel to EZVIZ logo on the cover, as shown in the figure below.
Page 15: Bluetooth Key Management
• Retry from step 1. 2� Manage Bluetooth Keys Lauch your EZVIZ app within bluetooth range and make sure your phone is bluetooth connected to the lock. Click More button behind their name, you can set term of validity and delete their bluetooth key.
Page 16: 2� Manage Accessory
EZVIZ app after you bind the keypad to the lock. 2. Lauch your EZVIZ app within bluetooth range and make sure your phone is bluetooth connected to the lock. 3. Tap your lock and choose Settings -> Accessory Management and choose the type of your accessory. Here we take password keypad as an example.
Page 17: 2� Lock
App Lock Timed Lock Auto lock requires the using of door sensor. For detailed information, please refer to Chapter Add Lock to EZVIZ -> Install the Door Sensor� 3� Operation and Management Bluetooth connection mode In consideration of quick reponse and power consumption, the lock provides 3 different bluetooth connection...
Page 18: Maintenance
1. Lauch your EZVIZ app within bluetooth range and make sure your phone is bluetooth connected to the lock. 2. Tap your lock and choose Setting -> Bluetooth Connection Mode and set the mood you need. Install Batteries Install batteries: press the button on the bottom and remove the front cover, drag the belt and the batteries will pop out.Install 4*AA-sized batteries into the slot, and then press battery cover.
Page 19 Clutch components fault. Ask professionals to check the lock. The lock remains open, and cannot be used The door sensor doesn't work Calibrate the door sensor again. normally. properly. For additional information about the device, please refer to www.ezviz.com.
Page 20: Operations On The Ezviz App
The app interface may be different due to version update, and the interface of the app you installed on your phone shall prevail. When you launch the EZVIZ app and tap your lock, you can view and manage the lock as needed on the homepage.
